GPX D200B User Manual

DVD PLAYER
User's Guide for Model D200B v1938-01
Important Safety Instructions
• Read these Instructions.
• Keep these Instructions.
• Heed all Warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or
other apparatus (including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized or grounding - type plug. A
polarized plug has two blades with one wider than the other. A grounding type
plug has two blades and a third grounding prong. The wide blade or the third
prong are provided for your safety. When the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Unplug this apparatus during lightning storms or when unused for long
periods of time.
• Refer all servicing to qualified service personnel. Servicing is required
when the apparatus has been damaged in any way, such as power-supply
cord or plug is damaged, liquid has been spilled or objects have fallen into
the apparatus, the apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
• Use only with a cart, stand, tripod, bracket, or table specified
by the manufacturer, or sold with the apparatus. When a cart is
used, use caution when moving the cart/apparatus combination
to avoid injury from tip-over.
FCC Warnings
Warning: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user's authority to operate the
equipment.
NOTE: This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
Power
Plug the attached AC cord into a standard AC power outlet to power the DVD player.
Y Pb/Cb Pr/Cr
R L VIDEO COAXIAL
AUDIO OUT VIDEO OUT DIGITAL
Disc Drawer
DVD / CD PLAYER
Component Video Output
Y Pb/Cb Pr/Cr
120V ~ 60Hz
R L VIDEO COAXIAL
AUDIO OUT VIDEO OUT DIGITAL
Composite Video Output
RCA Stereo Audio Outputs
can be determined by turning the equipment off and on, the user is encouraged to
try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Additional Warnings and Precautions
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE OF
PLUG TO WIDE SLOT, FULLY INSERT.
• Mains plug is used as disconnect device and it should remain readily operable
during intended use. In order to disconnect the apparatus from the mains
completely, the mains plug should be disconnected from the mains socket
outlet completely.
• CAUTION: Use of controls or adjustments or performance of procedures
other than those specified may result in hazardous radiation exposure.
• WARNING: Changes or modifications to this unit not expressly approved by
the party responsible for compliance could void the user's authority to operate
the equipment.
• WARNING: Use of this unit near fluorescent lighting may cause interference
regarding use of the remote. If the unit is displaying erratic behavior move
away from any fluorescent lighting, as it may be the cause.
• WARNING: Shock hazard - Do Not Open.
• Caution and marking information is located at the rear or bottom of the
apparatus.
• WARNING: To reduce the risk of fire or electric shock, do not expose this
apparatus to rain, moisture, dripping, or splashing.
• Objects filled with liquids, such as vases, shall not be placed on the apparatus.
• CAUTION: Danger of explosion if battery is incorrectly replaced. Replace
only with the same or equivalent type.
• WARNING: There is a danger of explosion if you attempt to charge standard
Alkaline batteries in the unit. Only use rechargeable NiMH batteries.
• Battery shall not be exposed to excessive heat such as sunshine, fire or the
like.
• Keep new and used batteries away from children. If the battery compartment
does not close securely, stop using the product and keep it away from children.
• If you think batteries might have been swallowed or placed inside any part of
the body, seek immediate medical attention.
• Do not mix old and new batteries.
• Completely replace all old batteries with new ones.
• Do not mix alkaline, standard (carbon-zinc), or rechargeable (ni-cad, ni-mh,
etc) batteries.
120V ~ 60Hz
Stop
OPEN/ PLAY/ STOP
CLOSE PAUSE
Open/Close
Play/Pause
Remote Reciever
Coaxial Digital Audio Output
Overview
Remote
Requires 2 AAA batteries (not included).
Power
Number Keypad
Use to enter channel
POWER
or track numbers.
Press to view alternate
angles on supported DVDs.
Press to access the
loaded DVD's menu.
Arrows/Enter
Press to make selections
in the on screen menus.
Press to access the title
menu on a loaded DVD.
Volume
Press to halt play of the DVD.
Play/Pause
Press to play or pause the DVD.
Press to switch between
Composite or S-Video.
Press to view the
on-screen display
Press to adjust the audio
mode on a supported DVD.
Press to switch between
NTSC and PAL.
Reverse/Fast Fwd
Press to search through an
individual chapter or track.
• Batteries should be recycled or disposed of as per state and local guidelines.
• WARNING: This product may contain chemicals known to the State of
California to cause birth defects, or other reproductive harm (California Prop
65). Wash hands after handling.
• This product meets and complies with all Federal regulations.
WARNING: DO NOT INGEST BATTERY,
CHEMICAL BURN HAZARD.
CAUTION
Warning: To reduce the risk of electric shock, do not remove
cover (or back). No user-serviceable parts inside. Refer
RISK OF ELECTRIC SHOCK
DO NOT OPEN
servicing to qualified service personnel.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
This symbol indicates that this product incorporates double
insulation between hazardous mains voltage and user
accessible parts.
This product utilizes a Class 1 laser to read Compact Discs.
This laser Compact Disc Player is equipped with safety
switches to avoid exposure when the CD door is open and
the safety interlocks are defeated. Invisible laser radiation is
present when the CD Player's lid is open and the system's
interlock has failed or been defeated. It is very important
that you avoid direct exposure to the laser beam at all times.
Please do not attempt to defeat or bypass the safety switches.
Power
OPEN/CLOSE
MUTE
Angle
AUDIO
Menu
GOTO
PROG
ANGLE
Title
MENU SETUP
ENTER
Stop
TITLE SUBTITLE
Video
OSD
VOLUME
L/R
VIDEO OSD WIDE ZOOM
N/P
L/R N/P SLOW REPEAT
STEP TTS
Open/Close Disc Tray
Mute
Audio
For TV play, press to turn
closed captioning ON or OFF.
For DVD play, press to adjust
audio settings for the DVD.
Go To
Press to enter a specific
chapter and
Prog
Press to program a loaded
disc to play titles, chapters, or
tracks in a specified order.
Setup
Press to access the
setup menu.
Subtitle
Press to turn subtitles
ON or OFF.
Skip Back/Forward
Press to skip between
chapters or tracks.
Zoom
Press to zoom in or out
on a loaded DVD.
Slow
Press to play in slow motion.
Repeat
Press to repeat a
chapter or track.
Step
Press to advance one
frame at a time.
TTS
Press to turn Text to Talk
ON or OFF (intended for
visually impaired users).
