Summary of Contents for ADC DSXpert 2005R
- Page 1 ADCP-80-421 Issue 1 October 2001 DSXpert™ 2005R DS3/E3 Remote Test Access System Installation Instructions 1173791 Rev A...
- Page 2 ADCP-80-421 Issue 1 October 2001 DSXpert™ 2005R DS3/E3 Remote Test Access System Installation Instructions 1173791 Rev A...
- Page 3 DISCLAIMER OF LIABILITY Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages.
-
Page 4: Table Of Contents
CUSTOMER INFORMATION AND ASSISTANCE ........... 25 Page iii © 2001, ADC Telecommunications, Inc. - Page 6 RELATED PUBLICATIONS Listed below are related manuals and their publication numbers. Copies of these publications can be ordered by contacting the ADC Technical Assistance Center at 1-800-366-3891 (in U.S.A. or Canada) or 952-917-3000, extension 73475 (outside U.S.A. and Canada). Title/Description...
- Page 7 Industry Canada. Operation in a residential area may cause unacceptable interference to TV and radio reception requiring the owner or operator to take whatever steps are necessary to correct the interference. Page vi © 2001, ADC Telecommunications, Inc.
- Page 8 Dual In-line Package Digital Signal, Level 3 Data Set Ready Data Terminal Equipment Data Terminal Ready Electrostatic Discharge Fallback Federal Communications Commission Ground Request to Send Receive Data Transaction Language 1 Transmit Data Page vii © 2001, ADC Telecommunications, Inc.
-
Page 10: General
FRONT LINE CARDS SLOT TEST CARD SLOTS 1 - 12 SLOTS 13 - 24 16852-A Figure 1. DSXpert 2005R Modular Chassis with Modules Inserted (modules may vary), Front View COMM AND POWER CARD TEST CARD REAR LINE CARDS REAR LINE CARDS... -
Page 11: Installation
ADCP-80-421 • Issue 1 • October 2001 The DSXpert 2005R product family consists of a chassis, up to 24 Front Line Cards, one Front Test Card, up to 24 Rear Line Cards, one Rear Test Card, one CPU Card, and one Communication and Power Supply Card. - Page 12 7. Secure the mounting brackets to the equipment rack using the 12-24 - 0.5-inch binder head machine screws provided. 8. Tighten the four mounting screws securely. Page 3 © 2001, ADC Telecommunications, Inc.
-
Page 13: Communication And Power Supply Card
There is a pair of male-to-female Input Power connectors (–48 Vdc, 2.5 A max) located on the Communication and Power Supply card. This card is installed on the rear of the chassis. Figure 5 shows a pair of male and female connectors. Page 4 © 2001, ADC Telecommunications, Inc. - Page 14 Warning: To fully power down the unit equipped with –48Vdc connectors, shut off power at the connecting power source. Do not disconnect dc connectors at terminal blocks on rear of chassis while power is being supplied to the unit. Page 5 © 2001, ADC Telecommunications, Inc.
-
Page 15: Connect Office Ground
After installing Power Supply Card connect male connector to female connector on chassis rear as shown in Figure 16872-A Figure 7. –48Vdc Input Power Connector, Male-to-Female Connection Page 6 © 2001, ADC Telecommunications, Inc. -
Page 16: Alarm Contacts (Optional)
9. Wire should be stripped to approximately 3/16-inch. Secure wire by tightening the top small screws on the male connector. ~3/16 IN. 18-22 AWG TURN SCREWS CLOCKWISE TO 16874-A SECURE WIRE Figure 9. Alarm Connector, Wiring Page 7 © 2001, ADC Telecommunications, Inc. -
Page 17: Blank Panels
Figure 10. Alarm Connector, Male-to-Female Connection 2.1.5 Blank Panels If applicable, remove blank panels by loosening fastener screws and pulling out from chassis as shown in Figure 11 Figure 16855-A Figure 11. Removing Blank Front Panels Page 8 © 2001, ADC Telecommunications, Inc. -
Page 18: Card/Module Installation
Before installing the CPU card, the onboard DIP switches must be properly configured to ensure proper operation of the DSXpert unit. The DSXpert 2005R unit has one bank of DIP switches, located on the CPU card, as shown in Figure Page 9 ©... - Page 19 Install the CPU card in the right most slot when viewed from the front. Secure module in the chassis by tightening the screws at the top and bottom of the module. Page 10 © 2001, ADC Telecommunications, Inc.
-
Page 20: Test Equipment Cards
Secure module in the chassis by tightening the screws at the top and bottom of the module. The Test Equipment Card has one green LED (labeled TST1). When operting properly the LED is illuminated green. Page 11 © 2001, ADC Telecommunications, Inc. - Page 21 ADCP-80-421 • Issue 1 • October 2001 16859-A Figure 15. Installing Front Test Equipment Card 16860-A Figure 16. Installing Rear Test Equipment Card Page 12 © 2001, ADC Telecommunications, Inc.
