- Page 1 OPERATIONS MANUAL MiniLink® Wireless Ethernet Systems MicroTek Electronics, Inc. 25691 Atlantic Ocean Drive, Suite B-3; Lake Forest, CA 92630 Information Hotline 888-36-MICRO www.microtekelectronics.com...
- Page 2 OBSERVE WARNINGS: All warnings in the operating instructions should be carefully followed. Do not make any modifications to the WEM, PIM, or any other MicroTek electronic device, as the unit will no longer comply with FCC regulations and therefore cancel its warranty.
- Page 3 Therefore, it is not possible to guarantee a successful application based on a drawing, application note, quote or other type of material that MicroTek may provide. Should a quote, drawing, etc. be made available, it is based on the performance of the WES product in an ideal environment with clear line-of-sight, absence of 5 GHz interference and/or frequency multi-path reflection.
- Page 4 As of July 20, 2007, a new FCC regulation has gone into effect which impacts operators of the U-NII band in the United States. As a result of this regulatory change, several MicroTek products are affected. The new FCC regulation impacts the sale of wireless equipment in the 5.25-5.35 GHz band.
-
Page 5: Table Of Contents
SECTION IMPORTANT SAFETY INSTRUCTIONS, FCC NOTICE ---------------- ( i ) RADIO FREQUENCY EXPOSURE, INDUSTRY CANADA ------------- ( ii ) IMPORTANT FCC REGULATORY NOTICE------------------------------- ( iii ) QUICK START GUIDE ----------------------------------------------------------- 2 PRE-INSTALLATION REMINDER, RETURN POLICY ----------------- 3 WEM DESCRIPTION ------------------------------------------------------------- 4 FRONT, REAR &... - Page 6 Trouble Shooting: If the signal level indicator is not fully lit, video does not appear on the screen or you are having other operational difficulties, please visit the trouble-shooting section on page 21 of the operations manual or contact MicroTek toll free at (888) 366-4276 for technical assistance.
-
Page 7: Quick Start Guide
Contact your MicroTek Electronics dealer or distributor to obtain an authorization to return the merchandise for credit. Return authorizations for repair can be sent directly to Microtek Electronics with a valid RA number. Call MicroTek Electronics to obtain an RA number for repair. -
Page 8: Wem Description
IRELESS The MiniLink WES is a plug and play CAT5/Ethernet cable replacement device. It operates in the 5.8 GHz U-NII bands on 5 non-overlapping channels. The WES system enables a wide variety of IP cameras, DVRs, encoders/decoders and web servers to be used across wireless line-of-sight links in ranges of 500 feet to 30 miles. -
Page 9: Pim Description
POWER INJECTION MODULE (PIM) Note: The Power Injector Modules are not weatherproof units and must be protected from moisture. PIM DESCRIPTION A. TOP VIEW B. RIGHT SIDE VIEW C. LEFT SIDE VIEW 1. ETHERNET IN – Connect to Ethernet device 2. -
Page 10: Wes Connection Diagram
WES CONNECTION DIAGRAMS The following wiring schemes represent the configurations that have been tested and verified by MicroTek Electronics based on typical Ethernet wiring solutions. Other wiring configurations could be possible based on the application. A bench test is recommended to verify the designs below. - Page 11 C. MOUNT OMNI-DIRECTIONAL HOST (IF APPLICABLE) Due to the orientation of the MiniLink Omni-directional Host when mounted, the unit must be kept inside a weatherproof housing. If the Weather Enclosure was purchased from MicroTek then it will come with pole/wall mounting hardware and instructions.
- Page 12 WEM INSTALLATION & OPERATION (cont’d) E. CONNECT HOST/CLIENT Connect the cable to the Host/Client. Slide the cable jacket up to the base of the connector. Slide the weatherproof connector over the cable jacket and screw it into the Host/Client and tighten.
- Page 13 IP address changes and other notes about your specific application. • A software tool is available for free download online on MicroTek Electronics’ website at www.microtekelectronics.com/softwaretools.htm the Host and Client. This tool can also be used as a diagnostic tool or to make alignment easier.
