ENERGY EFFICIENT IN-FLOOR CLEANING & CIRCULATING SYSTEM
INSTALLATION MANUAL
004-027-8775-00
REV00
ECN_1752
PUB 042319
295 East Corporate Place • Suite 100 • Chandler, AZ 85225
Toll Free: 1.800.621.5886 • Phone: 480.893.7607 • Fax: 480.753.3397
Paramount@1Paramount.com • www.1Paramount.com
US and Foreign patents and patents pending see
www.1paramount.com/about/patents/
1
Advertisement
Table of Contents
Related Manuals for Paramount Fitness ECOSYSTEM
Summary of Contents for Paramount Fitness ECOSYSTEM
- Page 1 ENERGY EFFICIENT IN-FLOOR CLEANING & CIRCULATING SYSTEM INSTALLATION MANUAL 004-027-8775-00 REV00 ECN_1752 PUB 042319 295 East Corporate Place • Suite 100 • Chandler, AZ 85225 Toll Free: 1.800.621.5886 • Phone: 480.893.7607 • Fax: 480.753.3397 Paramount@1Paramount.com • www.1Paramount.com US and Foreign patents and patents pending see www.1paramount.com/about/patents/...
- Page 2 Signal Words and Symbols Used In This Manual This Owner’s Manual and Installation Guide contains specific precautions and symbols to identify safety-related information. You will find DANGER, CAUTION, WARNING and NOTICE symbols which require special attention. Please read them carefully and follow these precautions as indicated! They will explain how to avoid hazards that may endanger you or persons using or maintaining your pool or spa.
-
Page 3: Table Of Contents
TABLE OF CONTENTS CONTENTS DESIGN & LAYOUT PRINCIPLE OF OPERATION....................................5 BENEFITS OF THE SYSTEM ....................................5 SURFACE RETURNS ......................................5 PROPER NOZZLE PLACEMENT ...................................5 NOZZLE PLACEMENT CRITERIA .................................5 NOZZLE PLACEMENT .......................................6 SUBMITTING DRAWING TO PARAMOUNT .............................6 DIMENSIONED NOZZLE PLACEMENT DRAWING ..........................7 PUMP REQUIREMENTS ....................................8 IN-FLOOR SYSTEM SPECIFICATION CHART ............................8 FILTER REQUIREMENTS SELECTING PROPER FILTER SIZE ......................8 IMPORTANT TECHNICAL NOTICE REGARDING... - Page 4 TABLE OF CONTENTS STEEL DETAIL CONCRETE DETAIL GUNITE OR SHOTCRETE PROCESS ..............................20 PLUMBING FOR RIBBED BODY ................................20 PLUMBING FOR SMOOTH BODY ................................20 PREPLASTER DETAIL RIBBED BODY INSTALLATION GUIDE ..............................21 SMOOTH BODY INSTALLATION GUIDE ..............................22 START UP - REMOVE PRESSURE TEST PLUGS, INSTALL BASKETS & LIDS ...............23 SYSTEM START UP CLEANING NOZZLE INSTALLATION ................................24 ECO NOZZLE WITH TWIST LOCK CAP ..............................24...
