- Page 1 HIGH PRESSURE CLEANERS PS3395 IMPORTANT: Please make certain that the person who is to use this equipment carefully reads and understands these instructions before operating. INSTRUCTION MANUAL...
- Page 2 We Appreciate Your Business. Thank you and congratulations for choosing Powershot , another quality product by Powerblast. This Operating Manual has been designed to instruct you on the correct use and operation of your Powershot product. Your satisfaction with this product and its safe operation is our ultimate concern.
-
Page 3: Table Of Contents
Table Of Contents Specifications.................4 Symbol Usage ..................4 Quick Set-Up Guide ................5 Quick Start Guide ................5 Power Washer Controls & Features...........7 Pressure Washer Terminology ............8 Assembly Instructions ...............8 Operating the Power Washer ............9 Maintenance ..................13 Storage .....................14 Accessories................14 Service Information................14 Troubleshooting ................15 Important Safety Instructions..............17 Warranty.................... -
Page 4: Specifications
Specifications PS3395HD 3300psi PSI Max*: 9.5L/min L/Minute Max*: High Pressure Hose: 20-100psi Presure of Inlet Water: Cold tap Inlet Water: 10% max Soap Consumption Rate: * Rated Pressure and Rated Water Flow is within manufacturing tolerance of (+/- 10%). In a continued commitment to improve quality, the manufacturer reserves the right to make component changes, design changes, or specification changes when necessary and without notice. -
Page 5: Quick Set-Up Guide
Quick Set-Up Guide WARNING! To reduce the risk of injury, read the pressure washer instruction manual and the engine instruction manual before operating pressure washer. Quick Start Guide DANGER! Never run engine indoors or in enclosed, poorly ventilated areas. Engine exhaust contains carbon monoxide, an odorless and deadly gas. - Page 6 WARNING! This Guide is not a substitute for reading the operator’s manual. User must read and understand operator’s manual before using this product.
-
Page 7: Power Washer Controls & Features
Power Washer Controls and Features NOTE: Photographs and line drawings used in this manual are for reference only and do not represent a specific model. Compare the illustrations with your unit to familiarize yourself with the location of various controls and adjustments. Save this manual for future reference. -
Page 8: Pressure Washer Terminology
Pressure Washer Terminology Assembly instructions PSI (Pounds per Square Inch): The unit of meas- ure for water pressure. Also used for air pressure, hydraulic pressure, etc. LPM (Litres Per Minute): The unit of measure for the flow rate of water. CU (Cleaning Units): LPM multiplied by psi equals CU. -
Page 9: Operating The Power Washer
Operating the Power Washer SURFACES: USES: Red - 0 Powerful pinpoint Pressure Adjustments Unpainted metal for spot cleaning or concrete. of hard, unpainted The pressure setting is preset at the factory to DO NOT use on surfaces or for achieve optimum pressure and cleaning. If you need wood. - Page 10 Changing Nozzles on Spray Wand NOTE: For every 7 litres of water pumped 1 litre of chemical/cleaning solution will be used. The nozzles for the spray wand are stored in the nozzle holder on the panel assembly. Colors on the 3.
- Page 11 TREAT FLUID INJECTION AS A SIMPLE CUT! See when spray gun trigger is not pressed. If pump is a physician immediately! left in bypass mode for more than two minutes in- ternal components of the pump can be damaged. DANGER! Carbon Monoxide. Using an engine indoors can kill you in minutes.
- Page 12 NOTE: Water source provided must be a minimum 12. Depress trigger on gun to start water flow. of 20 litres per minute at 20psi WARNING! Risk of unsafe operation. Stand 7. Connect high pressure hose (C) to pump outlet on a stable surface and grip gun/spray wand (I).
-
Page 13: Maintenance
To Check Oil NOTE: Failure to release system pressure will prevent removal of high pressure hose from spray The oil level should come to the dot in the middle of gun or pump connection. the sight glass (AA). 5. See Storage section in this manual for proper storage procedures. -
Page 14: Storage
2. Pull trigger on gun and/or when freezing temperatures are expected. handle to relieve any Simply fill a bucket up half way with anti-freeze/ water pressure. water mix and use a short length of hose to suck the mixture into the pump while running. Turn machine 3. -
Page 15: Troubleshooting
Troubleshooting PROBLEM SOLUTION POSSIBLE CAUSE No fuel Add fresh fuel Pressure builds up after two pulls on Squeeze gun trigger to relieve pressure the recoil starter or after initial use Engine will Choke lever in the “No Choke” position Move choke to the “Choke” position not start (see Engine Owner’s Attach spark plug wire... - Page 16 SOLUTION PROBLEM POSSIBLE CAUSE See How to Use Spray Wand paragraph in Spray wand not in low pressure the Operation Section Chemical filter clogged Clean filter Chemical screen not in cleaning Make sure end of detergent siphon hose Will not draw chemicals solution is fully submerged into cleaning solution...
