A Guide To Operating and Maintaining Your
Gas Heating/Electric Cooling Unit
NOTE TO INSTALLER
This manual should be left with the equipment owner.
FOR YOUR SAFETY
Do not store or use gasoline or other
flammable vapors and liquids in the vicin-
ity of this or any other appliance.
Improper installation, adjustment, alteration, serv-
ice or maintenance can cause injury or prop-
erty damage. Refer to this manual. For assistance
or additional information, consult a qualified in-
staller, service agency, or the gas supplier.
Model 48SS Without Base Rail Shown
Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Book 1 4
PC 111
Catalog No. 564-993
Tab
1a 6a
Combination Gas Heating/Electric Cooling Units
Printed in U.S.A.
FOR YOUR SAFETY
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas sup-
plier's instructions.
• If you cannot reach your gas supplier,
call the fire department.
Before performing recommended maintenance,
be sure gas supply and main power switch to
unit are turned off. Electrical shock could cause
personal injury.
Model 48SX With Optional Base Rail
Form 48SS,SX-3SO
Pg 1
48SS
48SX
5-98
Replaces: 48SS,SX-2SO
