Page 2: Safetyprecautions
SAFETY PRECAUTIONS Read all of the instructions before using this appliance. When using this appliance, always exercise basic safety precautions, including the following: 1) Use this appliance only for its intended purpose as described in this use and care guide. 2) This freezer must be properly installed in accordance with the installation instructions before it is used. - Page 3 10) This freezer should not be recessed or built-in an enclosed cabinet. It is designed for freestanding installation only. 11) Do not operate your freezer in the presence of explosive fumes. 12) Use of an extension cord is not recommended. 13) People (including children) that lack of product experience and knowledge are not recommended to use unless under supervision or given instruction on how to use the appliance in a safer or correct ways.
- Page 4 20) Do not replace the LED light by yourself, please contact the supplier if necessary. 21) In the case of not using the freezer for a long term, please unplug the power cord and turn off the power. And clean the freezer inner liner according to the cleaning method described above and dry it to prevent food from becoming moldy and deteriorated in a sealed state for a long time.
- Page 5 Leave the shelves in place so that children may not easily climb inside. ___________________________ Thank you for using our Haier product. Model number This easy-to-use manual will guide you in getting the best use of your freezer.
-
Page 6: Table Of Contents
Table Of Contents PAGE SafetyPrecautions ......................1 Parts And Features......................6 Installing Your Freezer .....................7 Unpacking your Freezer ......................7 Adjusting your freezer ......................7 Proper Air Circulation ......................7 Electrical Requirements.......................8 Install limitations........................8 Freezer Features And Use....................9 Operating Your Freezer.......................9 General Features.........................9 Fast Freeze.........................9 Food Storage Baskets.......................10 Defrosting And Draining.....................10 Lock and Key ........................11... -
Page 7: Parts And Features
Parts And Features 5. Thermostat knob 1. Cabinet 2. Foam-stuffed door 6. Fast freeze Indicator (orange light) 3. Water drain 7. Power-On Indicator (green light) 8. Castor 4. Control Panel... -
Page 8: Installing Your Freezer
Installing Your Freezer Unpacking Your Freezer 1. Remove all packaging material. This includes the foam base and all adhesive tape holding the freezer accessories inside and outside. 2. Inspect and remove any remains of packing, tape or printed materials before powering on the freezer. -
Page 9: Electrical Requirements
Electrical Requirement Make sure there is a suitable power outlet (220 volts, 15 amps outlet) with proper grounding to power the freezer. Avoid the use of three plug adapters or cutting off the third grounding in order to accommodate a two plug outlet. -
Page 10: Freezer Features And Use
Freezer Features And Use Operating Your Freezer Once the freezer is in its proper place, plug it in an electrical outlet having 220 volts and 15 amps. In case you unplug your freezer or experience an electrical outage, allow 5 minutes before plugging it back in. -
Page 11: Food Storage Baskets
Temperature Ranges Dial Position 4 ~ 8℃ 0 ~ 4℃ -4 ~ 0℃ -9 ~ -4℃ -14 ~ -9℃ -19 ~ -14℃ -24 ~ -19℃ Food Storage Basket (see fig.#1) Your freezer has 1 or 2 removable basket. It allows you to store food more accessibly or you can remove it if not needed. -
Page 12: Lock And Key
Lock and Key If your freezer has a lock and key feature to secure the freezer, Close the lid and turn key to lock. Turn key in direction to unlock. Castors If your freezer can be equipped with castors for easy moving, We recommend installing castors before using the freezer. -
Page 13: Normal Operating Sound
Heavy duty aluminum foil Plastic wrap made from saran film Self-sealing plastic bags Do not refreeze defrosted/thawed foods. It is recommended that the freezing date be marked on the packaging. Normal Operating Sounds You May Hear Water boiling, gurgling sounds or slight vibrations that are the result of the refrigerant circulating through the cooling coils. -
Page 14: Power Interruptions
Power Interruptions Occasionally there may be power interruptions due to thunderstorms or other causes. Remove the power cord from AC outlet when a power outage occurs. When power has been restored, replug power cord to AC outlet. If outage is for a prolonged period, inspect and discard spoiled or thawed food in freezer. -
Page 15: Troubleshooting
TroubleShooting Freezer Does Not Operate: Check if freezer is plugged in. Check if there is power at the AC outlet by checking from the circuit breaker. Monitor for 30-40 minutes and check if the freezer start working. Compressor cycle ... - Page 16 0070517115...
