AHD, CVI and TVI Passive Video
Balun Kit - 2x Transceivers and
DC12V
HDUBKITP
Quick Start Guide
Please read these instructions carefully before operating the unit
and keep for further reference. All the examples and pictures used
here are for reference only. The contents of this manual are subject
to change without notice.
Advertisement
Related Manuals for Genie HDUBKITP
Summary of Contents for Genie HDUBKITP
- Page 1 AHD, CVI and TVI Passive Video Balun Kit - 2x Transceivers and DC12V HDUBKITP Quick Start Guide Please read these instructions carefully before operating the unit and keep for further reference. All the examples and pictures used here are for reference only. The contents of this manual are subject...
-
Page 2: Specifications
AHD, CVI and TVI Passive Video Balun Kit - 2x Transceivers and DC12V The Genie HDUBKITP is a video balun that can use a single cost-effective ethernet cable to extend HD-TVI / AHD / HD-CVI / CVBS signal and power, with the transmission distance up to 300m and the resolution up to 4K (8MP). - Page 3 Quick Start Guide AHD, CVI and TVI Passive Video Balun Kit - 2x Transceivers and DC12V Dimensions 53.8mm 90mm Application HDUBKITP HDUBKITP HD DVR HD Camera DC Jack DC Plug Use high quality CAT5e UTP or CAT6 UTP cable. The max working distance is 300m for AHD, CVI camera, HD-TVI maximum distance is 250m.
- Page 4 Quick Start Guide AHD, CVI and TVI Passive Video Balun Kit - 2x Transceivers and DC12V Power Transmission Distance...
