laguna Smart Shop M2 Owner's Manual

3 phase power
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Smart Shop:
Smart Shop "M" Maker 2 - 3 Phase Power
User Guide for the Smartshop Machines equipped with the RichAuto B57E (HHC) Handheld Controller
Basic Operations, Quick Start, Multi
Tool Programs, Creating a G Code File with
V-Carve, Maintenance & Troub le Shooting, Installation Online, Default Settings.
Owner's Manual
Laguna Tools
744 Refuge Way Grande Prairie, TX
Service: +1 (800) 234 1976
Email: customerservice@laguantools.com
Updated December 2021
Copyright Laguna Tools 2021

Advertisement

Table of Contents
loading

Related Manuals for laguna Smart Shop M2

Summary of Contents for laguna Smart Shop M2

  • Page 1 Tool Programs, Creating a G Code File with V-Carve, Maintenance & Troub le Shooting, Installation Online, Default Settings. Owner's Manual Laguna Tools 744 Refuge Way Grande Prairie, TX Service: +1 (800) 234 1976 Email: customerservice@laguantools.com Copyright Laguna Tools 2021 Updated December 2021...
  • Page 3 For immediate service on any Laguna Tools products: Call: +1 (800) 234 1976 Email: customerservice@lagunatools.com Laguna Tools, Inc. LAGUNA® and the LAGUNA Logo® are the registered trademarks of Laguna Tools, Inc. All rights reserved. 04/01/2019 LAGUNA AMERICAN HEADQUARTERS Texas: 744 Refuge Way Suite 200, Grand Prairie, Texas 75050, U.S.A. Phone: +1-800-332-4094 Huntington Beach: 7291 Heil Ave Huntington Beach, CA 92647, U.S.A.
  • Page 4 - without the written permission of Laguna Tools. Products that are referred to in this document are either trademarks and/or registered trademarks of Laguna Tools, Inc. The publisher and the author make no claim to these trademarks.

  • Page 5: Table Of Contents

    Contents Contents Safety Electrical Safety Safety Rules for Machinery Product Specifications Machine Overview Receiving Your Machine ....................18 Unboxing ........................... 20 Machine Placement ......................21 Operation Instructions Machine Set-up ......................... 24 Establishing Home Position ....................25 Basic Button Functions ...................... 26 Securing the Workpiece ....................
  • Page 6 Schematics ........................64 Creating a "G-Code File" using V-Carve Program m ing ................66 Appendix Exploded & Normal View ....................69 Dealer Warranty ........................ 70 CNC Limited Warranty ....................... 72 Maker Cheat Sheet ......................73 Contact Information ......................74 Laguna Tools 2021...

  • Page 7: Safety

    Smart Shop "M" Maker 2 Safety SAVE THESE INSTRUCTIONS Refer to them often and use them to instruct others. Please read and understand all warnings and operation instructions before using any tool or equipment. Always follow basic safety precautions to reduce the risk of personal injury. Improper operation, maintenance or modification of tools or equipment could result in serious injury and property damage.
  • Page 8 Smart Shop "M" Maker 2 - 3 Phase Power Important Safety Instructions Read and understand all warnings and operating instructions before using this equipment. Failure to follow all instructions listed below, may result in electric shock, fire, and/or serious personal injury or property damage. Woodworking can be dangerous if safe and proper operating procedures are not followed.
  • Page 9 Smart Shop "M" Maker 2 exposure level limits will vary from country to country.

  • Page 10: Electrical Safety

    Smart Shop "M" Maker 2 - 3 Phase Power Electrical Safety Grounding Methods Grounding Methods Provided by CSA Group. (A) Receptacle with nominal rating less than 150 volts. (B) 150 volt receptacle without grounding pin fitted with adapter. (C) 150-250 volt receptacle. 1.
  • Page 11 Smart Shop "M" Maker 2 3. Grounded, cord-connected tools intended for use on a supply circuit having a nominal rating between 150 – 250 volts, inclusive: This tool is intended for use on a circuit that has an outlet that looks like the one illustrated in Fig C. The tool has a grounding plug that looks like the plug illustrated in Fig C.

  • Page 12: Safety Rules For Machinery

    Smart Shop "M" Maker 2 - 3 Phase Power Safety Rules for Machinery PLEASE READ AND UNDERSTAND ALL SAFETY WARNINGS AND OPERATING INSTRUCTIONS BEFORE USING THIS MACHINE FAILURE to follow all instructions listed below, may result in electric shock, fire, and/or serious personal injury or property damage.Woodworking can be dangerous if safe and proper operating procedures are not followed.
  • Page 13 Smart Shop "M" Maker 2 THE MACHINE WITH RESPECT AND CAUTION WILL CONSIDERABLY LESSEN THE POSSIBILITY OF PERSONAL INJURY. HOWEVER, IF NORMAL SAFETY PRECAUTIONS ARE OVERLOOKED OR IGNORED, PERSONAL INJURY TO THE OPERATOR MAY RESULT. SAFETY EQUIPMENT SUCH AS GUARDS, PUSH STICKS, HOLD-DOWNS, FEATHER BOARDS, GOGGLES, DUST MASKS AND HEARING PROTECTION CAN REDUCE YOUR POTENTIAL FOR INJURY.
  • Page 14 Smart Shop "M" Maker 2 - 3 Phase Power MACHINERY TO REDUCE THE RISK OF EYE INJURY OR BLINDNESS FROM FLYING PARTICLES. EVERYDAY EYEGLASSES ARE NOT APPROVED SAFETY GLASSES. WEARING PROPER APPAREL. DO NOT WEAR CLOTHING, APPAREL OR JEWELRY THAT CAN BECOME ENTANGLED IN MOVING PARTS.
  • Page 15 Smart Shop "M" Maker 2 DESIGNED. NEVER STAND ON MACHINE. SERIOUS INJURY MAY OCCUR IF MACHINE IS TIPPED OR IF THE CUTTING TOOL IS UNINTENTIONALLY CONTACTED. STABLE MACHINE. UNEXPECTED MOVEMENT DURING OPERATION GREATLY INCREASES RISK OF INJURY OR LOSS OF CONTROL.

