- Page 1 www.SharkVacThenSteam.com VAC-THEN-STEAM™ MV2010 OWNER’S GUIDE MV2010_11_IB_ENG_110103.indd 1 11-01-03 1:26 PM...
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS For Household Use Only WHEN USING YOUR SHARK THEN-STEAM™, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED, INCLUDING THE FOLLOWING: WARNING: THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY READ ALL INSTRUCTIONS BEFORE USING YOUR VAC-THEN-STEAM™. DANGER OF SCALDING. - Page 3 19. Carefully remove the micro-fiber pad immediately after you have unplugged and allowed the appliance to cool. 20. When cleaning the appliance, unplug the power cord from the electrical outlet and clean with a dry or damp cloth. Do not pour water or use alcohol, benzene or paint thinner on the unit.
- Page 4 Only this method creates and delivers 212°F steam that is effective enough to clean and sanitize all your hard floor surfaces. The Shark Vac-Then-Steam™ can help you achieve a truly clean and healthy environment for you and your family.
-
Page 5: Table Of Contents
English Contents Getting Started: Assembly ...2 Getting Started: Mode Controls ...4 Vacuum Mode ...5 Steam Mode ...8 Maintaining Your Vac-Then-Steam™ ...12 Troubleshooting Guide ...14 Warranty and Registration ...15 Visit SharkVacThenSteam.com for more helpful hints and support. www.SharkVacThenSteam.com MV2010_11_IB_ENG_110103.indd 1 11-01-03 1:26 PM... -
Page 6: Product View
Getting Started: Assembly When assembling your Vac-Then-Steam™ there may be a little water in or around the water tank. This is because we quality test all our Shark products before distributing them, so you get a quality Shark Vac-Then-Steam™. ®... - Page 7 ASSEMBLY Slide the Telescopic Handle into the cleaning unit until it locks into place. Once in position, you never have to remove the handle. For your comfort, you can adjust the height of the handle. To do so pull the latch down on the handle tube 90 degrees to the open position.
-
Page 8: Getting Started: Mode Controls
Getting Started: Vacuum and Steam Panel The Vac-Then-Steam™ has two operating modes: VACUUM MODE: DO NOT USE STEAM PAD AND FRAME IN VACUUM MODE OPERATING IN VACUUM MODE: Remove steam pad and frame, if attached. See page 8 for instructions. Vacuum will not activate if steam frame is attached. -
Page 9: Vacuum Mode
Vacuum Mode After inserting the telescopic handle, your cleaning system is vacuum-ready. Begin vacuuming your hard-surface floors by tilting the cleaning unit back and pressing the vacuum power button. USING VACUUM MODE Pull and twist the quick release cord holder to unwrap the power cord completely. - Page 10 Vacuum Mode STORAGE Place your foot lightly on the top of the base. Tilt cleaning unit into the upright position. Turn OFF “O” the vacuum power button and unplug the unit. Wrap cord around cord holders and secure plug. Store cleaning unit in an upright position.
- Page 11 EMPTYING THE DUST CUP EMPTYING THE CONE FILTER EMPTYING THE DUST CUP Press the dust cup latch at the bottom of the canister upward. Pull the dust cup assembly out and down. Twist dust cup cover counter- clockwise to open. Tap canister gently over trash receptacle to empty.
-
Page 12: Stem Mode Assembly
Steam Mode ASSEMBLY Attach a steam pad onto the bottom of the steam frame, matching the hook and loop fasteners. Place the steam frame/pad assembly on the floor with the magnetic connections facing up. TOLL FREE: 1-800-798-7398 MV2010_11_IB_ENG_110103.indd 8 MAGNETIC CONNECTIONS Place the cleaning unit onto the Steam Frame. - Page 13 FILLING THE WATER TANK Keep the cleaning unit in the upright position to add water. Turn the water tank cap counter-clockwise and remove from the tank. Use the filling flask and pour water into the tank. Do not overfill. Replace the cap on the water tank by turning cap clockwise and tightening.
-
Page 14: Steam Cleaning
Steam Mode STEAM CLEANING Plug in the cleaning unit. Slide the toggle switch to expose the steam power button. Press the steam power button to the ON “I” position. The illuminated red light indicates that the “boiler” is on. Wait 30 seconds for the water to heat up and for steam to be ready. -
Page 15: Care And Storage
STORAGE Unplug and turn the unit OFF “O”. Press your foot on the steam frame. Separate steam pad from steam frame. Remove the water tank cap and empty water tank. Wrap cord securely around cord management hooks. CAUTION: Use caution when handling the steam frame. -
Page 16: Maintaining Your Vac-Then-Steam
Maintaining Your Vac-Then-Steam™ CARE OF YOUR DUST CUP FILTERS Unplug and turn OFF “O” the vacuum. Pull out the dust cup. See page 7 for instructions. Lift the filter frame out from the top of the dust cup. Remove the two filter layers from the filter frame. -
Page 17: Post-Motor Filter
POST-MOTOR FILTER Twist the Shark logo knob on the ® post-motor cover counter-clockwise to release cover. Use both hands to grip cover on both sides and pull cover toward you. Gently peel the filter off the inside of the cover. Thoroughly rinse the filter in lukewarm water. -
Page 18: Troubleshooting Guide
Troubleshooting Guide PROBLEM The Vac-Then-Steam™ will not turn on. The Vac-Then-Steam™ will not make steam. The Vac-Then-Steam™ leaves water on the floor. The Vac-Then-Steam™ is hard to push. The Vac-Then-Steam™ is not picking up dirt. Visit SharkVacThenSteam.com TOLL FREE: 1-800-798-7398 MV2010_11_IB_ENG_110103.indd 14 POSSIBLE REASONS &... -
Page 19: Warranty And Registration
English ONE (1) YEAR LIMITED WARRANTY EURO-PRO Operating LLC warrants this product to be free from defects in material and workmanship for a period of one (1) year from the date of the original purchase, when utilized for normal household use, subject to the following conditions, exclusions and exceptions. If your appliance fails to operate properly while in use under normal household conditions within the warranty period, return the complete appliance and accessories, freight prepaid. - Page 20 Euro-Pro Operating LLC Newton, MA 02459 CAN: Ville St-Laurent, QC H4S 1A7 1-800-798-7398 www.SharkVacThenSteam.com Copyright © 2011 Euro-Pro Operating LLC Printed in China Illustrations may differ from actual product. MV2010.E.110103 MV2010_11_IB_ENG_110103.indd 16 11-01-03 1:26 PM...
