- Page 1 Operation & Installation Manual AIR-To-WATER HEAT PUMP INDOOR UNIT HU062WAMNA HU102WAMNA No. 0150554179 • Please read this manual carefully before using. • Keep this operation manual for future reference. Original instructions...
-
Page 2: Table Of Contents
Contents Safety ....................................1 Indoor Floor Area Requirements ............................3 Accessories ..................................7 Installation Instructions ..............................8 Electric wiring and the application ........................... 14 Operation instructions for controller..........................19 Move and scrap the air conditioning ..........................39... -
Page 3: Safety
• Do not expose the appliance to heat, flame, sparks. or other sources of ignition. Else, it may explode and cause injury or death. • Use only Haier accessories and components with this equipment. Failure to use unapproved or 3rd party accessories could result in damage, electrical shock or fire. - Page 4 Safety • Make sure that drainage piping is installed properly according to this instruction, preventing the water entering the room and cause damage to properties. • Take use of the attached accessories parts and specified parts for installation. Otherwise, it will cause the drop of unit, water leakage, fire or electrical shock.
-
Page 5: Indoor Floor Area Requirements
Indoor Floor Area Requirements Indoor floor area requirement • If the total refrigerant charge in the system is <1.84 kg, there is no additional minimum floor area is required. • If the total refrigerant charge in the system is ≥1.84 kg, additional minimum floor area complies requirements described as below: Symbol Description... - Page 6 Indoor Floor Area Requirements Table Ⅰ – Maximum refrigerant charge allowed in a room Maximum refrigerant charge in a room / mmax (kg) Aroom (m2) H=1.15m H=1.20m H=1.30m H=1.40m H=1.50m H=1.60m H=1.70m H=1.80m 0.265 0.276 0.299 0.322 0.345 0.368 0.391 0.414 0.530 0.553...
- Page 7 Indoor Floor Area Requirements Table Ⅱ – Minimum floor area Minimum floor area/ Amin total (m mc (kg) H=1.15m H=1.20m H=1.30m H=1.40m H=1.50m H=1.60m H=1.70m H=1.80m 1.84 7.84 7.20 6.15 5.71 5.33 4.99 4.70 4.44 1.86 8.02 7.36 6.27 5.77 5.39 5.05 4.75...
- Page 8 Indoor Floor Area Requirements Table Ⅲ Minimum venting opening area for natural ventilation Minimum venting opening area (VAmin) (cm mmax mexcess (kg) mc (kg) (kg) = mc - mmax 1.15m 1.20m 1.30m 1.40m 1.50m 1.60m 1.70m 1.80m 2.27 2.17 2.27 1.97 2.27 1.77...
-
Page 9: Accessories
Accessories Attached Accessories Accessories part Qty. Remarks Place position Installation plate I Fixed on wooden base Installation plate II Fixed on wooden base Installation manual Accesory bag Reducing pipe Only for HU062WAMNA Accesory bag... -
Page 10: Installation Instructions
Installation Instructions Dimension Diagram Front View Side View Bottom View... - Page 11 • Expansion tank should be overhauled once a year, Please replace and update in time if necessary. • When the water capacity of the water system is more than 180L, an additional expansion tank is required. Pipe Position Diagram Connection Size (in./mm) No. Pipe Description HU062WAMNA HU102WAMNA Refrigerant liquid 1/4(6.35) 3/8(9.52) ①...
- Page 12 Installation Instructions A. Select the Best Installation Location The unit must be installed indoors, and the requirements are as follows. • The indoor unit must be installed on a vertical wall. • The mounting wall must be even and nonflammable, it must be strong and solid enough to hold the unit and prevent it from vibration.
- Page 13 Installation Instructions C. Indoor Unit Installation • Secure the installation plate Ⅱ to the bottom of the unit with 3 screws. • Lift up the unit and hang the slots behind of the unit on the hook of the installation plate Ⅰ. •...
- Page 14 Installation Instructions D. Water Piping Installation Simple 2 zone (Floor heating + Radiator) Indoor Radiator Thermistor 1 Outdoor Mixing valve Thermistor 2 Pump Floor Heating 1 • Make sure the water piping is connected complying the European regulations. • Cover the pipe end to prevent dust entering the water piping when inserting it through a hole in the wall. •...
- Page 15 Installation Instructions E. Refrigerant Piping Installation • Please make flare after inserting flare nut (located at joint portion of Always use a backup wrench when tube assembly) onto the copper pipe. (in case of using long piping) tightening and loosening flare nuts. Tubing •...
