Summary of Contents for Samsung CS20Q1
- Page 1 All manuals and user guides at all-guides.com COLOUR ELECT TELEVISION Owner’s Instructions Before operating the unit, please read this manual thoroughly, and retain it for future reference. REMOTE CONTROL ON-SCREEN MENUS PICTURE IN PICTURE TELETEXT FUNCTION (depending on the model)
-
Page 2: Safety Instructions
All manuals and user guides at all-guides.com Safety Instructions The following illustrations represent the precautions to be taken when using and moving your television. 35° 5° Do NOT expose the television to Do NOT expose the television to Do NOT expose the television to extreme temperature conditions direct sunlight. -
Page 3: Table Of Contents
All manuals and user guides at all-guides.com Contents N PREPARING YOUR TELEVISION Safety Instructions ..................Caution ......................Front Control Panel ..................Connection Panels ..................Infrared Remote Control (All Functions Except Teletext & PIP) ....Infrared Remote Control (Teletext & PIP Functions) ........Inserting the Batteries in the Remote Control.......... -
Page 4: Front Control Panel
All manuals and user guides at all-guides.com Front Control Panel (depending on the model) ➣ Buttons and markings are subject to change. STAND-BY/TIMER MENU DISPLAY CHANNEL SELECTION INDICATOR VOLUME ADJUSTMENT REMOTE CONTROL SENSOR POWER TV/VIDEO STAND-BY/TIMER SELECTION VOLUME ADJUSTMENT INDICATOR POWER MENU DISPLAY CHANNEL SELECTION... -
Page 5: Connection Panels
All manuals and user guides at all-guides.com Connection Panels ☛ This figure shows the Standard Connector-jack panel. The actural configuration on your TV may be different, depending on the model. Side of TV Front of TV RCA AUDIO/VIDEO INPUT CONNECTORS HEADPHONE JACK (OPTION) RCA AUDIO/VIDEO INPUT... -
Page 6: Infrared Remote Control (All Functions Except Teletext & Pip)
All manuals and user guides at all-guides.com Infrared Remote Control (All Functions Except Teletext & PIP) ➣ Buttons and markings are subject to change. POWER DIRECT CHANNEL SELECTION ON-SCREEN DISPLAY PICTURE MENU DISPLAY AUTOMATIC SWITCH-OFF SOUND MODE SELECTION ONE/TWO-DIGIT CHANNEL SELECTION TURBO SOUND ON/OFF PICTURE STANDARD... -
Page 7: Infrared Remote Control (Teletext & Pip Functions)
All manuals and user guides at all-guides.com Infrared Remote Control (Teletext & PIP Functions) ➣ Buttons and markings are subject to change. PIP ON/OFF TELETEXT REVEAL PIP SWAP PIP LOCATE TELETEXT STORE PIP STILL TELETEXT HOLD TELETEXT SUB-PAGE FASTEXT TOPIC SELECTION TELETEXT DISPLAY/MIX LIST/FLOF MODE SELECTION TELETEXT NEXT PAGE... -
Page 8: Inserting The Batteries In The Remote Control
All manuals and user guides at all-guides.com Inserting the Batteries in the Remote Control You must insert or replace the batteries in the remote control when you : N Purchase the television. N Find that the remote control is no longer operating correctly. -
Page 9: Switching Your Television On And Off
All manuals and user guides at all-guides.com Switching Your Television On and Off The mains lead is attached to the rear of the television. Plug the mains lead into an appropriate socket. ➢ The main voltage is indicated on the rear of the TV set and the frequency is 50 or 60Hz. -
Page 10: Plug & Play Feature
All manuals and user guides at all-guides.com Plug & Play Feature When the television is initially powered ON, three basic customer settings proceed automatically and subsequently: setting the language, channel and clock. Plug & Play If the television is in Standby mode (red light visible on the Ant. -
Page 11: Viewing The Demonstration
All manuals and user guides at all-guides.com Viewing the Demonstration To become familiar with the various menus provided by your television, you can view the inbuilt demonstration. Picture œ œ Custom √ √ Mode Press the MENU button. √ √ Adjust Digital NR : Off... -
Page 12: Choosing Your Language
All manuals and user guides at all-guides.com Choosing Your Language When you start using your television for the first time, you must select the language which will be used for displaying menus and indications. Picture œ œ Custom √ √ Mode √... -
Page 13: Storing The Channels Automatically
All manuals and user guides at all-guides.com Storing the Channels Automatically You can scan the frequency ranges available on your television and in your area and store all the channels found automatically. Channel The channels are stored in the order in which they appear in the √... -
Page 14: Storing The Channels Manually
All manuals and user guides at all-guides.com Storing the Channels Manually When storing channels manually, you can choose: N Whether or not to store each of the channels found. Channel N The number by which you wish to identify each stored √... - Page 15 All manuals and user guides at all-guides.com Storing the Channels Manually (continued...) If you know the number of the channel to be stored, press the... L or M button to select the “Channel”. Manual store button. Color system : Auto 3.
