CONNECTING USB DEVICES

– Logi Dock has 5 USB ports: 2 USB-A
and 2 USB-C ports on the back panel;
1 USB-C port on the side
– Simply connect your external USB devices
such as a keyboard and mice with the USB-A
or C ports
Note: Please charge your iOS device via USB-A
or C ports with charging port icon ( ) only when
the Logi Dock is disconnected from the laptop

CONNECTING BLUETOOTH

MOBILE DEVICES
1 Press the Bluetooth pairing button at the back
®
panel for 3 seconds The ambient light in front
will blink blue
2 Open Bluetooth settings on your mobile
®
device
3 Select Logi Dock in discoverable devices
4 Once successfully paired, the ambient light will
turn solid blue for 5 seconds with sonification
CONNECTING A DISPLAYPORT DEVICE
To connect your DisplayPort video device
(such as monitor, projector) to Logi Dock,
insert the DisplayPort cable* to DisplayPort
on the back panel
* DisplayPort cable is not included
CONNECTING A HDMI DEVICE
To connect your HDMI video device
(such as monitor, projector) to Logi Dock,
insert the HDMI cable* to HDMI port
on the back panel
* HDMI cable is not included
-ENABLED
®
USB-C USB-A USB-A
USB-C
3 sec.
USB-C USB-A USB-A
USB-C DISPLAYPORT HDMI USB-C POWER
DISPLAYPORT
HDMI
USB-C
Logi Dock
10 English
