- Page 1 INS04 TIGERFLEX® SHIPLAP PENT BIKE STORE GENERAL ASSEMBLY INSTRUCTIONS...
-
Page 2: Before You Get Started
BEFORE YOU GET STARTED PLEASE READ INSTRUCTIONS CAREFULLY • Check the pack and make sure you have all the parts listed. • When you are ready to start, make sure you have the right tools at hand (not supplied). • Ensure there is plenty of space and a clean, dry area for assembly. TIMBER As with all natural materials, timber can be affected during various weather conditions. -
Page 3: Maintenance
Please retain instructions for future reference ROOF COVERING OPTIONS All Tiger buildings are designed to use TigerFelt high grade poly-backed durable mineral roofing felt. If you have ® chosen a different roof covering option – such as EPDM rubberised roof covering or Shed Shingles, please see their separate roofing instructions available on their product pages at tigersheds.com. -
Page 4: Tools Required
BEFORE YOU GET STARTED TOOLS REQUIRED: We recommend using the following tools (not supplied): HAMMER RUBBER MALLET DRILL LADDER TAPE MEASURE SHARP KNIFE SPIRIT LEVEL SCREWDRIVER + WOOD SAW FIXING KIT GUIDE: Clout Nails CN13 (13mm Galvanised - QTY Screws (4x50mm - QTY 50) 175) BS25... - Page 5 Please retain instructions for future reference BUILDING PACK CONTENTS: For full details of what should be included please see the list that is supplied with the delivery. They are also available on request in pdf form from our helpful Customer Support team – please call 0113 2054189 for Customer Support or use the Items Delivered Query form at tigersheds.com/contact.
-
Page 6: Floor Panel Installation
TIGERFLEX SHIPLAP PENT BIKE STORE ASSEMBLY GUIDE ® Step 1: FLOOR PANEL INSTALLATION • Install Heavy Duty Bearers as shown • Check your product floor size for the correct diagram (opposite page) Please ensure floor panels are butted up tightly with no gaps (S90) •... - Page 7 Please retain instructions for future reference SINGLE FLOOR 6x3*, 6x4* FLOOR PANEL DOUBLE FLOOR 6x5*, 6x6* DOUBLE FLOOR 8x3*, 8x4* FLOOR PANEL FLOOR PANELS FLOOR PANEL MULTI FLOOR MULTI FLOOR 8x5* Only 8x6* Only FLOOR PANELS FLOOR PANELS...
-
Page 8: Side Panel Installation
TIGERFLEX SHIPLAP PENT BIKE STORE ASSEMBLY GUIDE ® Step 2: SIDE PANEL INSTALLATION (Detail A) Make sure transport blocks have been removed. NOTE - Hammer off sideways. Do not prise off. • Secure blank back & blank side panel to each other in corners using 3x 50mm (S50) screws per joint. - Page 9 Please retain instructions for future reference SIDE PANEL SIDE PANEL SIDE PANEL FLOOR PANEL SIDE PANEL FLOOR JOIST SIDE PANEL FLOOR PANEL SIDE PANEL...
- Page 10 TIGERFLEX SHIPLAP PENT BIKE STORE ASSEMBLY GUIDE ® Step 3: DOOR SIDE PANEL INSTALLATION • Assemble door side panel as shown. (Before affixing to the shed). (S50) (Detail F) • Screw door header to the left and right hand sides as shown using 50mm screws.
-
Page 11: Door Installation
Please retain instructions for future reference Step 4: BS25 2TBB DOOR INSTALLATION • Lay assembled door side panel on a flat surface • Place doors into opening. (Detail H) • Leave approx. 4mm gap at side between door and side panel. •... - Page 12 TIGERFLEX SHIPLAP PENT BIKE STORE ASSEMBLY GUIDE ® Step 5: COMPLETED DOOR SIDE PANEL INSTALLATION • Secure completed door side panel to existing built structure as shown.. (S50) (Detail L) • Secure in corners using 3x 50mm screws provided per joint.
- Page 13 Please retain instructions for future reference Step 6: PENT GABLE TOP INSTALLATION • Fix Pent Gable Tops to the existing built structure. • The bottom of the gable top will slot into the top of the cladding on the panel below. Please ensure the gable top is positioned centrally above the side panels before screwing in place.
- Page 14 TIGERFLEX SHIPLAP PENT BIKE STORE ASSEMBLY GUIDE ® Step 6: PENT ROOF PANEL INSTALLATION • Attach roof panels as shown. Rest Pent roof panel on the High Side Top and side panel on the opposite side. (Detail R1 & R2) •...
- Page 15 Please retain instructions for future reference Step 9: BARGE BOARD & FINIAL INSTALLATION • Fit Barge Boards to the roof, trapping overhanging end of the felt in between to create a weatherproof seal. (N40) • Secure together using 3x 40mm nails per Barge Board.
- Page 16 INS04 Display Agent Woodlands DIY Store Station Yard, Horsforth, Leeds, LS18 5NZ Telephone: 0113 205 4189 Website: tigersheds.com Email: customersupport@tigersheds.com...
