Summary of Contents for Haier L32A9
- Page 1 OWNER`S MANUAL Please READ this manual carefully before operating your TV, and retain it for future reference LCD TV L26A9 MODEL: L32A9...
- Page 3 Know these safety symbols This “bolt of lightning” indicates uninsulated material within your unit may cause an electrical shock. For the safety of everyone in your household, please do not remove product covering. The “exclamation point” calls attention to features for which you should read the enclosed literature closely to prevent operating and maintenance problems.
-
Page 4: Important Safety Instructions
Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any of the ventilation openings. Install in accordance with the manufacturers instructions. Do not Install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. -
Page 5: Precaution
Precaution ADDITIONAL SAFETY PRECAUTIONS • Ensure that LCD TV stand is tightened properly to the set on the right way of tightening of the screw of the stand to the set. Improper tightening of screw may render the set unsafe. •... -
Page 6: Table Of Contents
Contents Guide for Preparatory Work IMPORTANT SAFETY INSTRUCTIONS ... 2 Read before operating equipment ... 2 Precaution ... 3 Panel control and rear terminal control ... 5 Preparation of remote control ... 7 Descriptions of remote control function ... 8 Connection and preparation of the TV set ... -
Page 7: Panel Control And Rear Terminal Control
Panel control and rear terminal control Explanations: The following illustration is for your convenience to recognize where all terminals are located and to connect peripheral equipment; due to the product improvement, the indications may be different from the actual one. The actual indications shall prevail. Side control panel Explanations on the keys on the side of the TV set and their functions... - Page 8 Panel control and rear terminal control Side CVBS and rear terminals 26” 32” Explanations on the rear terminals and their functions: COMPONENT: Color aberration component (YCbCr, YPbPr) Video/ Audio Input Terminal AUDIO: VGA audio input terminal PC IN: VGA video input terminal CVBS 1 IN: CVBS-1 audio/video input terminal S-VIDEO: Video input terminal (the audio is used the same way as CVBS-2 IN audio)
-
Page 9: Preparation Of Remote Control
Preparation of remote control Installation of remote control batteries •• As shown in the following diagram, put the remote control upside down and push open the battery chamber. •• Insert 2 AAA batteries as shown in the following diagram.(The positive and negative poles must correspond to the indication). -
Page 10: Descriptions Of Remote Control Function
Descriptions of remote control function Using remote control Note:Pressing most buttons once will activate the assigned function. Pressing a second time will de-activate it. When a button enables multiple options, a small list will be shown. Press repeatedly to select the next item in the list. - Page 11 TELETEXT TELETEXT The key does not work. The key does not work. SIZE The key does not work. SUBPAGE The key does not work. INDEX The key does not work. SUBTITLE The key does not work. HOLD The key does not work. REVEAL The key does not work.
