- Page 1 Multimedia Projector PLV-HD10 MODEL ✽ Projection lens is optional. Owner's Manual...
-
Page 2: To The Owner
Heat build-up can reduce the service life of your projector, and can also be dangerous. G Do not put any flammable object or spray can near the projector, hot air is exhausted from the ventilation holes. G If the projector is not to be used for an extended time, unplug the projector from the power outlet. -
Page 3: Safety Instructions
Do not use attachments not recommended by the manufacturer as they may cause hazards. Do not place this projector on an unstable cart, stand, or table. The projector may fall, causing serious injury to a child or adult, and serious damage to the projector. Use only with a cart or stand recommended by the manufacturer, or sold with the projector. -
Page 4: Federal Communication Commission Notice
AC POWER CORD REQUIREMENT The AC Power Cord supplied with this projector meets the requirement for use in the country you purchased it. AC Power Cord for the United States and Canada : AC Power Cord used in the United States and Canada is listed by the Underwriters Laboratories (UL) and certified by the Canadian Standard Association (CSA). -
Page 5: Table Of Contents
TABLE OF CONTENTS FEATURES AND DESIGN PREPARATION NAME OF EACH PART OF PROJECTOR SETTING-UP PROJECTOR CONNECTING AC POWER CORD LENS INSTALLATION POSITIONING PROJECTOR LENS SHIFT ADJUSTMENT PICTURE LEVEL AND TILT ADJUSTMENT MOVING PROJECTOR CONNECTING PROJECTOR TERMINALS OF PROJECTOR CONNECTING TO COMPUTER... -
Page 6: Features And Design
This Multimedia Projector is designed with most advanced technology for portability, durability, and ease of use. This projector utilizes built-in multimedia features, a palette of 16.77 million colors, and matrix liquid crystal display (LCD) technology. Compatibility This projector widely accepts various video and computer input signals including;... -
Page 7: Preparation
PREPARATION... -
Page 8: Setting-Up Projector
NOTE ON POWER CORD AC Power Cord must meet requirement of country where you use a projector. Confirm AC plug type with chart below and proper AC power cord must be used. If supplied AC Power Cord does not match AC outlet, contact your sales dealer. -
Page 9: Lens Installation
2. For installation, refer to installation manual supplied to a Projector. When moving or setting up a projector, be sure to replace a Lens Cover to protect a surface. And be careful not to hold or subject a lens to strong forces. It may damage lens, cabinet, or mechanical parts. -
Page 10: Picture Level And Tilt Adjustment
G When carrying a projector, use a suitable carrying case. G Do not transport a projector by using a courier or transport service in an unsuitable transport case. This may cause damage to a projector. To transport a projector through a courier or transport service, consult your dealer and best case should be applied. -
Page 11: Connecting Projector
CONNECTING PROJECTOR TERMINALS OF PROJECTOR This projector applies various input/output terminals and 4 terminal slots for expansion to tune to diversity of signals from computers and video equipment. 4-built-in Terminal Slots enable you to arrange desired combinations of input sources just by changing Terminal Boards. - Page 12 CONNECTING PROJECTOR...
- Page 13 CONNECTING PROJECTOR USB PORT (Series B) RESET BUTTON This projector uses a micro processor to control unit. Occasionally, micro processor may malfunction and need to be reset. This can be done by pressing RESET button with a pen, which will shut down and restart unit.
-
Page 15: Connecting To Video Equipment
• Audio Cable (RCA x 2) ✽ • Scart Cable ✽ ✽ • DVI-VGA Adapter ✽ = Cables are not supplied with this projector.) Video Source (example) Video Equipment with Video Equipment with SDI signal output/input Digital video signal output SDI Output... -
Page 16: Before Operation
POINT buttons Selects an item or adjusts value in the On-Screen Menu. (P20) REAR INDICATORS SIDE CONTROLS POWER ON–OFF button Turns the projector on or off. (P22) ON-OFF LENS SHIFT button Select LENS SHIFT function. (P23) INPUT 1/2 INPUT 1/2 button Select input source either INPUT 1 or INPUT 2. - Page 17 READY WARNING TEMP. LAMP REPLACE READY indicator This indicator lights green when a projector is ready to be turned on. And it flashes green in Power Management mode or internal projector temperature is to high. (P37, 39) REAR INDICATORS BEFORE OPERATION...
