XM-GS100
CONTROL LED
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked "*" are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
Ref. No. Part No. Description
A-1870-253-A CONTROL BOARD, COMPLETE
************************
4-411-136-01 BRACKET VOL
< CAPACITOR >
C206 1-162-927-11 CERAMIC CHIP 100PF
C207 1-114-983-91 CERAMIC CHIP 2.2uF
C208 1-100-597-91 CERAMIC CHIP 0.1uF
C209 1-114-983-91 CERAMIC CHIP 2.2uF
C210 1-116-871-11 ELECT
C211 1-162-927-11 CERAMIC CHIP 100PF
C212 1-116-871-11 ELECT
C213 1-116-871-11 ELECT
C214 1-162-927-11 CERAMIC CHIP 100PF
C215 1-127-715-11 CERAMIC CHIP 0.22uF
C216 1-136-169-00 FILM
C218 1-136-497-81 FILM
C219 1-116-871-11 ELECT
C222 1-100-597-91 CERAMIC CHIP 0.1uF
C223 1-162-927-11 CERAMIC CHIP 100PF
C224 1-100-597-91 CERAMIC CHIP 0.1uF
< CONNECTOR >
CN003 1-564-705-11 PIN, CONNECTOR (SMALL TYPE) 3P
< DIODE >
D201 6-502-961-01 DIODE DA2J10100L
D202 6-502-961-01 DIODE DA2J10100L
D203 6-502-961-01 DIODE DA2J10100L
D204 6-502-961-01 DIODE DA2J10100L
< IC >
IC903 8-759-710-97 IC NJM4565M-D
IC904 8-759-710-97 IC NJM4565M-D
IC905 8-759-710-97 IC NJM4565M-D
IC906 8-759-710-97 IC NJM4565M-D
< TRANSISTOR >
Q101 8-729-620-07 TRANSISTOR
< RESISTOR >
R207 1-216-825-11 METAL CHIP
R208 1-216-845-11 METAL CHIP
R210 1-216-813-11 METAL CHIP
20
SECTION 6

ELECTRICAL PARTS LIST

• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
Remark
5% 50V
10% 16V
10% 25V
10% 16V
4.7uF 20% 50V
5% 50V
4.7uF 20% 50V
4.7uF 20% 50V
5% 50V
10% 16V
0.22uF 5% 50V
0.1uF 5% 50V
4.7uF 20% 50V
10% 25V
5% 50V
10% 25V
*************************************************************
2SC3052EF-T1-LEF
2.2K 5% 1/10W
100K 5% 1/10W
*************************************************************
220 5% 1/10W
When indicating parts by reference num-
ber, please include the board name.
Ref. No. Part No. Description
R211 1-216-829-11 METAL CHIP
R213 1-216-823-11 METAL CHIP
R214 1-216-823-11 METAL CHIP
R216 1-216-825-11 METAL CHIP
R217 1-216-837-11 METAL CHIP
R218 1-216-827-11 METAL CHIP
R219 1-216-841-11 METAL CHIP
R220 1-216-819-11 METAL CHIP
R221 1-216-837-11 METAL CHIP
R222 1-216-829-11 METAL CHIP
R223 1-216-841-11 METAL CHIP
R224 1-216-821-11 METAL CHIP
R225 1-216-827-11 METAL CHIP
R228 1-216-827-11 METAL CHIP
R229 1-216-833-11 METAL CHIP
R230 1-216-841-11 METAL CHIP
R233 1-216-832-11 METAL CHIP
R234 1-216-841-11 METAL CHIP
R235 1-216-841-11 METAL CHIP
< VARIABLE RESISTOR >
RV201 1-227-851-11 RES, VAR, CARBON 10K/10K (LEVEL)
RV202 1-225-922-12 RES, VAR CARBON 20K/20K (SUBSONIC FILTER)
RV203 1-227-851-11 RES, VAR, CARBON 10K/10K
RV204 1-225-922-12 RES, VAR CARBON 20K/20K (LOW PASS FILTER)
A-1870-252-A LED BOARD, COMPLETE
********************
< CAPACITOR >
C991 1-100-597-91 CERAMIC CHIP 0.1uF
C992 1-100-597-91 CERAMIC CHIP 0.1uF
< LED >
D919 6-503-323-01 LED SELG2E10C-S-TP3 (ILLUMINATION)
D920 6-503-322-01 LED SELG2E10C-S-TP6 (ILLUMINATION)
D921 6-503-557-01 LED 1L0341V31C0TPC01 (PROTECTOR)
< RESISTOR >
R990 1-216-829-11 METAL CHIP
R991 1-216-829-11 METAL CHIP
R992 1-216-829-11 METAL CHIP
Remark
4.7K 5% 1/10W
1.5K 5% 1/10W
1.5K 5% 1/10W
2.2K 5% 1/10W
22K 5% 1/10W
3.3K 5% 1/10W
47K 5% 1/10W
680 5% 1/10W
22K 5% 1/10W
4.7K 5% 1/10W
47K 5% 1/10W
1K 5% 1/10W
3.3K 5% 1/10W
3.3K 5% 1/10W
10K 5% 1/10W
47K 5% 1/10W
8.2K 5% 1/10W
47K 5% 1/10W
47K 5% 1/10W
(LOW BOOST (40 Hz))
10% 25V
10% 25V
4.7K 5% 1/10W
4.7K 5% 1/10W
4.7K 5% 1/10W