-
Page 12: Connection And Preparation Of The Tv Set
Connection and preparation of the TV set Mounting the seat Take the TV set and its seat out of the carton, and assemble them with the screws in the accessory box as shown in the following diagram: Put the TV set on the soft cloth or cushion on the desktop with the face downwards.Place the seat on a secure plane surface. -
Page 13: Backboard Singal Source Interfaces
Backboard singal source interfaces There are a lot of signal sources that can be connected to your TV set. The following diagram shows how to connect them. Friendly tips: If you want to hang the TV set on a wall, all connecting lines must be inserted into the ports of the TV set in advance. -
Page 14: Side Signal Source Interfaces
Side signal source interfaces CVBS 2/ S-VIDEO IN Earphone socket: The user may use the earphone via the earphone socket. CVBS-2 /S-VIDEO input: Connect the VIDEO outputs or S-VIDEO outputs of DVD player, LCD player, video recorder or video camera, etc. to the VIDEO input or S-VIDEO input of the TV set. -
Page 15: Preset And Watch Tv
Preset and watch TV The following is how to use the On/Off key ( off the TV set. (Press the key Channel +/- in standby mode may power on the unit, its the same for the side panel and the remote control. Power On/Off 1. -
Page 16: Menu Operation
Menu operation Pressing the menu button may display or exit the main menu. In the main menu, you may use the functional options to be adjusted by moving up or down, press the > to enter the sub-menu adjustment, and press the menu key to exit the main menu. -
Page 17: Image Setting
Menu operation I. Image setting Video preset: Provide five image setting modes including Personal, Standard, Vivid, Movie, enco. You can adjust the "Contrast, Brightness, Color and Sharpness" to your taste only in the Personal mode. Contrast: Make the dark color in the black portion of the image enricher and make the white color brighter. -
Page 18: Sound Setting
Menu operation II. Sound setting Audio preset: Three output sound modes can be set, i.e. Personal, Music and speech. In the speech and Music modes, it is impossible to adjust Bass and Treble, while in the Personal mode, you may set the audio output effect by adjusting the Bass and Treble to your taste. -
Page 19: Function Setting
Menu operation III. Function setting Menu language: Set the menu language. Defaulted as English. Menu timeout: Options including 10, 20, 30, 40, 50 and 60 seconds are available for you to set the menu timeout. Sleep timer: Set the time interval for the TV set to enter standby mode automatically. -
Page 20: Channel Setting
Menu operation IV. Channel setting (the following menus only appear in the TV mode) Auto search: Search and store program automatically; press the "Menu" key to exit the Auto search mode. Update search: Save the stored program and start a new search; Press the "Menu" key to exit the Update search mode. -
Page 21: Vga Setting
Menu operation AFC: It can be set to On and Off. While it is set to On, the TV set will detect the TV signal automatically, and in case of offset of the signal within a certain range, it can adjust the channel to the correct position. -
Page 22: Using Remote Control Function
Using Remote Control function ■ Mute, freezing and playback In case an important guest visits you or you receive an incoming call Mute setting while watching TV program, you can simply press the Mute key on the remote control to turn off the sound of TV program.Pressing the "Mute" key or the Vol + key again may restore the sound. -
Page 23: Troubleshooting
Troubleshooting Trouble Shooting Tips Symptoms Items to Check and Actions to follow “Ghost” or double images Using a highly directional antenna may improve the picture. No power and turn on the television again. No picture No picture and power switched on clearance around the vents of the device to be certain there are no blocking walls or cabinets which would limit the air flow. -
Page 24: Glossary
Glossary Aspect Ratio The ratio between the width and height of the TV picture on the screen. In a normal TV set the aspect ratio is 4 to 3 (4:3). The new aspect ratio in HDTV is 16:9 which resembles the aspect ratio in a movie theatre (Widescreen). -
Page 25: Care And Cleaning
Care And Cleaning WARNING concerning stationary images on the TV Screen: Do not leave fixed images on the screen for extended periods of time. This can cause uneven aging of the LCD panel. Normal use of the TV should involve viewing of programs that have constantly moving or changing images. -
Page 26: Product Specif Cations
Wide x Height x Thickness (excluding the seat) (including the seat) Net weight (excluding the seat) L26A9 L32A9 660mm diagonal 800mm diagonal Color system: Auto, PAL, NTSC, SECAM, NTSC Sound system: DK, I, BG, M, AUTO FM, MONO, STEREO, BILINGUAL... -
Page 27: Product Specifications
Product specif cations This unit supports HDTV/SDTV(YPbPr/YCbCr) formats: Signal format 480i/480p 576i/576p 720p 1080i Input format of supported PC interface: Number Resolution 640*480@60Hz 800*600@60Hz 1024*768@60Hz 1280*720@60Hz 1360*768@60Hz (recommended) Input format of supported HDMI interface: Name of signal 480i/480p 576i/576p 720p 1080i Refresh frequency (Hz) 50/60... - Page 32 Q41G26MV672 4A...
