Prince Castle UHCMAX Pre-Installation Manual

READ ALL INSTRUCTIONS BEFORE INSTALLING AND USING THE MACHINE
SAFETY INFORMATION
These appliances are intended to be used for commercial
applications, for example in kitchens of restaurants, canteens,
hospitals and in commercial enterprises such as bakeries,
butcheries, etc., but not for continuous mass production of
food. Appliance shall not be cleaned with a water jet or a
steam cleaner. Keep the unit away from running water. Follow
instructions when performing any cleaning or maintenance.
This appliance can be used by persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction
concerning use of the appliance in a safe way and understand
the hazards involved.
This appliance shall not be used by children.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
without supervision.
Plug unit in. Plug unit into a grounded receptacle with a
matching plug configuration.
All electrical connections must be in accordance with local
electrical codes and any other applicable codes.
If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent, or similarly qualified persons
in order to avoid hazards.
To prevent an electric shock hazard, this device must be
bonded to equipment in close proximity with an equipotential
bonding conductor. This device is equipped with grounding lug
for this purpose and is marked with the symbol above.
Two man lift, unit weight 90.72 kg (200 lbs). Appliance
designed to be placed on a McDonald's specified table.
Possible slippery floor adjacent to the appliance.
PN: 547-514 (Rev B)
Updated: 05/21
PRE-INSTALLATION GUIDE
•
•
•
•
•
•
•
Ground lug
symbol
Indicates information important to the proper operation of the
and/or severe bodily injury or death.
P
product design without notice. Such revisions do not entitle the
buyer to corresponding changes, improvements, additions or
replacements for previously purchased equipment.
Ratings: 208-240V, 2600 - 3450W, 50/60Hz.
Distance from the back wall at least 15.24 cm (6 inches).
Page 1 of 11
WARNING / CAUTION
Do not install on or near a combustible material.
For NA version, do not connect to a circuit operating at
more than 150 volts to ground.
For continued protection against the risk of fire, replace
main unit fuse with fuse of same type and rating: 3A 250V
To reduce the risk of fire or electric shock, do not remove
the top cover. No user-serviceable parts inside. Repair
should be done by authorized service personnel only.
Electric Shock Hazard. Disconnect from power before
servicing.
NOTICE
Do not lift unit by the top cover or at end caps. Do lift unit
at center of heater plate.
Do not place objects weighing more than 13.61 kg (30
lbs) on the top of this unit.
IMPORTANT
unit. Failure to observe may result in damage to the equipment
rince Castle reserves the right to change specifications and
ELECTRICAL SPECIFICATIONS
