Optoma ThemeScene H77 User Manual
Optoma technology projector user's manual
Hide thumbs
Also See for Optoma ThemeScene H77:
- Service manual (67 pages) ,
- Protocol function list (3 pages) ,
- Datasheet (1 page)
Table of Contents
Advertisement
Quick Links
Download this manual
See also:
Service Manual
Precautions ...................................................................................................................... 2
Product Features ............................................................................................................. 4
Package Overview ........................................................................................................... 5
Product Overview ........................................................................................................... 6
Main Unit .................................................................................................................. 6
Control Panel ............................................................................................................. 7
Connection Ports ....................................................................................................... 8
Wireless Remote Control ........................................................................................... 9
Connecting the Projector ................................................................................................ 10
Powering On/Off the Projector ....................................................................................... 11
Powering On the Projector ....................................................................................... 11
Powering Off the Projector ........................................................................................ 12
Adjusting the Projected Image ........................................................................................ 13
Adjusting the Projector's Height .............................................................................. 13
Adjusting the Projector's Zoom/Focus ..................................................................... 14
Onscreen Display Menus .............................................................................................. 18
How to Operate ......................................................................................................... 18
Menu Tree ................................................................................................................. 19
Picture ....................................................................................................................... 20
Image ......................................................................................................................... 22
System ....................................................................................................................... 24
Display ....................................................................................................................... 25
Troubleshooting ............................................................................................................... 27
Replacing the Lamp ......................................................................................................... 30
Ceiling Mount Installation .............................................................................................. 31
Table of Contents
1
Advertisement
Table of Contents
Related Manuals for Optoma Optoma ThemeScene H77
Summary of Contents for Optoma Optoma ThemeScene H77
-
Page 1: Table Of Contents
Connection Ports ... 8 Wireless Remote Control ... 9 Installation Connecting the Projector ... 10 Powering On/Off the Projector ... 11 Powering On the Projector ... 11 Powering Off the Projector ... 12 Adjusting the Projected Image ... 13 Adjusting the Projector’s Height ... 13 Adjusting the Projector’s Zoom/Focus ... -
Page 2: Usage Notice
Warning- After installing a new lamp, reset the lamp life using Warning- Before turning off the product, follow the cooling fan Warning- Turn on the projector first and then select the signal Warning- Do not use lens cap when projector is in operation. - Page 3 Turn off the product before cleaning. Use a soft cloth moistened with mild detergent to clean the display housing. Disconnect the power plug from AC outlet if the product is not being used for a long period of time. Do not: Block the slots and openings on the unit provided for ventilation.
-
Page 4: Introduction
Introduction Product Features This product is a WXGA single chip 0.79-inch DLP projector featuring: True WXGA resolution 1280 x 720 addressable pixels Single chip DLP technology Power zoom and focus HDTV compatible (480i/p, 576i/p, 720p, 1080i ) NTSC/PAL/SECAM, and HDTV compatible... -
Page 5: Package Overview
Package Overview This projector comes with all the items shown below. Check to make sure your unit is complete. Projector Unit Composite Video Cable 1.8m User’s Manual/ Warranty Card Due to the differ- ence in applications for each country, some regions may have different accessories. -
Page 6: Product Overview
Introduction Product Overview Main Unit 1. Control Panel 2. Power Socket & Main Power Switch 3. Four Adjustable Feet 4. Lens 5. Lens Cap 6. Connection Ports... -
Page 7: Control Panel
Control Panel 1. Lens Shift (Up/Down) 2. Optics Zoom In/Up 3. Optics Zoom Out/Down 4. Optics Focus -/Left 5. Optics Focus+/Right 6. Four Directional Select Keys 7. Resync 8. Source 9. Menu/Exit 10. Enter Introduction... -
Page 8: Connection Ports
Introduction Connection Ports 2. Temp LED 3. Power LED 4. Power Socket 5. Main Power Switch 6. IR Receiver 7. RCA YPbPr Connectors 8. BNC YPbPr/RGBHV 9. +12V Relay Connectors 10. RS-232 Connector 11. S-Video Input Connector 12. Composite Video Input 13. -
Page 9: Wireless Remote Control
Wireless Remote Control 1. Power On/Off 2. Display Hide 3. Brightness 4. Freeze 5. Contrast 6. Re-sync 7. Hue Adjustment 8. Electronic Zoom 9. Keystone Adjustment 10. Format 11. Menu/Exit 12. Optics Zoom In/Up Introduction 13. Optics Zoom Out/Down 14. Optics Focus +/Left 15. -
Page 10: Installation
(Optional) Antenna +12V Relay Outputs To ensure that the projector properly displays source material from your computer, please configure the display settings of your graphics card to less than or equal to 1280 x 720 resolution. Be sure that the timing of the display setting is compatible with the projector. -
Page 11: Powering On/Off The Projector
The startup screen will display in approximately one minute. 4. Turn on your source (computer, notebook, video player etc), the projector will automatically detect your source. If the screen displays “No Signal,” make sure the signal cables are securely connected. -
Page 12: Powering Off The Projector
After the “Power” indicator stops flashing, you may then turn off the main power switch on the side of the projector. If you want to turn on the projector, you must press “Power” within 90 seconds of when the “Power”... -
Page 13: Adjusting The Projected Image
2. Rotate the adjustable foot counterclockwise to raise the projector or clockwise to lower it. Repeat with the remain- ing feet as needed. 3. Reset the projector on its feet and re-adjust as needed. Four Adjustable feet Installation... -
Page 14: Adjusting The Projector's Zoom/Focus
Installation Adjusting the Projector’s Zoom/Focus You may adjust the projected image size by pressing the Zoom buttons. Press to zoom in or to zoom out. To adjust focus of an image, press the focus shift buttons . The projector will focus at distances from 3.3 to 32.8 feet (1.0 to 10.0m). -
Page 15: User Controls
Using the Remote Control Power “Power” turns on the projector’s lamp, refer to the “Powering On/Off the Projector” section on page 11~ 12 for more details. Hide “Hide” immediately turns the screen black. Press “Hide” a second time to restore the display. - Page 16 “Hue” adjusts the color balance from red to green. H.Keystone & V.Keystone Correct image distortion caused by rotating and tilting the projector. Re-Sync Automatically synchronizes the projector to the input source. Zoom Press “Zoom” to display the zoom menu. Press Format Display the “Format”...
