Summary of Contents for Intel AXXRSBBU3
- Page 1 ® Intel RAID Smart Battery AXXRSBBU3 Installation Guide Order Number: C95291-005...
- Page 2 No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Intel's Terms and Conditions of Sale for such products, Intel assumes no liability whatsoever, and Intel disclaims any express or implied warranty, relating to sale and/or use of Intel products including liability or warranties relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright or other intellectual property right.
- Page 3 Information rendez-vous sur le site http://support.intel.com/support/motherboards/server/sb/cs- 010770.htm. Instrucciones de seguridad importantes Lea todas las declaraciones de seguridad y precaución de este documento antes de realizar cualquiera de las instrucciones. Vea Intel Server Boards and Server Chassis Safety Information en http://support.intel.com/support/motherboards/server/sb/cs-010770.htm. Important Safety Instructions...
- Page 4 Turn off the server and disconnect telecommunications systems, networks, modems, and the power cord attached to the server before opening it. Otherwise, personal injury or equipment damage can result. ® Intel RAID Smart Battery Installation Guide...
-
Page 5: Table Of Contents
Contents ® About the Intel RAID Smart Battery ..............1 Installing the Hardware..................2 Prepare the Server........................2 ® Install the Intel RAID Smart Battery ..................2 Connect the Battery Cable ..................... 2 Connect the Clamshell to the Chassis ................3 Attach the Connecting Cable to the Server System ............ - Page 6 ® Intel RAID Smart Battery Installation Guide...
-
Page 7: About The Intel Raid Smart Battery
Integrated ® Server RAID and the SCSI RAID on Motherboard (ROMB) solutions used on particular Intel Server Platforms. The Smart Battery preserves the contents of the RAID DIMM in the event of a power failure. Once power is restored, all of the preserved data in the RAID Cache DIMM is flushed to the RAID drives. -
Page 8: Installing The Hardware
RAID (SAS): Use the 27-inch cable. ® ® Intel Server Chassis SC5400 and Intel Entry Server Chassis SC5299-E: Use the 27-inch cable. Add-in SRCSAS controllers that use the Intel RAID Smart Battery: Use the 20-inch cable. ® Intel RAID Smart Battery Installation Guide... -
Page 9: Connect The Clamshell To The Chassis
® The Intel RAID Smart Battery SXXRSBBU3 is designed for easy attachment to either an Intel pedestal or rack chassis. Follow the set of instructions below that is appropriate for your server. If you are installing this component into a third-party chassis, you will first need to install an attachment mechanism, such as industrial-grade Velcro*. - Page 10 ® ® ® Intel Server Chassis SC5400, Intel Entry Server Chassis SC5299-E, Intel Server Platforms SR4850HW4, SR6850HW4, SR4850HW4/M, and SR6850HW4/M 1. Locate the installation clips inside the chassis. They are at the left side of the chassis, near the rear.
- Page 11 ® Intel Server Platforms SR1550AL and SR2500AL 1. Clips are located on the inside floor of the chassis, at the left side, near the front of the chassis, near the power supply. 2. Align the tabs on the clamshell with the slots on the chassis.
-
Page 12: Attach The Connecting Cable To The Server System
Figure 5. Routing and Connecting the Cable inside the Chassis ® ® ® Intel Server Chassis SC5400, Intel Entry Server Chassis SC5299-E, Intel Server Platforms SR4850HW4/M and SR6850HW4/M Connect the cable to the SAS ROMB board as shown below. Note: RAM is required in the DIMM socket. AF000254 Figure 6. -
Page 13: Finish Up The Hardware
® Intel Server Platforms SR1550AL and SR2500AL Connect the cable to the midplane SAS ROMB board as shown below. AF000483 Figure 7. Routing and Connecting the Cable inside the Chassis Finish Up the Hardware 1. Reinstall any components inside of the server chassis that you needed to remove. See your server board or chassis documentation for instructions.