-
Page 17: Important Safety Instructions
Important Safety Instructions Wash hands after handling. WARNING! This product may not be DANGER! : Carbon Monoxide. Using an equipped with a spark-arresting muffler. If engine indoors can kill you in minutes. En- the product is not equipped and will be used gine exhaust contains high levels of carbon around flammable materials or on land cov- monoxide (CO), a poisonous gas you can- ered with materials such as agricultural crops,... - Page 18 DANGER! Risk of Explosion or Fire WHAT CAN HAPPEN HOW TO PREVENT IT Spilled gasoline and it’s vapors can become Shut off engine and allow it to cool before adding ignited from cigarette sparks, electrical arcing, fuel to the tank. exhaust gases and hot engine components Use care in filling tank to avoid spilling fuel.
- Page 19 DANGER! Risk to Breathing (Asphyxiation) WHAT CAN HAPPEN HOW TO PREVENT IT Operate pressure washer in a well ventilated area. Breathing exhaust fumes will cause serious Avoid enclosed areas such as garages, base- injury or death! Engine exhaust contains car- ments, etc.
- Page 20 Injuries can result if system pressure is not To relieve system pressure, shut off engine, turn off reduced before attempting maintenance or water supply and pull gun trigger until water stops disassembly. flowing. Use only accessories rated equal to or higher than the rating of the pressure washer.
- Page 21 If engine does not start after two pulls, squeeze trigger of gun to relieve pump pressure. Pull starter If proper starting procedure is not followed, cord slowly until resistance is felt. Then pull cord engine can kickback causing serious hand and rapidly to avoid kickback and prevent hand or arm arm injury.
- Page 22 DANGER! Risk of Chemical Burn WHAT CAN HAPPEN HOW TO PREVENT IT Use of acids, toxic or corrosive chemicals, Do not spray acids, gasoline, kerosene, or any oth- poisons, insecticides, or any kind of flammable er flammable materials with this product. Use only solvent with this product could result in serious household detergents, cleaners and degreasers injury or death.
-
Page 23: Warranty
Powerblast customer service on 1800 812 223. Registered warranty period for the PS3395: Kohler 3000 series engine covered by 24 month Kohler warranty Warranty covers failure caused by manufacturing and material defects in the product, during the war- ranty period specified. - Page 24 PUMP SERVICE ASSY KIT 7200068 COUPLER 3/8(F)X M22(F)14MM TWIST 7103266 PLUG, SNAP-ON X GHT(M) 7105013 WHEEL, SERVICE KIT 7110437 ENGINE SVC ASSY, SH265 KOHLER, RED 7103750 MOUNTING KIT, ENGINE 7109301 NOZZLE,#2.6 5PCSET 0, 15, 25, 40 & PSOAP 7107941 KNOB-BOLT ASSEMBLY 7110107...
- Page 25 11.1.1 11.1.2 11.1 11.1 5 5 5...
- Page 26 ITEM PART NO QTY. DESCRIPTION 7109932 PUMP SERVICE ASSY KIT 530017 PUMP, CY SERIES, HORIZ TRIPLEX, 12x8.2 7105474 HARDWARE KIT, PUMP MOUNTING 7101506 KEY, SHAFT 3/16 X 3/16 X 1-1/2 ITEM PART NO QTY. DESCRIPTION 7103642 HOSE, 3/8" x 25' x 4500PSI PLAT 2PC SWV/SWV 7108125 GUN, 4500PSI 3/8QC(M) INLET X M22(F) OEM 7103550...
- Page 27 PHOENIX CY SERIES TRIPLEX PUMPS PUMP COVERED IN THIS IPL 530017 3400psi @ 2.3 gpm PUMP, CY SERIES, HORIZ TRIPLEX, 12X8.2...
- Page 28 PUMP KIT, 530017 MANIFOLD PART NO. 7110118 530015 PUMP DRAWING PARTS LIST ITEM PART NO. DESCRIPTION COMMENT 7110132 VENTURI KIT TORQUE TO 7110131 THERMAL RELIEF VALVE 155 IN-LB 18N-M 7105740 CHECK VALVE KIT 2 KITS REQ'D FOR THIS MODEL 7110129 VALVE CAP KIT TORQUE TO 155 IN-LB 18N-M 7110125 SEAL RETAINER KIT...
- Page 29 Record all information and attach sales receipt here for future reference PURCHASE DATE: ______________________________ SERIAL NUMBER ______________________________________ Congratulations on your new POWERSHOT product. We are proud to have you as our customer and will strive to provide you with the best service and reliability in the industry.
