Sealey FH2010.V2 Instructions

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
Indoor use only
instruction
manual
1. SAFETY
THIS PRODUCT IS ONLY SUITABLE FOR WELL INSULATED AREAS OR OCCASIONAL USE.
1.1. ELECTRICAL SAFETY
WARNING! It is the user's responsibility to check the following:
‰
Check all electrical equipment and appliances to ensure that they are safe before using. Inspect power supply leads, plugs and
all electrical connections for wear and damage. Sealey recommend that an RCD (Residual Current Device) is used with all electrical
products. You may obtain an RCD by contacting your local Sealey stockist.
If the multi-tool is used in the course of business duties, it must be maintained in a safe condition and routinely PAT (Portable
Appliance Test) tested.
Electrical safety information. It is important that the following information is read and understood.
1.1.1. Ensure that the insulation on all cables and on the appliance is safe before connecting it to the power supply.
1.1.2. Regularly inspect power supply cables and plugs for wear or damage and check all connections to ensure that they are secure.
1.1.3. Important: Ensure that the voltage rating on the appliance suits the power supply to be used and that the plug is fitted with the
correct fuse - see fuse rating in these instructions.
DO NOT pull or carry the appliance by the power cable.
8
DO NOT pull the plug from the socket by the cable. Remove the plug from the socket by maintaining a firm grip on the plug.
8
DO NOT use worn or damaged cables, plugs or connectors. Ensure that any faulty item is repaired or replaced immediately by a
8
qualified electrician.
1.1.4. This product is fitted with a BS1363/A 3 pin plug.
If the cable or plug is damaged during use, switch off the electricity supply and remove from use.
Replace a damaged plug with a BS1363/A 3 pin plug. If in doubt contact a qualified electrician.
Class II products are wired with live (brown) and neutral (blue) only are marked with the Class II symbol;
A) Connect the BROWN live wire to the live terminal 'L'.
B) Connect the BLUE neutral wire to the neutral terminal 'N'.
C) After wiring, check that there are no bare wires and ensure that all wires have been correctly connected.
Ensure that the cable outer sheath extends inside the cable restraint and that the restraint is tight.
DO NOT connect either wire to the earth terminal.
8
Sealey recommend that repairs are carried out by a qualified electrician. If an extension reel is used it
should be as short as possible and fully unwound before connection. A reel with an RCD fitted is preferred
since any appliance plugged into it will be protected. The cable core section is important and should
be at least 1.5mm², but to be absolutely sure that the capacity of the reel is suitable for this product and for
others which may be used in the other output sockets, we recommend the use of 2.5mm² section cable.
1.2. GENERAL SAFETY
WARNING! Disconnect the heater from the mains power, before servicing or performing any maintenance. Servicing or maintenance
‰
must only be carried out by an authorised service agent.
Check that the heater is in sound condition and good working order. Take immediate action to repair or replace damaged parts.
9
WARNING! DO NOT use the heater near flammable material, liquids, solids, gases or compressed gas cylinders etc.
‰
DO NOT allow any untrained or incompetent persons use the heater. Ensure they are familiar with the controls and hazards of the
8
heater.
DO NOT allow children to touch or to operate the heater
8
DO NOT obstruct the air inlet or outlet on the heater.
8
DO NOT cover the heater.
8
DO NOT operate the heater when you are tired or under the influence of alcohol, drugs or intoxicating medication.
8
DO NOT touch the heater casing or grill when first switched off as these are hot and will take time to cool.
8
DO NOT use the heater for anything other than its intended purpose. It is not suitable for drying clothes or laundry.
8
DO NOT place the heater close to a bath, wash basin, shower, swimming pool or any other water-filled area or wet surface.
8
DO NOT get the heater wet or use in areas of high condensation.
8
DO NOT place the heater up against any surface such as a wall, door or furniture etc.
8
DO NOT place the heater immediately below any electrical outlet.
8
DO NOT allow the power lead to lie in front of the heater outlet.
8
DO NOT attempt to repair a damaged heater, contact an authorised service agent.
8
DO NOT stand on the heater.
8
© Jack Sealey Limited
FAN HEATER 2000W 2 HEAT SETTINGS WITH
THERMOSTAT
FH2010.V2
MODEL NO:
DO NOT
cover
Original Language Version
Recommended fuse rating
10 Amp
FH2010.V2 Issue:4 (1) 20/01/21
