MANUALE OPERATIVO / INSTRUCTION MANUAL IM818-IU v0.1 RI-R45 RI-R45 Insulation monitoring device Monitor di isolamento di impianti IT fino a 440 VCA of IT systems up to 440 VAC (1 soglia TRIP) (1 threshold TRIP) pag. 1 / 4...
Page 2
Introduction L’RI-R45 è un dispositivo che consente il monitoraggio dell'isolamento di RI-R45 is a device that allows the insulation monitoring to earth up impianti IT fino a 440 VCA. Il controllo della resistenza di isolamento avviene to 440 VAC of networks (IT systems). By applying a DC component measure applicando un segnale di misura a componente continua tra la linea e la terra signal between the insulated line and earth it’s possible to control the...
Page 3
Dip switch di programmazione Dip switches setting n°8) F.S. TRIP – OFF n°8) F.S. TRIP – OFF F.S. TRIP = sicurezza positiva attivita su relè di TRIP; in questa condizione il F.S. TRIP = positive safety activated on TRIP relay. In this condition the relè...
Page 4
EN 61010-1, EN 61557-8, EN 61326-1 Reference standards EN 61010-1, EN 61557-8, EN 61326-1 For further details please contact: Per ulteriori informazioni contattare: Contrel elettronica s.r.l. Via San Fereolo, 9 I-26900 Lodi Tel: +39 0371 30207 / 30761 / 35386 Fax: +39 0371 32819 E-Mail: contrel@contrel.eu...
