TRI-FOLD LOAD RAMPS
Models
Product sold as a pair packaged in one container
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVe THIS MAnuAL.
Copyright
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
96513 - 6' x 9" 96514 - 6' x 11"
OPeRATIng InSTRucTIOnS
Distributed exclusively by Harbor Freight Tools
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our website at: http://www.harborfreight.com
2007 by Harbor Freight Tools
©
. All rights reserved. No portion of this
®
.
®
Advertisement
Table of Contents
Related Manuals for Harbor Freight Tools 96514
Summary of Contents for Harbor Freight Tools 96514
-
Page 1: Operating Instructions
TRI-FOLD LOAD RAMPS Models 96513 - 6' x 9" 96514 - 6' x 11" OPeRATIng InSTRucTIOnS Product sold as a pair packaged in one container Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. -
Page 2: Specifications
66” L X 8” W Perforated Steel 6’ x 9” 30.5 lb. (Each Ramp) 1 Per Ramp SAVe THIS MAnuAL Inspect Ramps periodically, and if damaged, have them 96514 66” L X 9” W Perforated Steel 6’ x 11” 33.1 lb. (Each Ramp) Page 2... - Page 3 When unpacking, check to make sure the parts listed at the end of this manual are included. If any parts are missing or broken, please call Harbor Freight Tools at the number on the cover of this manual.
-
Page 4: Operation
Flange Tongue Warning! In the following assembly process, the flange pictured must face down with the Tongue (10) edge fully contacting the tailgate. It is designed to keep the Ramps from moving once the weight of the load is riding on the ramp. Refer to the Assembly Drawing near the end of this manual. - Page 5 Chain Adjustment: Remove the bolt and washer that hold the safety chain to the ramp. Reinsert the bolt through a link that will shorten the chain so the loading ramp can not be pulled backwards by the ATv’s rear tire. Make sure that the bolt is properly tightened and the washer prevents the bolt from slipping through the chain link.
- Page 6 • THIS RAMP IS FOR uSe WITH 2 OR 4-WHeeLeD ATV’S OnLy. DO nOT uSe THIS RAMP TO unLOAD 3-WHeeLeD VeHIcLeS. • DO nOT uSe THIS RAMP TO unLOAD Any VeHIcLe THAT WeIgHS MORe THAn 1000 Lb. • DO nOT uSe THIS RAMP TO unLOAD Any VeHIcLe THAT IS WIDeR THAn THe RAMPS, ADjuST THe RAMPS by MOVIng THe ATV cLOSe TO THe HAuLIng VeHIcLe AnD ADjuSTIng THe WIDTH beFORe PuTTIng Any WeIgHT On THe TRI-FOLD RAMPS.
-
Page 7: Maintenance
Never attempt to load any dirt bike or other 2-wheel motor bike alone. Always have a qualified adult to assist. Line up the 2-Wheel bike with one of the Tri-Fold Ramp sections. With one person pushing the bike slowly up the Ramp, a helper should be in the bed of the hauling vehicle both to guide and to apply the brake if it is necessary to stop the bike while it is on the ramp. -
Page 8: Limited 90-Day Warranty
LIMITeD 90 DAy WARRAnTy Harbor Freight Tools Co. makes every effort to assure that its products meet high quality and durability standards, and warrants to the original purchaser that this product is free from defects in materials and workmanship for the period of 90 days from the date of purchase. This... -
Page 9: Parts List
When ordering replacement parts, specify which sku the parts are for. note: Part Lower Ramp Hinge Hinge Middle Ramp Upper Ramp Bolt M8 X 20 with Washer and Nut Bolt M10 X 30 with Nut Handle (Attaches to Hinge between part 1 and part 4) Jacket of the Handle Tongue Bolt M8 X 20 with Washer and Nut... - Page 10 ReV 07l SKU 96513/14 For technical questions, please call 1-800-444-3353. Page 10...
