4747 230R Multi-Freq User Guide
1 230R base station receiver
2 body-worn transmitter
(330T shown here)
3 speakers (470-2856-119)
(compact wall speaker shown here)
*speakers packaged separately
4 microphone/(AT0655 boom
microphone shown here)
5 power supply
(040-7402-105)
6 power cord
(AT0787 for USA/Canada)
(AT0787-EN for England)
(AT0787-EU for Europe)
(AT0787-AU for Australia and
New Zealand)
NOTE: Refer to part number cross-reference list
All manuals and user guides at all-guides.com
4/22/05 3:09 PM
10 aux-out adaptor plug/(3.5mm – 2.5mm)
Page 12
7 antenna
(AT0831)
8 aux out cable/(RCA 3.5mm)
(AT0805)
9 aux-in adaptor plug /(
(310-2544-1342)
(310-2544-1341)
11 330T transmitter charging cord
(1.3mm – Dual 1.3mm)
(300-6497-105)
12 speaker wire
(AT0581)
(Plenum rated, 24ft/7.3m, 48ft/14.6m,
60ft/18.3m lenths)
1 / in – Dual RCA)