-
Page 18: Operation Of Remote Control
BEFORE OPERATION OPERATION OF REMOTE CONTROL ▲ ▲ ▲ ▲ RESET... -
Page 19: Remote Control Code Change And Operating Range
This switching function prevents remote control interference when operating several projectors or video equipment at the same time. (Change the remote control code for the projector first before changing that for the remote control. See “Remote control” on page 37.) -
Page 20: Operating On-Screen Menu
BEFORE OPERATION OPERATING ON-SCREEN MENU HOW TO OPERATE ON-SCREEN MENU You can control and adjust this projector through ON-SCREEN MENU. Refer to following pages to operate each adjustment on ON-SCREEN MENU. 1 DISPLAY MENU Press MENU button to display ON-SCREEN MENU. -
Page 21: Menu Bar
(Refer to P30-31) IMAGE ADJUST MENU BEFORE OPERATION SETTING MENU Used to change settings of projector or reset Lamp Replace Counter. (Refer to P35-38) SOUND MENU Used to adjust sound [volume, Bass or Treble], to select Built-in SP On- Off and Sound Mute. -
Page 22: Basic Operation
Projection Lamp automatically. Refer to “Power management” on page 37. When WARNING TEMP. Indicator is flashing, projector cannot be turned on, refer to the section "MAINTENANCE" on page 39. When the both WARNING TEMP. and READY Indicator flashing, refer to the section "MAINTENANCE" on page 39. -
Page 23: Adjusting Screen
ADJUSTING SCREEN Press ZOOM L/M button on Side Control or on Remote Control Unit. Message “Zoom” is displayed. Press ZOOM L button to make image larger, and press ZOOM M button to make image smaller. Press FOCUS L/M button on Side Control or on Remote Control Unit. -
Page 24: Sound Adjustment
BASIC OPERATION DIRECT OPERATION Volume Press VOLUME (+/–) button(s) on Side Control or on Remote Control Unit to adjust volume. Volume dialog box appears on screen for a few seconds. (+) button to increase volume, and (–) button for decreasing. Mute Press MUTE button on Remote Control Unit to cut off sound. -
Page 25: Selecting Input Source
DVI (Digital Visual Interface) from being copied. The specification of HDCP is decided and controlled by Digital Content Protection, LLC. Should the specification be changed, this projector may not display the digital content protected by HDCP. -
Page 26: System Select
(Some computers need to be set manually.) The projector displays one of the Auto, -----, Mode 1 ~ Mode 20, or the system provided in the projector. When projector cannot recognize connected signal as PC... -
Page 27: Select Video System
When Video System is 1035i, 1080i/50 or 1080i/60, select system manually first. COMPONENT VIDEO SIGNAL FORMAT If projector cannot reproduce proper video image, it is necessary to select a specific component video signal format among 480i, 575i, 480p, 575p, 720p, 1035i , 1080i/50 or 1080i/60. -
Page 28: Display Adjust
DISPLAY ADJUST This projector has a picture screen resize function, which enables you to display desirable image size. Press MENU button and ON-SCREEN MENU will appear. Press POINT LEFT/RIGHT button(s) to move a red frame pointer to DISPLAY ADJUST Menu icon. -
Page 29: Auto Pc Adjustment
Store adjustment parameters. Adjustment parameters from Auto PC Adjustment can be memorized in this projector. Once parameters are memorized, setting can be done just by selecting Mode in SYSTEM SELECT Menu (P26). Refer to step 3 of MANUAL DISPLAY ADJUSTMENT section (P31). -
Page 30: Manual Display Adjustments
However, some computers and video equipments employ special signal formats which are different from standard ones and may not be tuned by Multi-Scan system of this projector. If this happens, projector cannot reproduce a proper image and image may be recognized as a flickering picture, a non-synchronized picture, a non-centered picture or a skewed picture. - Page 31 Current mode Press SELECT button to show information of computer selected. Clamp Adjusts clamp position. When image has a dark bar(s), try this adjustment. Store To store adjustment parameters, move a red frame pointer to Store icon and then press SELECT button. Move a red arrow pointer to any of Mode 1 to 20 that you want to store and then press SELECT button.
-
Page 32: Image Adjustments
Select image level Image 1 ~ Image 10 by pressing IMAGE 1 ~ IMAGE 10 buttons on Remote Control Unit. Standard (AV) Normal picture level preset on this projector for AV mode. Cinema Picture level adjusted for picture with fine tone. -
Page 33: Image Level Adjustments
IMAGE LEVEL ADJUSTMENTS Press MENU button and ON-SCREEN MENU will appear. Press POINT LEFT/RIGHT buttons to move a red frame pointer to IMAGE ADJUST Menu icon. Press POINT UP/DOWN button to move a red frame pointer to item that you want to adjust and then press SELECT button. Level of each item is displayed. - Page 34 L2 ········ Auto picture control LEVEL 2 position. Auto lamp control The projector reduce the brightness and set into the low power consumption mode. When this function is “On”, the brightness is adjusted automatically to a level that is suitable for the screen.
-
Page 35: Setting
English, German, French, Italian, Spanish, Portuguese, Dutch, Swedish, Russian, Chinese, Korean and Japanese. Lamp Mode This Projector is equipped with 4 Projection Lamps and a number of using lamps can be switched to 4 lamps or 2 lamps. Using 2 lamps maintain life of Projection Lamps. - Page 36 After making the adjustment, press a SELECT button to return to the Menu screen. Logo When this function is “On,” projector displays logo when starting up. Ceiling When this function is “On,” picture is top / bottom and left / right reversed.