-
Page 5: Design & Layout
DESIGN & LAYOUT PRINCIPLE OF OPERATION The IN-FLOOR SYSTEM cleans by injecting pressurized water through a series of nozzles located throughout the pool. The pressurized water flow keeps dirt in suspension for removal by the pool filtration system, an active main drain, a skimmer, and an optional in-deck debris canister. -
Page 6: Nozzle Placement
NOZZLE PLACEMENT STEP 1 - DRAW POOL SHAPE A scaled drawing of the pool must be made including the following details: A. Outline of pool shape B. All steps, benches, offsets, etc. C. Normal main drain location D. Break or transition point between shallow and deep end (if applicable) E. -
Page 7: Dimensioned Nozzle Placement Drawing
DIMENSIONED NOZZLE PLACEMENT DRAWING After the nozzle placement has been determined, a scaled drawing will be made with dimensions clearly indicated. The dimensioned drawing should be the plumber’s guide and a part of the superintendent’s check sheet to insure proper placement. -
Page 8: Pump Requirements
PUMP REQUIREMENTS Selecting Proper Pump Size 1. Determine GPM and Ft./Hd. requirements from Specification Chart below. 2. Refer to manufacturer’s pump curve for the equipment specified for the pool. 3. Compare Part # and Model #. Do not rely on horsepower. Most manufacturers make both full-rated and up-rated pumps This also relates to low and high service factors. -
Page 9: Equipment Layout
EQUIPMENT LAYOUT Single Pump CIRCULATION SYSTEM PUMP_____ GPM_____HD MIN. FILTER HEATER CART. 130 D.E. 48 SAND 49 OPTIONAL EDC CANISTER MDX-R3 DEBRIS DRAIN... -
Page 10: Plumbing Detail
PLUMBING DETAIL PLUMBING (FLOOR) Install the SYSTEM with required feed lines from the water valve to banks of heads containing two or more nozzles each. The feed lines are 2” Schedule 40 PVC pipe. Paramount recommends that the lines enter at the center of length of pool. Excavate a niche to the bottom of the pool depth at that location. -
Page 11: Nozzles On A Line
Nozzles will not rotate dependably if plumbing directive is not followed NOTICE Do not plumb nozzles in line, all nozzles must be on a branch INCORRECT METHOD OF PLUMBING 2 NOZZLES ON A LINE 3 NOZZLES 4 NOZZLES... -
Page 12: Plumbing Water Valve
PLUMBING WATER VALVE GLUING INSTRUCTIONS 1. Remove Clamp 8. Reposition o-ring in groove in the valve base. 2. Lift off dome (save 0-ring) 9. Replace dome and V-Clamp and tighten until snug. 3. Remove pressure gauge and knob from inside valve 10. -
Page 13: Valve Circuit Layout
OPTION TWO • (2) 2”X12” PVC PIPE (port 3,6) • (2) 2”X15” PVC PIPE (port 2,4) • (2) 2”X18” PVC PIPE (port 1,5) • (1) 2”X21” PVC PIPE (port inlet) • (2) 2”X2 1/4” PVC PIPE (port 6) • (8) 2” SLIP 90° elbows •... -
Page 14: Plumbing Heaters
PLUMBING HEATERS FROM FROM SKIMMER MAIN DRAIN BALANCING VALVE BALANCING VALVE PUMP FILTER CHECK BACKWASHING VALVE VALVE CHECK VALVE 1” BYPASS HEATER IMPORTANT LINE MANUAL 1” BYPASS LINE WATER VALVE HEATERS When installing a heater on the pool, a 1" PIPE OR GATE VALVE BY-PASS TO PARTIALLY DIRECT WATER AROUND THE HEATER IS NECESSARY. -
Page 15: Plumbing Debris Canisters
PLUMBING DEBRIS CANISTERS PLUMBING FILTER/CLEANER PUMP Single Pump System OPTIONAL EDC CANISTER RETURN FROM OPTIONAL SPA LINE PUMP 10-15 GPM 2" PVC 2" PVC 2½" PVC MDX-R3 DEBRIS DRAIN OPTIONAL DDC2 DECK CANISTER SDX2 Apply primer twice before gluing EQUIPMENT SIDE pipe or fittings to EDC canister DEBRIS CANISTER Install 3 Way Valve... -
Page 16: Canister Plumbing Detail & Pressure Test
CANISTER PLUMBING DETAIL & PRESSURE TEST The DDC2 patented debris canister is unique in that the lid is a water sealed lid. NOTE; Because of this the canister has a socket for a 1½" equalizer line that must be plumbed through the pool wall with a 1½" straight pipe. There are two other sockets one on each side of the equalizer line. -
Page 17: Pool Drain System
POOL DRAIN SYSTEM Indicates a hazardous situation which, if not WARNING avoided, could result in death or serious injury. The drain used must be installed in accordance with the manufacturer’s written instruction manual, and in conformity with applicable Federal, State, Local and Swimming pool industry building and safety codes. Consult the Paramount MDX-R3 VGB Compliant Debris Drain for specific instruction on how to plumb. -
Page 18: Plumbing Nozzle Bodies
