Icom IC-A210 Service Manual page 40

SECTION 6
[CHASSIS PARTS]
REF ORDER
NO. NO.
W1 8900016940 OPC-1820
W2 8900016950 OPC-1737
W3 8900016960 OPC-1738
W4 8900016970 OPC-1739
W5 8900016980 OPC-1740
W6 8900016990 OPC-1741
W7 8900017000 OPC-1743
W8 8900017010 OPC-1744
W9 8900017021 OPC-1745A
MP1 8010020770 2974 CHASSIS
MP2 8110009140 2974 T-COVER
MP3 8930072790 2974 STOPPER PLATE
MP4 8110009150 2974 B-COVER
MP5 8510018420 2974 SHIELD COVER
MP6 8210023930 2974 FRONT PANEL (Incl. MP7, MP8)
MP7 8930072770 2974 V-LENS
MP8 8930072780 2974 E-LENS
MP9 8310069720 2974 WINDOW PLATE
8310069720 2974 WINDOW PLATE
MP10 8930072860 2974 WINDOW SHEET
MP11 8610013150 Knob K-264
MP12 8610013160 Knob K-265
MP13 8610013170 Knob K-265 (A)
MP14 8610013180 Knob K-266
MP15 8610013190 Knob K-266 (A)
MP16 8610013200 Knob N-356
MP17 8610013210 Knob N-357
MP18 8610013220 Knob N-358
MP19 8930072830 2974 A-SPONGE
MP20 8930072840 2974 B-SPONGE
MP21 8930073160 2974 S-LENS
MP22 8820001450 2974 CAP SCREW
MP23 8930073260 Shield sponge (CD)
MP24 8930073270 2974 INSULATION SHEET
MP25 8930073480 2974 CLIP
MP26 8930022572 867 STOPPER-2
MP27 8820000691 867 CUP SCREW-1
MP28 8930024080 867 SPRING
MP29 8860000740 Spring pin M1.2X6 SUS
MP30 8850000690 Flat washer M3 SUS 3X7X0.5
MP31 8810002950 Screw BiH M3X6 SUS
MP32 8810003131 Setscrew (A) 2.6X6 ZC3
MP33 8810010151 Screw BT B0 2X10 SUS SSBC
MP34 8830001470 VR nut (N)
MP35 8810006300 Setscrew (C) 3X8 SUS
MP36 8810003520 Hex stop screw M3X3 ZK
MP37 8930069430 Insulation sheet (LM)
MP38 8930027730 Sponge (DC)
MP39 8930057730 Shield sponge (J)
MP43 8950000180 Cable tie -80
[MAIN UNIT]
REF ORDER
NO. NO.
RL1* 6330001730 AHY107
CP1* 6910009670 HK3-S-T
J1 6510011591 B2P-VH (LF) (SN)
J3 6510007020 TMP-J01X-V6
J7* 6510026100 22FLT-SM2-TB (LF) (SN)
J8 6510018450 TMP-S01X-B1
J9* 6510018941 B13B-PH-SM4-TB (LF) (SN)
J10 6510021071 S2P-VH (LF) (SN)
J11* 6510022311 B5B-PH-SM4-TB (LF) (SN)
S1* 2260003060 NANOSMDC016F
T4 5920000751 ST-82 (P)FL
MP1* 8510018070 2979 VCO case
MP2* 8510017600 OG-363050
MP3* 8510017600 OG-363050
MP5* 8510017600 OG-363050
MP6* 8510017600 OG-363050
MP7* 8510017600 OG-363050
*: Refer to SECTION 9 "BOARD LAYOUTS."
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
All manuals and user guides at all-guides.com
MECHANICAL PARTS
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
[USA-01] 1
[EXP-01] 1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
2
2
2
2
4
27
2
4
1
16
4
1
1
3
4
DESCRIPTION QTY.
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
6 - 1
[FRONT UNIT]
REF ORDER
NO. NO.
DS11 5060000020 UEL127
S1 2250000580 EC11EAB24C
S2* 2230001200 LS35J2-T
S3* 2230001200 LS35J2-T
S4* 2230001200 LS35J2-T
S5* 2230001200 LS35J2-T
S6* 2230001200 LS35J2-T
[K-CONNECT UNIT]
REF ORDER
NO. NO.
J4* 6510018941 B13B-PH-SM4-TB (LF) (SN)
J6 6510017150 TMP-S01X-C1
J7* 6510024680 HSJ1636-011020
F1* 5210001070 0451008.MRL
[PA UNIT]
REF ORDER
NO. NO.
J500* 6510011591 B2P-VH (LF) (SN)
J501 6510017150 TMP-S01X-C1
J502* 6510022311 B5B-PH-SM4-TB (LF) (SN)
J503 6510017150 TMP-S01X-C1
J504 6510017150 TMP-S01X-C1
MP1 8510012910 2270 RUG
MP3* 6910014760 OG-503040
[VOLUME UNIT]
REF ORDER
NO. NO.
R1 7210003270 TP76N00NA-26F-10KB-2974
J1* 6510026160 06FLZ-SM2-TB (LF) (SN)
[ACCESSORIES]
REF ORDER
NO. NO.
J8001 6510026350 2974BNC-LP
P8001 6510013840 4338-15
P8002 6510014430 DS-6532
EP8001 6510013850 4366-GL
EP8002 0880002520 MB-113
MP8001 8010011621 867 BRACKET-1
MP8002 8310023870 867 O.P. LABEL
MP8003 8310023880 867 O.P. LABEL (A)
MP8004 8830000730 Self-clinching nylon Nut TPLC-440
MP8005 8850001210 ICOM washer (V)
MP8006 8860000720 C-ring S 11 SUS
MP8007 8810007080 Screw BiH UNC NO.6X12.7 SUS
MP8008 8830000740 Nut UNC NO.6 SUS
MP8009 8950002550 Nylon clip SL-9N
MP8010 8830000750 Nylon Nut UNC NO.6 SUS
MP8011 8810007070 Screw BiH UNC NO.4X12.7 SUS
MP8012 8810007060 Screw UNC NO.6X12.7 SUS
MP8013 8830000761 Clip nut UNC NO.6-1
MP8014 8830000771 Speed nut U-TYPE UNC NO.6 ZC3
MP8015 8930022970 867 pin
DESCRIPTION QTY.
1
1
1
1
1
1
1
DESCRIPTION QTY.
1
1
1
1
DESCRIPTION QTY.
1
1
1
1
1
1
1
DESCRIPTION QTY.
1
1
DESCRIPTION QTY.
1
1
1
30
1
1
1
1
2
1
1
1
1
1
1
2
6
6
4
2
