Husler Turf Equipment at time of delivery. Be sure to register the tractor plus each attachment that displays a model and serial identification number plate with Hustler Turf Equipment. IMPORTANT: non-approved attachments voids the warranty and releases Hustler Turf Equipment from any liability arising from subsequent use of this equipment.
Page 5
The foregoing warranties are in lieu of all other warranties, expressed or implied, including but not limited to the implied warranties of merchantabil- ity and fitness for a particular purpose. However, if the Hustler Turf Equip- ment is purchased as a consumer product, any implied warranty of merchantability or fitness for a particular purpose is limited to the duration of this limited warranty.
Page 6
This machine like any other powered equipment is potentially dangerous unless properly operated. Any operator must be cautious and keep safety in mind at all times. Any operator, prior to using the Hustler Turf Equipment, should thoroughly familiarize himself with the owner's manual regarding operation and safety of the machine, as well as all safety warnings on the machine itself.
Page 7
The foregoing warranties are in lieu of all other warranties, expressed or implied, including but not limited to the implied warranties of merchantabil- ity and fitness for a particular purpose. However, if the Hustler Turf Equip- ment is purchased as a consumer product, any implied warranty of merchantability or fitness for a particular purpose is limited to the duration of this limited warranty.
Page 8
This machine like any other powered equipment is potentially dangerous unless properly operated. Any operator must be cautious and keep safety in mind at all times. Any operator, prior to using the Hustler Turf Equipment, should thoroughly familiarize himself with the owner's manual regarding operation and safety of the machine, as well as all safety warnings on the machine itself.
Page 9
This safety alert symbol is used to call attention to a message intended to is equipment. le degree of PERSONAL SAFETY for operators and other L result in severe per- 8result in 601156_1106 adable. Safety and Instruction Decals▲Specific safety warning decals are located on the equipment near the immediate areas of potential hazards.
Page 10
Keep engine and pump compartment(s) clean (especially in exhaust area) to prevent fire and provide maximum engine and hydraulic cooling. Refueling While Operating Never perform maneuvers Stop engine and allow engine to cool for 2 at high ground speeds. minutes prior to refueling. Avoid sudden turns.
Use this diagram when determining the degree of slope to be mowed. E (15 D (10 C (5 1. Hold this sheet of paper in front of you. Make sure that Line A is horizontal. 2. Align Line B with a vertical surface such as pole, tree or building. 3.
Safe Operating Practices This product is capable of amputating hands and feet and throwing objects. Always follow all safety instructions to avoid serious injury or death. Operation ▲ Never leave a running machine unattended. Always disengage deck clutch, place steering control levers in park brake position, stop tractor engine, and remove ignition key when leaving operator’s seat.
▲ Never make sudden starts, stops, turns, or reverse direction, especially when maneuvering on slopes. The steering is designed for sensitive response. Rapid movement of the steering control levers in either direction could result in a reaction of the tractor that can cause serious injury.
Steering control levers in park brake position Figure 3-3 Deck lift pedal Figure 3-4 C. Deck clutch switch (Fig. 3-1) — this switch engages the deck. Pull the switch up to engage and push switch down to disengage the clutch. IMPORTANT: Never engage clutch with engine running at high rpm or when the deck is under load.
Mini FasTrak 36/42 Slot Bypass valve rod (Left rod shown) (Viewed from the rear left underneath side) Figure 3-5 Bypass valve rod shown in towing position Figure 3-6 for a couple of minutes; then rotate ignition key counter-clockwise to the OFF position.
Page 17
FRONT OF TRACTOR FACES THIS DIRECTION FORWARD TRAVEL PIVOT TURN N = NEUTRAL POSITION Direction of arrows indicate direction of tractor movement equipment, should read the manual completely and thoroughly, and should have attempted slow moving maneuvers to become familiar with the operation of the equipment before attempting normal speed operation.
stop djusting Figure 3-10 Stop handle Three point turn Height Figure 3-9 Alternate mowing direction to keep the grass growing straight and bet- ter dispersion of the clippings. Remember, grass grows at different rates at different time of the year. Mow more often in the early spring to maintain the same cutting height.
EXAMPLE: When the height adjusting stop is placed in the 1-1/2” (3.81 cm) hole, with the 1/4” (.64 cm) plate facing to the front of the unit, the cutting height is at 1-1/2” (3.81 cm). When the height adjusting stop is placed in the 1-1/2”...
MAINTENANCE & ADJUSTMENTS Safe Servicing Practices This product is capable of amputating hands and feet and throwing objects. Always follow all safety instructions to avoid serious injury or death. Service ▲ Unless specifically required, DO NOT have engine running when ser- vicing or making adjustments to tractor.
Lubrication Use SAE multi-purpose grease. Electrical system The electrical system is a 12-volt, negative ground. Recommended bat- tery size is a garden tractor BCI group U1R with 225 or better cranking AMP rating. A maintenance-free battery is recommended. Otherwise, follow bat- tery manufacturer’s maintenance, safety, storing and charging specifications.
Mini FasTrak 36/42 shown Keep fuel away from open flame or spark and store machine away from open flame or spark if there is fuel in the tank. Use extra caution when handling gasoline and other fuels. They are flammable and vapors are explosive. A fire or explo- sion from gasoline can burn you and others and can damage property.
Use a 15/16" wrench to remove the 5/8" cap screw holding the blade to the spindle shaft from underneath. NOTE: A blade holding tool (part number 381442) is available from Hustler Turf Equipment. It is designed to prevent the blades from rotating when they are being removed or installed on the spindle.
Cap screw Figure 4-1 Mini FasTrak 36/42 shown Figure 4-9 Figure 4-10 WARNING: Failure to correctly torque the bolt may result in the loss of the blade which can cause serious injury. WARNING: Mower blades are sharp and can cut. Wrap the blade(s) or wear gloves and use extra caution when servicing them.
Mini FasTrak 36/42 Maintenance Schedule Refer to Fig. 4-12 WEEKLY SERVICE AT OR 50 INTERVALS INDICATED HOURS Verify safety start interlock system Prior to each use Visually inspect unit for loose hardware and/or damaged parts Prior to each use Visually inspect tires Prior to each use Check oil level, engine (1) Prior to each use or every 4 hours...
SYMPTOMS PROBABLE CAUSES Starting motor does not Steering control levers not crank in park brake position or switch not adjusted Deck clutch switch engaged Weak or dead battery Electrical connections are corroded or loose 20 amp fuse is blown For additional causes The engine will not No fuel or line plugged start, starts hard or fails...
When storing the unit at the the end of the mowing season, the following steps should be taken to ensure readiness for the next mowing season. Remove all grass, dirt, and trash from tractor and mower. Clean tractor and mower and touch up all scrapes with Hustler spray paint. IMPORTANT: Wash the machine with a mild detergent and water.