- Page 37 Power management This projector is equipped with a power management function. When the input signal is interrupted and any button is not pressed for 30 seconds or more, the power management function operates in order to reduce power consumption and conserve lamp operating time.
- Page 38 SETTING Key lock This function locks the operation of the projector's control panel and the remote control. This locks operation of the projector's control panel. This locks operation of the remote control. This cancels the Key lock function. If the projector's control panel accidentally becomes locked and you do not have the remote control nearby, turn the MAIN ON/OFF switch to OFF.
-
Page 39: Appendix
If this case happenes, disconnect and reconnect the AC power cord, and then turn on the projector again to check its operation. If the projector shuts down again or fails to be turned on, the internal check and repair will be required. -
Page 40: Lamp Management
When any of 4 lamps becomes out, Lamp Mode is changed over from 4 lamps to 2 lamps. And when any of 2 lamps are out, a projector operates with 1 lamp. Lamp Mode can be switched to 4 lamps or 2 lamps manually. Refer to SETTING section on... -
Page 41: Lamp Replacement
NOTE : Do not reset LAMP REPLACEMENT COUNTER when lamp is not replaced. CAUTION : DO NOT OPERATE A PROJECTOR WHILE ANY OF LAMPS IS REMOVED. IT MAY RESULT IN MALFUNCTIONS, FIRE HAZARD, OR OTHER ACCIDENTS. NOTES ON LAMP REPLACEMENT To maintain quality of picture (better balance of color and brightness in entire screen), we recommend replacing all 4 lamps at a time. -
Page 42: Cleaning Projection Lens
Additionally, check carefully to ensure that there are no broken shards or pieces of glass around the projector or coming out from the cooling air circulation holes. Any broken shards found should be cleaned up carefully. No one should check the inside of the projector except those who are authorized trained technicians and who are familiar with projector service. -
Page 43: Troubleshooting
(When you reconnect a projector, be sure to turn a computer and monitor off before you power up a projector. Power equipment back on in order of : Projector and computer.) - Page 44 You can often correct operating problems yourself. If a projector fails to work properly, see "TROUBLESHOOT- ING" section on pages 43-44. To correct failure, try "Solutions". If after following all operating instructions, you find that service is necessary, contact Sanyo Service Station or store where you purchased unit.
-
Page 45: Indicators And Projector Condition
LAMP The projector is OFF. (The MAIN switch OFF position or the AC Power Cord is unplugged.) The projector is READY to be turned on with the POWER ON- OFF button. The projector is operating normally. The temperature inside the projector is abnormally high. The projector cannot be turned on. -
Page 46: Menu Tree
APPENDIX Input Input 1 Input 2 Input 3 System SVGA 1 SVGA 2 SVGA 3 Custom System Auto 1080i/60 1080i/50 1035i 720p 575p 480p 575i 480i Custom System 480i 575i 1035i 1080i/60 1080i/50 720p 1080p/30 1080psf/30 Custom MENU TREE SDI 1 SYSTEM SDI 2 SYSTEM... - Page 47 Image adjust Image Standard (AV) Cinema Standard (PC) Real Image 1 ~ Image 10 Quit Contrast 0 - 63 Brightness 0 - 63 Color 0 - 63 Tint 0 - 63 Color temp. XLow/Low/Mid/High 0 - 63 Green 0 - 63 Blue 0 - 63 Sharpness...
-
Page 48: Technical Specifications
APPENDIX TECHNICAL SPECIFICATIONS Projector Type Dimensions (W x H x D) Net Weight LCD Panel System Panel Resolution Number of Pixels Color System High Definition TV Signal Motorized Lens Shift Scanning Frequency Horizontal Resolution Projection Lamp Input 1 Jacks Input 2 Jacks... -
Page 49: Configurations Of Terminals
CONFIGURATIONS OF TERMINALS DVI-I TERMINAL (DIGITAL/ANALOG) This terminal accepts only Digital (TMDS) or Analog (RGB) output signal. Connect display output terminal of computer to this terminal with DVI cable (supplied). Pin Configuration C1 C2 SERIAL PORT IN/OUT TERMINAL Pin Configuration Connect serial port output terminal of computer to this terminal with Serial Cable (not supplied). -
Page 50: Compatible Computer Specifications
APPENDIX COMPATIBLE COMPUTER SPECIFICATIONS Basically this projector can accept a signal from all computers with V, H-Frequency mentioned below and less than 230 MHz of Dot Clock. ON-SCREEN RESOLUTION DISPLAY VGA 1 640 x 480 VGA 2 720 x 400... -
Page 51: Optional Parts