PLUMBING NOZZLE BODIES NOTICE 1” BY 1” CUTOUT 2” SCH 40 PIPE, AROUND THE PIPE 15” LONG FOR WATER STOP All risers must be 90 degrees (perpendicular) to the finished floor CONCRETE CUT PIPE HERE PLUMBING FOR RIBBED BODY SOIL 2”... -
Page 19: Plumbing Nozzle Placements
PLUMBING NOZZLE PLACEMENTS 8' MAX 8' MAX 2. Nozzles should be pulled out as far as possible in order to reach corners. 3. Reversed radius* of step corners will help to eliminate dirty steps. * This will also help with the floor cleaning where the bottom step meets the pool wall. Heads 2”... -
Page 20: Steel Detail
STEEL DETAIL Rebar must be kept away from 2” PVC riser. Rebar should be bent around any riser or pipe so that steel is minimum of 2” away from the pipe. CONCRETE DETAIL GUNITE OR SHOTCRETE PROCESS CONCRETE: 1. Make a cutout or opening approximately 1” deep and 1” bigger than the pipe. 2. -
Page 21: Preplaster Detail
PREPLASTER DETAIL RIBBED BODY INSTALLATION GUIDE NOTICE Heavy body glue is required. Make a cutout or opening Cut off riser pipes flush with concrete Remove cap. Prime the inside of the pipe. approximately 1” deep and 1” bigger surface. NOTICE DO NOT PRIME than the pipe. -
Page 22: Smooth Body Installation Guide
SMOOTH BODY INSTALLATION GUIDE NOTICE You can use regular PVC glue on smooth body Make a cutout or opening Cut off riser pipes flush with concrete Remove cap. Prime the inside of the pipe. approximately 1” deep and 1” bigger surface. -
Page 23: Start Up - Remove Pressure Test Plugs, Install Baskets & Lids
START UP - REMOVE PRESSURE TEST PLUGS, INSTALL BASKETS & LIDS 1. Remove all pressure test plugs. 2. Install all baskets and lids. WARNING Indicates a hazardous situation which, if not avoided, could result in death or serious injury. Turn off pump before installing valve Do not stand over valve Valve Installation... -
Page 24: System Start Up
SYSTEM START UP CLEANING NOZZLE INSTALLATION Before installing nozzles flush all lines by: a. Start pump, run for 10 minutes before installing the water valve module. b. Install the water valve module and let valve cycle to flush out any debris remaining in each line. ECO NOZZLE WITH TWIST LOCK CAP 1. -
Page 25: Winterizing Instructions
WINTERIZING INSTRUCTIONS WINTERIZATION PROCEDURE FOR IN-FLOOR SYSTEM There are many methods to winterizing a pool and pool equipment. Different methods are used depending on regional conditions. It is the pool operator’s responsibility to ensure all components of the pool and pool equipment are protected from the most severe freeze conditions in their specific area. -
Page 26: Winterization Procedure For Equipment Side Debris Canister
WINTERIZATION PROCEDURE FOR EQUIPMENT SIDE DEBRIS CANISTER The EDC canister must be winterized in areas prone to freezing temperatures. 1. Remove the EDC canister lid and basket (and optional fine mesh bag). 2. Use a wet or dry vacuum to remove all the water from the EDC. 3. -
Page 27: Troubleshooting
TROUBLESHOOTING IN-FLOOR CLEANING SYSTEM TROUBLE SHOOTING ISSUE SOLUTION The system doesn’t clean like it has previously • If the nozzles are turning on and off in groups, but don’t clean as far as they once did, then the in-floor system isn’t getting enough water to run effectively. A quick way to check this is by looking at the pressure gauge, it needs to be 9-10 PSI or above. - Page 28 Clean area around one zone only When one set of Nozzles comes on with the pump each day, but never rotates more than once a day, the Water Valve isn’t cycling. • “Pause” Mode may be active. Turn the Knob on top of the Water Valve to “RUN”.
-
Page 29: Product Part Numbers
PRODUCT PART NUMBERS Item Part Number Description 004-527-5080-XX ECO nozzle with caps 005-527-5090-XX ECO Nozzle Caps (2 Pieces - 1/4”, 7/16”- 1 Each) 004-527-4120-XX ECO Ribbed Body with Plaster Cap 004-527-4762-XX ECO Smooth Body with Plaster Cap * Requires the use of a riser #005-252-1520-00 or 005-252-1522-00 004-552-5452-00 Small Nozzle Tool, Plastic Handle 004-252-5443-00... -
Page 30: Water Valve / Module
WATER VALVE / MODULE 005-302-3590-00 Pressure Gauge 005-302-3502-00 Pause Assembly Includes: Screw Knob, O-Ring & Pawl 005-302-4300-03 Top Dome Complete Includes: Top, Gauge & Pause Assembly Modules: 004-302-4408-00 6 Port 005-302-3570-00 Band Clamp (Complete) Includes Knob & Nut 005-302-3600-00 Band Clamp Knob 005-302-0640-00 Band Clamp Nut 005-302-0100-00...