-
Page 16: Electric Wiring And The Application
Sectional area of Rated current of Leakage current / action current of Model source power line (mm²) circuit breaker (A) leakage protector (mA) 1PH, 220-240V~, HU062WAMNA 32A 30MA less than 0.1S 50HZ 1PH, 220-240V~, HU102WAMNA 32A 30MA less than 0.1S 50HZ... - Page 17 Electric wiring and the application • Earth resistance should meet the national standard requirement. • The yellow and green double color line of air conditioning unit is ground wire, do not move, splice or use it for any other purpose. Unit ground terminal cannot be connected with a self-tapping screw or risk electric shock. •...
- Page 18 Electric wiring and the application • The outdoor unit and indoor unit require independent power distribution. • The power supply terminal block for outdoor unit AW042SSCHA & AW062SSCHA is marked as 1, 2 and 3, which correspond to live line, neutral line and earth line respectively. For indoor unit and outdoor unit AW082SNCHA & AW102SNCHA, the live line, neutral line and earth line is marked as L, N and G.
- Page 19 Electric wiring and the application Failure code Indoor unit failure code Code Error code definition Notes in water temp.sensor(Twi)failure Restorable out water temp.sensor(Two)failure Restorable in refrigerant temp.sensor(Thi)failure Restorable out refrigerant temp.sensor(Tho)failure Restorable EEPROM failure Unrecoverable Communication failure with outdoor unit Restorable communication failure with wired controller Restorable...
- Page 20 Electric wiring and the application Definition of indoor unit dial switch • Please turn off the power supply before opening the cover of the electric cabinet and changing the dial code. • The capacity setting of indoor and outdoor unit must be matched, for example, the outdoor unit model is AW042SSCHA, then the indoor unit capacity must be set according to 042 in the list.
-
Page 21: Operation Instructions For Controller
Operation instructions for controller Part information for controller Restart button ① : Hold Restart button for 10s to restart controller. Check whether the controller software is normal. Display / Touch area Restart button ② : Press to restart controller. Check whether the controller chip is normal. Hanger hole Hanger hole Power: 12V DC... - Page 22 Operation instructions for controller Power supply (12V, GND): 12V DC, please pay attention to “+, -” of power supply. Fire alarm linkage contact (ALARM1, ALARM2): Short circuit the ALARM1 and ALARM2 (Reserved port). Third party interface (B1, A1): A1 — 485+, B1—485-(Reserved port). Communication port (B2, A2): It is used for connecting converter, please pay attention to “+, -”, A2—485+, B2—485-.
- Page 23 Operation instructions for controller The hanging plate is placed in the direction of the illustration, where A/B is the location of the 86 cassette screws, and the C/D is the position of the 120 cassette screws. The pendant is fixed to the hole of the pendant, please pay attention to the UP direction.
- Page 24 Operation instructions for controller Notes: 1. B1 and A1 are unavailable. 2. B2 and A2 for 485 interface, access to split unit's 485 B and A, paying attention to line order. 3. ARALM1 and ALARM2 factory default is connected, if not be connected, then the main interface of the controller will display alarm information, and all indoor units will be turned off.
- Page 25 Operation instructions for controller Function operation Main interface display Picture 1 This controller can control all parts temperature of the split system, including Zone1, Zone2, DHW (Domestic Hot Water), and Pool. During installation, Zone1, Zone2, DHW, and Pool can be set to ON or OFF. Note: If one Zone in the system, set Zone 1 on;...
- Page 26 Operation instructions for controller Main interface When search is completed, the main interface will show as below. Picture 3 is the example. The interface display is subject to the "Equipment Installation" function in installation settings. MAIN/SUN Controller Time Mode Zone2 Zone1 Pool Menu...
- Page 27 Operation instructions for controller Note: During heating operation of the unit, the setting temperature of zone 1 is higher than zone 2; during cooling operation of the unit, the set temperature of zone 1 is lower than zone 2. If the temperature of the later adjustment exceeds the limit, the temperature in another area will change accordingly.
- Page 28 Operation instructions for controller Picture 8 Picture 9 You can set except dates for the schedule in Picture 9. Schedule information is not executed on exceptional days. Picture 10 Tap “OK” in Picture 8, the display interface is as follows. Repeat steps to add another schedule.
- Page 29 Operation instructions for controller Picture 11 ② Delete First, tap the “DELETE” icon in the Picture 12, then small circle will appear like Picture 13; Second, select the schedules to be deleted. Last, press the “DELETE” icon in the lower right corner. Picture 12 Picture 13...