-
Page 22: Line Access Cards
Card installation is shown in Figure 17 Figure 16859-A Figure 17. Installing Front Line Access Card 16858-A Figure 18. Installing Rear Line Access Card Page 13 © 2001, ADC Telecommunications, Inc. -
Page 23: Cable Routing
ADCP-80-421 • Issue 1 • October 2001 One feature of the DSXpert 2005R Remote Test Access System is the capability to disable the local jack access to individual DS3/E3 circuits. This feature, called “locking”, allows the remote operator to secure uninterrupted traffic on certain high priority DS3/E3 lines. The locking... - Page 24 ADCP-80-421 • Issue 1 • October 2001 REAR LINE ACCESS CARDS SLOTS 1 - 12 AND 13 - 24 CIRCUIT LINE PORTS TRACER LAMP PORTS 16864-A Figure 19. DS3/E3 Port Connections Page 15 © 2001, ADC Telecommunications, Inc.
- Page 25 X OUT Tx OUT Tx OUT TRANSPARENT MODE X IN EQ IN FAC IN X IN Rx IN Rx IN 16878-A TRACER LAMP PORTS Figure 21. DS3/E3 Line Port Connections to DSX Cross-Connect Modules Page 16 © 2001, ADC Telecommunications, Inc.
-
Page 26: Ds3/E3 Test Ports
Optionally, test equipment ports may be daisy-chained across several 2005R DSXpert units to allow sharing of test sets among the chassis. It is not related to daisy-chaining of the COMM IN/COMM OUT serial control ports. Page 17 © 2001, ADC Telecommunications, Inc. -
Page 27: Comm Ports
ADCP-80-421 • Issue 1 • October 2001 To daisy-chain the test equipment ports, connect the ports as shown in Figure 23. Up to 4 DSXpert 2005R units can be daisy-chained together via their NEXT RACK ports. CHASSIS 1 CHASSIS 2 TEST EQUIPMENT CARD... - Page 28 Figure 24. IN1 Port Connections Table Table Table Table 6, and Table 7 detail the pin-out configurations of the RJ-45 ports on the Communication and Power Supply card. Table 3. 10Base-T Interface RJ-45 SIGNAL Page 19 © 2001, ADC Telecommunications, Inc.
- Page 29 DIRECTION Chain In First (SFIRST) Fall-back Bit 0 (FB0) IN/OUT Fall-back Bit 1 (FB1) IN/OUT Signal Ground – – Receive Data (SRXD) Transmit Data (STXD) Clear to Send (TCTS) Request to Send (TRTS) Page 20 © 2001, ADC Telecommunications, Inc.
-
Page 30: Daisy-Chaining Chassis (Optional)
This allows up to four units to share a single communication link, such as a common IP address. To daisy-chain DSXpert chassis together, connect the ports as shown in Figure CHASSIS 1 CHASSIS 2 TO LAN TO CONTROLLING TERMINAL OR PC 16868-A Figure 25. Daisy-Chaining Communication Ports Page 21 © 2001, ADC Telecommunications, Inc. -
Page 31: Aux Ports
The AUX1 port on the Communication and Power Supply card is used to connect the communication port of a test device, as shown in Figure CHASSIS 1 TO LAN TO TEST DEVICE 1 COMMUNICATION PORT 16869-A Figure 26. Connecting AUX/LOCAL Port Page 22 © 2001, ADC Telecommunications, Inc. -
Page 32: System Verification
LEDs may be tested by depressing the LAMP TEST button on the front of the CPU card. See Figure 27. All LEDs on the front card modules should illuminate. LAMP TEST PUSHBUTTON 16876-A Figure 27. LAMP Test Button Page 23 © 2001, ADC Telecommunications, Inc. -
Page 33: Specifications
ADCP-80-421 • Issue 1 • October 2001 4 SPECIFICATIONS This chapter provides technical specifications for the DSXpert 2005R DS3/E3 Remote Test Access System. System specifications are shown in Table Table 8. DSXpert 2005R System Specifications PARAMETER SPECIFICATION REMARKS Dimensions 23 x 12 x 6 inches (58.42 x 30.48 x 15.24 cm) -
Page 34: Customer Information And Assistance
ADC Telecommunications, Inc., P.O. Box 1101, Minneapolis, MN 55440-1101, U.S.A. Contents herein are current as of the date of publication. ADC reserves the right to change the contents without prior notice. In no event shall ADC be liable for any damages resulting from loss of data, loss of use, or loss of profits and ADC further disclaims any and all liability for indirect, incidental, special, consequential or other similar damages. - Page 36 www.adc.com...
