Summary of Contents for Nextar MA177
- Page 1 MA177...
-
Page 2: Table Of Contents
Connecting the player to computer...6 Loading files to the player...6 Disconnecting the USB cable ...8 Charging the battery...9 Using the MP3 Player...10 Turning on ...10 Adjusting the volume ...10 Pausing and playing music tracks ...10 Skipping to the next/previous music track...10 Searching forward/backward within a track ... - Page 3 Listening Cautions ... 15 Precautions... 16 FCC Caution... 17 FCC Compliance... 17...
-
Page 4: Introduction
Introduction Congratulations on purchasing the MP3 Player. Before using the player, read this manual thoroughly and keep it for future reference. This manual will help you use all of the existing features to make your player view more enjoyable. This manual contains important safety information and correct operation instructions. Read the manual carefully before you use the player in order to avoid any confusion or damage. -
Page 5: Important Safety Precautions
Important Safety Precautions Always follow these basic safety precautions when using your player. This will reduce the risk of product damage and personal injury. Do not disassemble, repair or modify the player by yourself. Refer servicing to qualified personnel. Do not dispose of the player in fire to avoid explosion because the player has built-in battery. Do not touch the player with bare hands if the built-in battery is leaking. -
Page 6: Features
Features Compact and stylish design Built-in rechargeable Li-polymer battery USB 2.0 high speed transmission LED indication Supports playback of MP3, WMA music files Six preset equalizers (Normal, Pop, Rock, Classic, Jazz, Bass) to suit the type of audio output... -
Page 7: Location Of Controls
Location of Controls Earphone Jack Connect with the supplied earphone. Press to increase the volume; Press and hold to switch between EQ modes. Press to select the previous track; Press and hold to fast search forward; Press to start or pause playback; Press and hold to turn on or turn off the player. -
Page 8: Connecting With The Computer
Connecting with the Computer System requirements You computer system must meet the following specifications: - Microsoft Windows 98/SE or later version Intel Pentium II 200MHz or AMD K6 or above 128 MB RAM - Mac OSX V9.2 or later version Power PC G4 800MHz or above 256 MB RAM - Linux OS Kernel V2.4.0 or later version... -
Page 9: Installing The Driver For Windows 98 Se
The computer system detects “New hardware” and starts to install the driver automatically. Wait for the system to finish the installation. When it has finished, a new “Removable Disk” will be created in “My Computer”. Loading files to the player To download the files from your computer, perform the following steps: www.nextar.com before connecting... - Page 10 “Removable Disk” is displayed. Select the files on your computer and simply move it into the “Removable Disk” in the usual way (drag-and-drop, copy-and-paste). After copying is completed, the data will be available on the MP3 player. Note: Please do not disconnect the USB cable during loading. It may cause malfunction of the player and the files.
-
Page 11: Disconnecting The Usb Cable
Disconnecting the USB cable After completing the file transfer, please disconnect the USB cable as the following way: Double click the green arrow “Safety Remove Hardware” in the taskbar on the bottom right of the window. Select “USB Device” and click “Stop”. When the “Stop a Hardware device”... -
Page 12: Charging The Battery
Charging the battery The battery of the player is charging automatically when the player is connected to the computer. Make sure the computer is turned on. The battery of the player is 80-percent charged in about three hours and fully charged in about five hours. If you charge the player while loading files to the player, it might take longer. -
Page 13: Using The Mp3 Player
To turn on the player, press and hold the [G] button. The indicator will illuminate and then flash. After a short pause the first music track on the MP3 Player starts playing automatically (File stored in the root directory are played first followed by any files stored in folders). The indicator will flash slowly during playback. -
Page 14: Searching Forward/Backward Within A Track
Locking all buttons The lock function disables all of the buttons on the MP3 player. This prevents you from inadvertently pressing the buttons while using the MP3 player on the move. To enable the lock function, press and hold the [ To disable the lock function, press and hold [ ] button. -
Page 15: Turning Off
Turning off To turn off the MP3 player at any time, press and hold the [G] button for 2 seconds. Once the pressed button is released, the indicator and MP3 player will turn off. Note: When the MP3 player is turned on again, it will continue playing the track that was playing when the MP3 player was turned off. -
Page 16: Troubleshooting
Troubleshooting If you have problems in operating your player, please check the points below before sending it to service center. Cannot power on The battery may be exhausted. Please recharge the battery. Files cannot be downloaded Check if the driver is installed correctly in the computer. Check the connection between the player and PC. -
Page 17: Specifications
Specifications Audio Format MP3/WMA Weight About 25g (without accessories) MP3 bit Rate 8Kbps–320Kbps WMA bit rate 32Kbps–384Kbps S/N rate ≥91dB Dynamic range ≥80dB Distortion <0.05% Battery Music playback about 12 hours Normal//Rock/Pop/Classic/Jazz/Bass Size 43*34.2*14 mm Frequency response 20Hz~20KHz Dynamic current ≤18mA Power off current ≤0.3mA... -
Page 18: Listening Cautions
Listening Cautions Do not play your headphones or earphones at a high volume. Hearing experts advise against continuous extended play. If you experience a ringing in your ears, reduce volume or discontinue use. Do not use while operating a motorized vehicle. It may create a traffic hazard and is illegal in many areas. You should use extreme caution or temporarily discontinue use in potentially hazardous situations. -
Page 19: Precautions
Precautions When not using the player for an extended period of time, please charge the battery at least once per month to extend the battery life. Do not use the player in extremely hot, cold, dusty or damp environments. Make sure the keys are unlocked before using the player (otherwise controls will not function). Avoid dropping or striking the unit .This may cause external and internal physical damage to the player. -
Page 20: Fcc Caution
FCC Caution This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 21 device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This product may receive radio interference caused by mobile telephones or other products during operation. If such interference is apparent, please increase separation between the product and the mobile telephone or other product. This product may receive radio interference caused by mobile telephones or other products during operation.
- Page 22 Nextar may find it necessary to modify, amend or otherwise change or update this manual. We reserve the right to do this at any time, without any prior notice. All specifications and features are subject to change without notice. All screen shots shown are simulated and may not represent the actual screen on production units sold to consumers.
- Page 23 We are seriously concerned about environmental protection, and we hope that you share our concern as well. For more information regarding our recycling program, please visit us at http://www.nextar.com/green or call us at 1-888-849-0846...
