Technical data

Power supply input (X5)
Solenoid control output (X5)
OESL feedback input (X4)
Charging current monitoring
(X1...X3)
Optical links (V1...V6)
Standards applied
Operating temperature
Dimensions (L × W × D)
Mounting
Other features
Technical data
Operating voltage 230 VAC +10/-15%, 50/60 Hz or 115 VAC +10/-15%, 50/60 Hz
Current consumption 40/80 mA typical (230/115 VAC)
Protection by Microfuse 2.5 A, slow
6-position detachable screw terminal block, wire size max. 2.5 mm
Control voltage 115 or 230 VAC, +10/-15%
Control current max. 2 A for 3.5 s or max. 4 A for 20 ms
Protection by Microfuse 2.5 A, slow (common with power supply input)
6-position detachable screw terminal block, wire size max. 2.5 mm
Excitation voltage output 15 VDC max. 10 mA
4-position detachable screw terminal block, wire size max. 2.5 mm
Max. nominal input voltage of the drive: 690 VAC (IEC), 600 VAC (UL)
Max. charging current 16 ADC
3-position detachable screw terminal block, wire size max. 2.5 mm
Agilent Technologies Versatile Link series 5 MBd optical transmitters & receivers
Transmitter current 10 mA
Max. optical cable (POF) length 4 m
Safety requirements: EN 50178 Electronic equipment for use in power installations
IEC 61800-5-1 Semiconductor power converters for adjustable frequency drive
systems
UL 508 C Industrial Control Equipment
EMC emission: EN 6100-6-4 (IEC 61000-6-4) Emission for industrial environment
EMC immunity: EN 61000-6-2 (IEC 61000-6-2) Immunity for industrial environment
Free air circulation: +0...+50 °C
Forced convection cooling: Max. +70 °C, min. air flow 2 m/s
247 × 77 × 66 mm
On 7.5 × 35 mm mounting rail (EN50022), vertical or horizontal
UL approved (UL listed according to UL 508 C)
Conformal coating as standard
2
(Wieland 8142)
2
(Wieland 8142)
2
(Wieland 8142)
2
(Wieland 8142)
