Owner's guide

NV350Q

NV350Q_26_IB_ENG_101019.indd 1

10-10-19 9:19 AM

Table of Contents

Summary of Contents for Shark NV350Q

Page 1 Owner’s guide NV350Q NV350Q_26_IB_ENG_101019.indd 1 10-10-19 9:19 AM...
Page 2: Important Safety Instructions
WHEN USING AN ELECTRICAL APPLIANCE, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE OBSERVED, INCLUDING THE FOLLOWING: READ ALL INSTRUCTIONS BEFORE USING YOUR SHARK NAVIGATOR LIFT-AWAY. ® POLARIZED PLUG: To reduce the risk of electric shock, this appliance has a polarized plug (one blade is wider than the other).
Page 3 6. DO NOT allow young children to operate the vacuum or use as a toy. Close attention is necessary when used by or near children. 7. DO NOT use vacuum cleaner if it has been dropped, damaged, left outdoors, or submerged in water. Return to EURO-PRO Operating LLC for examination, repair, or adjustment.
Page 4 This manual covers model number: NV350Q 26 TECHNICAL SPECIFICATIONS Voltage: 120V., 60Hz Watts: 1200W Amps: NV350Q_26_IB_ENG_101019.indd 4 10-10-19 9:19 AM...
Page 5: Table Of Contents
Contents Thank you for Getting Started purchasing Mode 1: Upright Vac the Shark ® Mode 2: Detachable Canister Navigator Above-Floor Cleaning Lift-Away. With Floor Nozzles Duster with Micro-Fiber Pad Storing Maintenance Troubleshooting Guide Warranty NV350Q_26_IB_ENG_101019.indd 5 Emptying the Dust Cup...
Page 6: Getting Started
Getting Started FIRST THING’S FIRST, YOU NEED TO KNOW WHAT’S IN THE BOX YOU JUST OPENED: Hose Handle with Stretch Extension Wan Detachable Canist zzle Motorized Floor Brush No Crevice T Dusting Br Turbo Brush Bare Floor Nozzle Extension Tube Duster with Micro-Fiber Pad NV350Q_26_IB_ENG_101019.indd 6 Fig.
Page 7: Navigator Lift-Away
Your new Shark Navigator Lift-Away vacuum cleaner can easily be configured into different ® cleaning modes to meet all your cleaning needs: upright vacuum and detachable canister - both with constant suction power. Fig. 7 MODES: UPRIGHT VAC Upright vacuuming - floors and carpets. (Fig. 7) NV350Q_26_IB_ENG_101019.indd 7...
Page 8: Mode 1: Upright Vac
Mode 1: Upright Vac To reduce the risk of electric shock, unplug the unit before assembling, adding or removing attachments or converting modes. WARNING: The On/Off switch is on the top of the detachable canister. Always ensure the power is OFF (“O”...
Page 9 Cord Hook Release Collar Fig. 13 TO USE: Rotate the cord release to quickly release the power cord. Secure the power cord in the cord hook (a). (Fig. 13) = Brush Roll ON = Bare Floor = OFF Press the On/Off switch (b) to the “I” position to vacuum bare floors (straight suction only) or to the “II”...
Page 10: Mode 2: Detachable Canister
Mode 2: Detachable Canister You can carry your vacuum cleaner in both modes by the carry handle located on top of the dust cup. Fig. 15 LIFT AWAY DETACHABLE CANISTER FOR PORTABLE CLEANING Separate the detachable canister from the floor nozzle.
Page 11: Above-Floor Cleaning
Above-Floor Cleaning Fig. 17 Suction Release Collar CLEAN ABOVE THE FLOOR IN UPRIGHT VAC OR DETACHABLE CANISTER MODE Press the handle release button and pull the handle up or press the extension wand release button and pull the extension wand up. Attach desired accessory onto the end of either the extension wand or the handle.
Page 12: Duster With Micro-Fiber Pad
Store the dusting brush and the crevice tool on the mounts on the accessory holder. Store your vacuum cleaner safely in a cool dry area where it will not be a hazard, will not get damaged and will not cause damage to anyone or anything.
Page 13: Maintenance
Maintenance To reduce the risk of electric shock, unplug the unit before performing any cleaning, maintenance, or troubleshooting checks. Reassemble all parts securely before operating vacuum. DO NOT operate the vacuum without the pre- motor filters and dust cup in place. DO NOT operate the vacuum with WET filters.
Page 14: Cleaning The Pre-Motor Filters
Maintenance - cont’d COMPONENT Dust Cup Pre-Motor Foam Filter Pre-Motor Felt Filter Post-Motor HEPA Filter Pre-Motor Foam Filter Felt Filter Post Motor HEPA Filter Fig. 25 CLEANING THE PRE-MOTOR FILTERS Remove the dust cup. Pull the 2 filters out from the top of the motor base.
Page 15: Cleaning The Turbo Brush
Fig. 29 Fig. 30 CLEANING THE TURBO BRUSH Slide the locking latch (a) forward and gently tilt brush housing upward to open. (Fig. 29) IMPORTANT: DO NOT force; it will not open all the way. Carefully remove any blockage or debris. Turn the turbo brush over to inspect the rotating brush and cut away any build-up of hair or string wrapped around the rotating bristle brush with...
Page 16: Checking For Blockages
Maintenance - cont’d Make sure you are working in a well lit area and use a flashlight to help search for blockages. Fig. 32 CHECKING FOR BLOCKAGES The motorized brush indicator light will illuminate red if there is a blockage or a jam. Blockages may cause your vacuum to overheat and shut down.
Page 17: Troubleshooting Guide
(See “Checking for Blockages” for instructions.) This vacuum cleaner is equipped with a motor protective thermostat. If for some reason your vacuum overheats, the thermostat will automatically turn the unit off. Should this occur, perform the following steps to restart the motor thermostat: 1.
Page 18 Notes NV350Q_26_IB_ENG_101019.indd 18 10-10-19 9:19 AM...
Page 19: Warranty
EURO-PRO FIVE-YEAR (5) LIMITED WARRANTY EURO-PRO Operating LLC warrants this product to be free from material defects and workmanship for a period of five (5) years from the date of purchase when utilized for normal household use, subject to the following conditions, exclusions and exceptions. The liability of EURO-PRO Operating LLC is limited solely to the cost of the repair or replacement of the unit at our option.