-
Page 16: Giving Channels Names
All manuals and user guides at all-guides.com Giving Channels Names If you want edit the name, you can assign new names as required. Channel √ √ Auto store Press the MENU button. √ √ Manual store √ √ Name Press the L or M button to select the “Channel” and press the √... -
Page 17: Skipping Unwanted Channels
All manuals and user guides at all-guides.com Skipping Unwanted Channels You can exclude the channels of your choice from the channel scan operation. When you scan through the stored channels, those you have chosen to skip are not displayed. Channel √... -
Page 18: Fine Tuning Channel Reception
All manuals and user guides at all-guides.com Fine tuning Channel Reception If the reception is clear, you do not have to fine-tune the channel, as this is done automatically during the search and store operation. If however the signal is weak or distorted, you may have to fine- Channel tune the channel manually. -
Page 19: Sorting The Stored Channels
All manuals and user guides at all-guides.com Sorting the Stored Channels You can exchange the numbers of two channels, in order to: N Modify the numeric order in which the channels have Channel been automatically stored. √ √ Auto store N Give easily remembered numbers to the channels that √... -
Page 20: Changing The Picture Standard
All manuals and user guides at all-guides.com Changing the Picture Standard You can select the type of picture which best corresponds to your viewing requirements. The following picture effects are available in the order given: Picture œ œ Custom √ √ Mode N Custom, Standard, Sports, Natural, Mild. -
Page 21: Adjusting The Picture Settings
All manuals and user guides at all-guides.com Adjusting the Picture Settings Your television has several settings which allow you to control picture quality: Picture N Color tone, Contrast, Brightness, Color, Sharpness, Tint œ œ Custom √ √ Mode (NTSC only) √... -
Page 22: Activation/Deactivation The Digital Noise Reduction Feature
All manuals and user guides at all-guides.com Activating/Deactivating the Digital Noise Reduction Feature If the broadcast signal received by your television is weak, you can activate the Digital Noise Reduction feature to help reduce any static and ghosting that may appear on the screen. Picture œ... -
Page 23: Changing The Sound Standard
All manuals and user guides at all-guides.com Changing the Sound Standard (depending on the model) You can select the type of special sound effect to be used when watching a given broadcast. The following sound effects are available in the order given: Sound œ... -
Page 24: Adjusting The Sound Settings
All manuals and user guides at all-guides.com Adjusting the Sound Settings (depending on the model) The sound settings can be adjusted to suit your personal preferences. Sound œ œ Custom √ √ Mode √ √ Press the MENU button. Adjust Auto volume : Off Press the L or M button to select the “Sound”... -
Page 25: Extra Sound Settings
All manuals and user guides at all-guides.com Extra Sound Settings (depending on the model) The following sound settings can be adjusted to suit your personal preferences. Sound N Auto volume œ œ Custom √ √ Mode √ √ Adjust Each broadcasting station has its own signal conditions, Auto volume : Off and so it is not easy for you to adjust the volume every... -
Page 26: Selecting The Sound Mode
All manuals and user guides at all-guides.com Selecting the Sound Mode (depending on the model) The “S.MODE I-II” button displays/controls the processing and output of the audio signal. When power is switched ON, the mode is automatically preset to either “Dual-I” or “Stereo”, depending on the current transmission. -
Page 27: Selecting The Turbo Sound
All manuals and user guides at all-guides.com Selecting the Turbo Sound (depending on the model) Turbo sound suitably emphasizes both higher and lower bands of sound (and includes other effects). To enjoy more magnificent and dynamic sound when watching music, movie or other channel, simply press the TURBO button on the remote control. -
Page 28: Setting The Sleep Timer
All manuals and user guides at all-guides.com Setting the Sleep Timer You can select a time period of between 30 and 180 minutes after which the television automatically switches to Standby mode by pressing the “ SLEEP " button. Press the SLEEP button on the remote control. -
