- Page 1 PRODUCT INFORMATION PI−34.53 LSN − Non−Automatic Fire Detector Series 210 FMC−210−DM−G−R / FMC−210−DM−H−R FMC−210−DM−G−B / FMC−210−DM−H−B / FMC−210−DM−G−Y FMC−210−EST−G−B FMC−210−SM−G−B / FMC−210−SM−G−R BDL−F.01U.066.176 A2.en / 11.04.2007 Page ST−FIR/ PRM1 / sib...
- Page 2 BDL−F.01U.066.176 A2.en/ 11.04.2007 ST−FIR/ PRM1 / sib Page 2 of 17...
-
Page 3: Table Of Contents
Produktinformation FMC−210−DM / SM / EST LSN PI − 34.53 en Table of contents Product description ....... Features . -
Page 4: Product Description
Produktinformation FMC−210−DM / SM / EST LSN PI − 34.53 en 1. Product description The series 210 non−automatic fire detector is used for manual alarm triggering in the local security network (LSN). The Form H detectors are designed for exterior areas, the Form G detectors for interior areas. Overview of non−automatic fire detectors, series 210 Manual call points D FMC−210−DM−G−R... -
Page 5: Planning Notes
Produktinformation FMC−210−DM / SM / EST LSN PI − 34.53 en Additional LSN features The LSN non−automatic fire detector series 210 offers all the features of the improved" LSN technology: D Flexible network structures including T−taping" without additional elements. D Up to 254 LSN improved elements per loop or stub line. D Automatic or manual detector addressing can be selected via the rotary switch, in each case with or without auto detection. -
Page 6: Use In Explosive Areas
Limiting values: D Detectors may only be operated with central units whose line output is energy−limited according to EN 50021. This applies to all Bosch fire panels. D The line voltage (U ) must not exceed 33 V! D The maximum current (I... -
Page 7: Order Contents
Produktinformation FMC−210−DM / SM / EST LSN PI − 34.53 en 4. Order contents 4.1. Basic model Product ID Designation F01U011956 FMC−210−DM−G−R, Manual call point for interior areas (Form G), red F01U011958 FMC−210−DM−H−R, Manual call point for exterior areas (Form H), red F01U011959 FMC−210−DM−G−B, Manual call point for interior areas (Form G), blue... -
Page 8: Device Structure
Produktinformation FMC−210−DM / SM / EST LSN PI − 34.53 en 5. Device structure The non−automatic fire detector is available in several variants and essentially consists of the following elements. Pos. Designation Plastic housing Cable ducts (interchangeable), for cable inlet and outlet. The cable can also be ducted through openings in the rear wall of the housing. -
Page 9: Functional Description
Produktinformation FMC−210−DM / SM / EST LSN PI − 34.53 en 6. Functional description 6.1. Manual call point Manual call point and stop device: In the event of an alarm, the glass pane (2) is broken first, then the manual call point (3) is pressed hard. This activates the microswitch for alarm triggering and the indicator LED (4) flashes. -
Page 10: Installation Dimensions (View: Housing Rear Wall Interior)
Produktinformation FMC−210−DM / SM / EST LSN PI − 34.53 en 7.1. Installation dimensions (view: housing rear wall interior) 135 mm 13 mm Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î Î... -
Page 11: Installation Variants For Fire Hose Cabinets
Produktinformation FMC−210−DM / SM / EST LSN PI − 34.53 en 7.3. Installation variants for fire hose cabinets 2.5 mm 12,5 149,5 Pos. Description Installation depth version 1: min. 39 mm Installation depth version 2: 14 mm Installation depth version 3: approx. 30 mm With this version, it is not necessary to open the door of the hose box e.g. -
Page 12: Connection
Produktinformation FMC−210−DM / SM / EST LSN PI − 34.53 en 7.4. Connection − − − − LSN1 LSN2 Pos. Description Connector For execution of the external power supply +U / 0 V LSN in LSN1 LSN out LSN2 Earth connection for the cable shielding BDL−F.01U.066.176 A2.en/ 11.04.2007 ST−FIR/ PRM1 / sib... -
Page 13: Addressing
Germany; these regulations refer to the maintenance intervals as per the manufac- turer’s instructions. D Bosch ST recommends a functional and visual inspection at least once a year. D Maintenance and inspection work should be carried out regularly and by trained personnel. -
Page 14: Additional Documentation
Produktinformation FMC−210−DM / SM / EST LSN PI − 34.53 en 8.3. Additional documentation For those with the appropriate access authorisation, see Bosch ST ExtraNet at www.boschbest.de for the updated product information and the installation manual as a downloa- dable PDF file. -
Page 15: Table Of Abbreviations
Produktinformation FMC−210−DM / SM / EST LSN PI − 34.53 en 10. Table of abbreviations = Wiring diagram manual = Fire panel = Fire detector = German Institute for Standardization = Manual call point = Intrusion control panel = European standard = Danger detection system = Customer service information = Light Emitting Diode... -
Page 16: Notes
Produktinformation FMC−210−DM / SM / EST LSN PI − 34.53 en 11. Notes −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− −−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−−− BDL−F.01U.066.176 A2.en/ 11.04.2007 ST−FIR/ PRM1 / sib Page 16 of 17... - Page 17 Bosch Sicherheitssysteme GmbH Robert−Koch−Straße 100 D−85521 Ottobrunn, Germany www.bosch−sicherheitssysteme.de info.service@de.bosch.com Page 17 of 17...