- Page 14 WEB PAGES (cont’d) B. STATUS – DEVICE STATUS 1. POINT-TO-POINT HOST AP The Device Status page provides the details of how the Single-Point Host is configured. The Access Point Name can be changed on the “Admin” page under the ADVANCED tab but the SSID cannot change.
- Page 15 B. STATUS – DEVICE STATUS 2. MULTI-CONNECT HOST AP The Device Status page provides the details of how the Multipoint Host is configured. 3. CLIENT SU The Device Status page provides the details of how the Client is configured. (cont’d) - 11 -...
- Page 16 WEB PAGES (cont’d) STATUS – HOST/CLIENT ASSOCIATION LISTS 1. POINT-TO-POINT AND MULTI-CONNECT HOST The Client List page of the Host AP shows the MAC address(s) of the paired or grouped Client SU(s) that are connected to the Host AP. For Point-to-Point systems, one MAC address will be shown. For Multi-connect systems, the Host AP will show all of the Client SU MAC addresses currently RSSI= Received...
- Page 17 WEB PAGES (cont’d) D. STATUS – STATISTICS The Statistics page will indicate the number of transmitted and received data packets versus the number of dropped packets. - 13 -...
- Page 18 WEB PAGES (cont’d) E. BASIC - WIRELESS The wireless page is used for enabling Super mode. The Super mode combines adjacent channels to provide up to 50+ Mbps of throughput. The channels available in Super mode are: 4 and 6 only. If another channel is selected, Super mode will not be enabled. To enable Super To change frequencies from the firmware (must start with remote side first):...
-
Page 19: Network Settings
F. BASIC – ETHERNET 1. NETWORK SETTINGS The Network Settings page is used for changing the IP Address, Subnet Mask and or Default Gateway of the Host or Client. - 15 -... - Page 20 WEB PAGES (cont’d) G. ADVANCED – ADMINISTRATION This section of the Advanced tab is used for changing the password and other administration services for the Host or Client. H. ADVANCED – SYSTEM To reboot the system and/or bring it to its default settings, visit the system page of the Advanced tab.
- Page 21 WEB PAGES (cont’d) I. ADVANCED – FIRMWARE This page is used to flash firmware upgrades should it be necessary to do so. - 17 -...
- Page 22 _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ _________________________________________________________________________________ If you have any questions regarding the advanced setup of the MiniLink Wireless Ethernet System, please contact MicroTek’s Technical Assistance at 888-366-4276 (Monday through Friday 8-5pm PST) or online at www.microtekelectronics.com Serial Number IP Address Serial Number...
-
Page 23: Web Browser Interface
WEM SPECIFICATIONS RF Modules RF SECTION Power Output Transmitting Frequency Channel Capacity Modulation Latency Sensitivity Polarization Antenna Type & Gain Beam Width Data Throughput Rate FCC ID Industry Canada MANAGEMENT Interface Frequency Selection Web Browser Interface Access Method Protocols Used MECHANICAL Physical Dimensions... -
Page 24: Wem Specifications
WEM SPECIFICATIONS (cont’d) Power Injection Module MECHANICAL Physical Dimensions Weight Interface POWER Power Requirements Power-over-Ethernet (PoE) Indicator Connectors ENVIRONMENTAL Humidity Operating Temperature System Ranges POINT-TO-POINT SYSTEMS_______ Up to 2500 Feet Up to 2 Miles Up to 12 Miles Up to 30 Miles Distance specifications assume an optimal environment (see pg ii for details) MULTI-CONNECT SYSTEMS Up to 500 Feet... -
Page 25: Trouble Shooting
If you have tried the trouble shooting steps above and the system is still not working correctly, please contact MicroTek at 888-366-4276, Monday through Friday, between the hours of 8:00AM and 5:00PM Pacific Time. One of our technicians will work with you to rectify the problem over the phone. -
Page 26: Faq
“over-the-air” in your configuration, more systems can be added to an existing WES system. There are multiple options to do this depending on the environment and application. Contact MicroTek technical support or sales at 888-366-4276 (Weekdays 8am – 5pm PST) or e-mail at your leisure to information. -
Page 27: Warranty
The warranty period on the repaired or replaced part or portion of this product shall be limited to the unexpired term of the original warranty. The buyer shall be responsible for all shipping and transportation of the product to MICROTEK for any performance under this warranty.