- Page 17 Using the Control Panel Power The power switch is located near the power socket on the side of the projector. Use it to power on/off the projector. Please refer to the “Powering On/Off the Projector” section on pages 11~ 12.
-
Page 18: Onscreen Display Menus
User Controls Onscreen Display Menus How to Operate The projector has multilingual onscreen display menus that allow you to make image adjustments and change a variety of settings. The projector automatically detects the source. To launch the menu, press “Menu/Exit” on the Remote Control or Control Panel. -
Page 19: Menu Tree
Menu Tree PICTURE... Mode Contrast Brightness Color (Video only) Hue (Video only) Sharpness Gamma Reset White Peaking IMAGE... Color Temp Image Mode Advanced Adjustment Signal Reset SYSTEM... Language Bulb Source Lock Auto Shutdown Blanking Eco Mode Color Space DISPLAY... Projection Format Vertical Shift H.Keystone... -
Page 20: Picture
User Controls Picture Mode Contrast Brightness Color Sharpness Gamma Reset Mode There are three factory presets optimized for various types of pictures: Cinema, Normal, and Vivid. You can customize contrast, brightness, intensity, color, tint, sharpness, and gamma for each preset mode. Contrast Contrast controls the degree of difference between the lightest and darkest parts of the picture. - Page 21 Picture Mode Contrast Brightness Color Sharpness Gamma Reset Gamma Gamma affects how dark scenery is displayed. With a greater gamma value, dark scenery will appear brighter. Use adjust gamma values. Reset Return the adjustments and settings to factory default values. Current: Returns the current menu’s settings to factory default values.
-
Page 22: Image
User Controls Image White Peaking Color Temp. Image Mode Advanced Adjustment Signal Reset White Peaking Use the white peaking control to set the white peaking level of the DMD chip. “0” stands for minimal peaking, and “10” stands for maximum peaking. If you prefer a stronger image, adjust toward the maximum setting. - Page 23 Image White Peaking Color Temp. Image Mode Advanced Adjustment Signal Reset Reset Return the adjustments and settings to factory default values. Current: Return the current menu’s settings to factory default values. All: Return all menu settings to factory default values. User Controls Film IMAGE...
-
Page 24: System
Eco Mode This is also known as “Economy Mode.” Selecting “On” decreases the fan noise from the projector as well as enhancing the black level and reducing the brightness. You may find this is the best mode for watching movies. -
Page 25: Display
Digital zoom Projection The factory default setting. When you select this function, the projector reverses the image so you can project from behind a translucent screen. When you select this function, the projector turns the image upside down for ceiling-mounted projection. -
Page 26: Digital Zoom
Front Desktop DISPLAY Native: Original image size. 16:9: The standard widescreen display format of the projector. Letterbox: Letterbox mode zooms a letterboxed image intended for 4:3 display to full screen wide. Original Input Window: When a 4:3 image is bigger than a 16:9 screen, select the “Window”... -
Page 27: Appendices
Verify that your display resolution setting is less than or equal to 1280 x 720. If the projector is still not projecting the image, you may need to adjust your monitor display setting. To do this, please refer to the following instructions. - Page 28 Make sure the transparent lens cap is removed. Make sure the projection screen is between the required distance 3.3 to 32.8 feet (1.0 to 10.0 meters) from the projector. types” under the SP box; choose the resolution mode you need under the “Models”...
- Page 29 Problem: Lamp burns out or makes a popping sound When the lamp reaches its end of life, it will burn out and may make a loud popping sound. If this happens, the projector will not turn on until the lamp module has been replaced. To replace the lamp, follow the procedures in the “Replacing the Lamp”section on...
-
Page 30: Replacing The Lamp
The projector displays a warning message “Lamp may fail soon ! Replacement Suggested !” When you see this message, please contact your local reseller or service center. Make sure the projector has cooled down for at least 30 minutes before changing the lamp. Warning:... -
Page 31: Ceiling Mount Installation
1. To prevent damaging your projector, please use the ceiling mount package for installation. 2. If you wish to use a third party ceiling mount kit please ensure the screws used to attached a mount to the projector met the following specifications: Please note that...
