Monogram ZDWI240 Installation Instructions Manual
Hide thumbs
Also See for ZDWI240:
- Installation instructions manual (24 pages) ,
- Owner's manual (20 pages) ,
- Installation instructions manual (8 pages)
Related Manuals for Monogram ZDWI240
Summary of Contents for Monogram ZDWI240
- Page 1 INSTALLATION INSTRUCTIONS with Design Guide Wine Chiller, Wine Reserve and Beverage Center MONOGRAM.COM...
-
Page 2: Safety Information
To reduce the risk associated with choking, do not allow children under 3 years of age to have access to small parts during the installation of this product. For Monogram local service in your area, call 800.444.1845 or visit monogram.com. For Monogram service in Canada, call 888.880.3030 For Monogram Parts and Accessories, call 800.444.1845 or visit monogram.com. - Page 3 Consignes de Sécurité AVERTISSEMENT Risque d’explosion. Conservez les matériaux et vapeurs inflammables de votre réfrigérateur. Le non-respect de cette instruction peut en- traîner un risque d’incendie, d’explosion ou de décès. AVERTISSEMENT petites pièces à la portée des enfants âgés de moins de 3 ans. BRANCHEMENTS ÉLECTRIQUES AVERTISSEMENT Risque d’électrocution.
-
Page 4: Table Of Contents
