Memorex MSB310 Instructions

Bluetooth Party Speaker
MSB310 v2783-01
Important Safety Instructions
• Read these Instructions.
• Keep these Instructions.
• Heed all Warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in accordance with the
manufacturer's instructions.
• Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
• Do not defeat the safety purpose of the polarized or grounding -
type plug. A polarized plug has two blades with one wider than the
other. A grounding type plug has two blades and a third grounding
prong. The wide blade or the third prong are provided for your
safety. When the provided plug does not fit into your outlet, consult
an electrician for replacement of the obsolete outlet.
• Protect the power cord from being walked on or pinched particularly
at plugs, convenience receptacles, and the point where they exit
from the apparatus.
• Only use attachments/accessories specified by the manufacturer.
• Unplug this apparatus during lightning storms or when unused for
long periods of time.
• Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such
as power-supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
• Use only with a cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over.
FCC Warnings
Warning: Changes or modifications to this unit not expressly approved
by the party responsible for compliance could void the user's authority to
operate the equipment.
NOTE: This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
Features
• Bluetooth wireless - range 59 ft.
• Voice prompts announce speaker functions
• Two 8" full range speakers.
• LED light effects
• FM scan radio
• Microphone input
• Rotary volume control
• 3.5mm Aux in
• USB port - supports MP3 file format
• Carry handle
• Built-in rechargeable battery
• Battery life: approx. 5 hours at 50%
Control Panel
1. Power/Volume Wheel: Turn to power ON/OFF and adjust volume level
2. DC Power Input: Use to charge the internal battery and power the speaker. Charge
time is approximately 4 hours.
3. Charging Status LED: Solid red light when charging. When the unit is fully charged,
the light will turn off.
4. USB Media Port
5. Micro SD Port
6. Source/LEDs: Press to change audio source between Bluetooth, Aux in, USB, SD,
and FM. Press and hold to turn LED lights ON/OFF.
7. Next: Press to skip to next track. In FM Mode press to cycle through radio stations.
8. Play/Pause/Pair/Pair: Press to play/pause a track. In FM Mode press and hold to
start auto-search and save all scanned radio stations. Press and hold for 3 seconds
to manually pair to a Bluetooth device.
9. Previous/Connect: Press to replay previous track. In FM Mode press to cycle
through radio stations. Press and hold for 3 seconds to enter Party Plus mode which
will allow this speaker to pair with another ISB310 speaker for True Wireless Stereo.
10. Aux in (3.5mm Input)
11. Microphone Input
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses,
and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will
not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from
that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Additional Warnings and Precautions
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH WIDE BLADE
OF PLUG TO WIDE SLOT, FULLY INSERT.
• Mains plug is used as disconnect device and it should remain readily operable
during intended use. In order to disconnect the apparatus from the mains
completely, the mains plug should be disconnected from the mains socket
outlet completely.
• WARNING: Shock hazard - Do Not Open.
• CAUTION: Use of controls or adjustments or performance of procedures
other than those specified may result in hazardous radiation exposure.
• WARNING: Changes or modifications to this unit not expressly approved by
the party responsible for compliance could void the user's authority to operate
the equipment.
• WARNING: Do not place this unit directly onto furniture surfaces with any
type of soft, porous, or sensitive finish. As with any rubber compound made
with oils, the feet could cause marks or staining where the feet reside. We
recommend using a protective barrier such as a cloth or a piece of glass
between the unit and the surface to reduce the risk of damage and/or staining.
• WARNING: Do not ingest battery, chemical burn hazard.
• Battery shall not be exposed to excessive heat such as sunshine, fire or the
like.
• Lithium batteries, like all rechargeable batteries, are recyclable and should
be recycled or disposed of according to state and local guidelines. They
should never be disposed of in normal household waste and they should never
be incinerated, as they might explode. Contact your local government for
disposal or recycling practices in your area.
WARNING:
CAUTION
RISK OF ELECTRIC SHOCK
do not remove cover (or back). No user-serviceable
DO NOT OPEN
parts inside. Refer servicing to qualified service
ATTENTION
personnel.
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operating and maintenance (servicing)
instructions in the literature accompanying the
appliance.
The lightning flash with arrowhead symbol, within
an equilateral triangle, is intended to alert the
user to the presence of un-insulated "dangerous
voltage" within the product's enclosure that may
be of sufficient magnitude to constitute a risk of
electric shock to persons
This symbol indicates that this product incorporates
double insulation between hazardous mains voltage
and user accessible parts.
WARNING :
This product can expose you to
chemicals including lead, which is known to the State
of California to cause cancer and birth defects or
other reproductive harm. For more information go to
www.P65Warnings.ca.gov. This product meets and
complies with required Federal product guidelines.
MICRO SD
5
6
8
10
11
To reduce the risk of electric shock,
.
1
2
3
4
7
9