- Page 30 Operation instructions for controller ③ Unavailable To make a schedule unavailable, tap on the “UNAVAILABLE” icon, see Picture 12. Tap the icon of the desired schedule(s) to unavailable. After tapping “UNAVAILABLE”, unavailable schedules are grayed out as seen in Picture 14. Picture 14 ④...
- Page 31 Operation instructions for controller 3. Setting Tap “SETTING” on the interface of Picture 6 to enter the setting interface, shown in Picture 17. Picture 17 1) General setting You can change the Backlight brightness, Screensaver time, and Main/Sub controller switch by taping and dragging the slider.
- Page 32 Operation instructions for controller 3) Function setting Picture 20 Press “FUNCTION” icon to enter the function setting interface, shown in Picture 20. In this interface, you can turn on or off some common functions, and adjusting its working hours. In this interface, you can set following functions. System functions of user setting Function Parameter Range...
- Page 33 Operation instructions for controller Click the middle position of the lower sidebar of the screen to set the functions of IDU (Indoor Units). IDU functions of user setting Function Parameter Range Default Remarks Force Defrost On/Off Each IDU is controlled separately Heater1 Electric Heating Auto/Forced ON/Forced OFF Auto...
- Page 34 Operation instructions for controller ① Equipment installation Picture 23 Tap “EQUIPMENT INSTALLATION” icon to enter the unit configuration interface. You can turn on or off the corresponding functions in this interface. Function Parameter Range Default Zone 1 On/Off Zone 2 On/Off Pool On/Off...
- Page 35 Operation instructions for controller Function Parameter Range Default Zone 1 Compensation Temp. of Cooling -15~15°C 0°C Zone 1 Compensation Temp. of Heating -15~15°C 0°C Zone 2 Compensation Temp. of Cooling -15~15°C 0°C Zone 2 Compensation Temp. of Heating -15~15°C 0°C DHW Compensation Temp.
- Page 36 Operation instructions for controller Note: Zones water temperature control mode is valid at zone1 and zone2. a. Direct: set direct water temperature (fixed value). b. Auto curve: set water temperature depends on outdoor ambient temperature. The unit automatically adjusts the set temperature according to the curve, which cannot be changed by users.
- Page 37 Operation instructions for controller ⑤ Restore setting Tapping “RESTORE SETTING”, the system will be resettled to factory defaults and clear all settings. Picture 27 If you click “YES” to reinitialize, the controller will restart. If you click “Cancel”, then exit POP. 5) Status Tapping “STATUS”...
- Page 38 Operation instructions for controller ① System Function Remarks On indicates that there is an optional PCB (IO board), and Off Optional PCB indicates that there is no optional PCB. Third Party Controller Mode of Pool On/Off Third Party Controller Mode of DHW On/Off IDU Quick Stop Normal, Stop...
- Page 39 Operation instructions for controller ② IDU Status Picture 29 Function Remarks IDU Mode Stop, Cool, Heat, DHW, Pool IDU Antirust Operation On/Off IDU Anti-freeze Operation On/Off IDU Defrost Operation On/Off IDU Heater1 Overheated Normal, Overheated IDU Heater2 Overheated Normal, Overheated IDU Heater1(1kW) Output On/Off IDU Heater2(3kW) Output...
- Page 40 Operation instructions for controller ③ ODU Status Picture 30 Function Remarks Outdoor Unit Mode Stop, Cool, Heat Outdoor Defrost On/Off Outdoor Type Outdoor Voltage Type Power supply voltage of outdoor unit. Outdoor Frequency Type 50Hz/60Hz Outdoor Refrigerating Capacity Display accuracy: 0.5HP Outdoor Compressor Target Frequency Display accuracy: 1rps Outdoor Compressor Actual Frequency...
-
Page 41: Move And Scrap The Air Conditioning
Move and scrap the air conditioning • When moving, to disassemble and re-install the air conditioning, please contact your dealer for technical support. • In the composition material of air conditioning, the content of lead, mercury, hexavalent chromium, polybrominated biphenyls and polybrominated diphenyl ethers are not more than 0.1% (mass fraction) and cadmium is not more than 0.01% (mass fraction). - Page 44 Qingdao Haier Air Conditioner Electric Co.,Ltd. Haier Industrial Park,Qianwangang Road,Eco-Tech Development Zone,Qingdao 266555, Shandong,China...