Page 29: Switching The Television On And Off Automatically
All manuals and user guides at all-guides.com Switching the Television On and Off Automatically You can set the On/Off timers so that the television will: N Switch on automatically and tune to the channel of your Time choice at the time you select Clock : 11 : 35 am N Switch off automatically at the time you select... -
Page 30: Setting The Blue Screen Mode
All manuals and user guides at all-guides.com Setting the Blue Screen Mode If no signal is being received or the signal is very weak, a blue screen automatically replaces the noisy picture background. If you wish to continue viewing the poor picture, you must set the Function “Blue screen”... -
Page 31: Picture In Picture
All manuals and user guides at all-guides.com Picture In Picture You can display a “Picture-In-Picture screen” within the main picture of TV program or Video input. In this way you can watch or monitor TV program or the Video input from any connected equipment while watching TV or other Video input. -
Page 32: Teletext Decoder
All manuals and user guides at all-guides.com Teletext Decoder Most television channels carry “teletext,” pages of written information that provide information such as: Television programme times News bulletins Weather forecasts Sports results Subtitles for the hard of hearing The teletext pages are organized according to six categories: Part Contents Selected page number. -
Page 33: Selecting A Specific Teletext Page
All manuals and user guides at all-guides.com Selecting a Specific Teletext Page Press the number buttons on the remote control to enter the page number directly: Enter the three-digit page number listed in the contents by pressing the corresponding numeric buttons. Result: The current page counter is incremented and the page is then displayed. -
Page 34: Using Flof To Select A Teletext Page
All manuals and user guides at all-guides.com Using FLOF to Select a Teletext Page The various topics included in the teletext pages are color-coded, and can be selected by pressing the colored buttons on the remote control. Display the teletext contents page by pressing the TTX/MIX button. Press the colored button corresponding to the topic that you wish to select (The available topics are listed on the status information line). -
Page 35: Connecting To The Av-1 Or 2 Input/Outputs
All manuals and user guides at all-guides.com Connecting to the AV-1 or 2 Input/Outputs ➣ These figures show typical connector-jack panels. The actual configuration on your TV may be different, depending on your model. ➢ AV-1 is used for equipment with an RGB output, such as video game devices and video disc players or a VCR. -
Page 36: Connecting To The Rear S-Video Input (Option)
All manuals and user guides at all-guides.com Connecting to the Rear S-VIDEO Input (Option) ➢ The S-VIDEO/RCA (AUDIO-L and R) connectors are used for equipment with an S-Video output, such as a camcorder or VCR. Rear of TV Camcorder (MONO) VIDEO L-AUDIO-R MONITOR... -
Page 37: Connecting To The Rca Input
All manuals and user guides at all-guides.com Connecting to the RCA Input ➢ The RCA connectors are used for equipment such as camcorders, video disc players and some video game devices. Side of TV Camcorder Video disc player Front of TV Decoder/ Video game device... -
Page 38: Connecting Headphones
All manuals and user guides at all-guides.com Connecting Headphones You can connect a set of headphones to your television if you wish to watch a television programme without disturbing the other people in the room. Plug a set of headphones into the 3.5 mm mini-jack socket of the television. -
Page 39: Automatic Degaussing To Remove Colour Patches
Troubleshooting: Before Contacting Service Personnel Before contacting Samsung after-sales service, perform the following simple checks. If you cannot solve the problem using the instructions below, note the model and serial number of the television and contact your local dealer. - Page 40 All manuals and user guides at all-guides.com - AFTER SALES SERVICE - Do not hesitate to contact your retailer or service agent if a change in the performance of your product indicates that a faulty condition may be present. ELECTRONICS AA68-01179A (ENG)