  • Page 16: Product Specifications

    Smart Shop "M" Maker 2 - 3 Phase Power Product Specifications...

  • Page 17: Machine Overview

    Smart Shop "M" Maker 2 Machine Overview...

  • Page 18: Receiving Your Machine

    Note any visible damage, torn packaging, scuffs or any abnormal marks on the delivery receipt or Sample Bill of Lading (BOL). Sample RMA **Any machines returned to Laguna Tools must be returned with packaging in the same manner in which...
  • Page 19 We require that the defective item/part be returned to Laguna Tools with the complaint. The end-user must request an RMA (Return Material Authorization) Numberfrom Customer Service and include the (RMA) number with any...

  • Page 20: Unboxing

    Smart Shop "M" Maker 2 - 3 Phase Power Unboxing Your Smart Shop M2 was carefully packaged for safe transport. The Smart Shop M should arrive packaged in a single wooden crate. When unpacking your machine, separate all enclosed materials to ensure that there are no damages to either the machine or the parts you’ve received.

  • Page 21: Machine Placement

    All shipping damage must be noted upon delivery and signed by the owner and the delivery driver. If you find any damaged items in your package, you must contact Laguna Tools to file a complaint. In order to return damaged goods under the limited warranty to Laguna Tools, Inc., you MUST have the original packaging. All claims of loss or damaged goods must be reported to Laguna Tools within 24 HOURS of delivery.
  • Page 22 Smart Shop "M" Maker 2 - 3 Phase Power LIGHTING: Ensure that the lighting your band saw is placed under is adequate enough that regular operation and maintenance can be performed safely. Any glares, shadows, or strobe lighting which may distract or prevent the operator from safely operating the machinery should be removed from the working area.

  • Page 23: Operation Instructions

    Smart Shop "M" Maker 2 Operation Instructions...

  • Page 24: Machine Set-Up

    Smart Shop "M" Maker 2 - 3 Phase Power Machine Set-up CNC Machine Smart Shop ll IMPORTANT: In order for installation to be efficient and cost effective we require several items to be completed PRIOR to our technician’s arrival. Should you have any questions please feel free to call our Customer Service at 1-800-234-1976 or contact your sales representative.

  • Page 25: Establishing Home Position

    Smart Shop "M" Maker 2 Establishing Home Position When the B57E HHC Handheld Controller is first powered on, the user will be prompted with the “HomeTypeAtStart” window. The machine needs to be homed each time the machine is powered & when positioning is lost. This resets your machine coordinates origin, relative to the home switches and flags.

  • Page 26: Basic Button Functions

    Smart Shop "M" Maker 2 - 3 Phase Power Basic Button Functions \The B57E HHC Rich-Auto Motion Control System uses 1-button and 2-button combination functions. Only the most used button functions are covered in this section and the sections on the following pages.

  • Page 27: Securing The Workpiece

    Smart Shop "M" Maker 2 Securing the Workpiece Mount Workpiece to the Tabletop a. This can be done with the supplied table clamps (See Photo Below). b. There exist a multitude of ways to secure your workpiece. Find what method works best for your application before proceeding.

  • Page 28: Tool Changing Procedure

    Smart Shop "M" Maker 2 - 3 Phase Power Tool Changing Procedure Tool Changing-Must have 90-95 PSI Air Pressure in System before continuing** 1. A tool can be inserted or removed in Two Ways. a) Manually -Using the “Red”Manual Tool Release Button” on the side of tool head. b) Automatically -Using the Tool Switch Button.

  • Page 29: Tool Changing

    Smart Shop "M" Maker 2 Tool Changing Tool Changing-Must have 90-95 PSI Air Pressure in System before continuing** “Verify that the machine is connected to an Air Supply.” 2a.) The tool changer needs 6 bar-6.5 bar or 87 psi-95 psi. 2b.)Use the pressure regulators (See Figures Below) on the back of the machine to adjust air pressure.

  • Page 30: Tool Changing

    Smart Shop "M" Maker 2 - 3 Phase Power 2a.) Press “Tool-Switch” button. Use Y+ & Y-Buttons to highlight tool selection (Tools are listed from Left to Right.). Machine will then switch from current Tool in Spindle to Tool Selected. Press REF/OK Button.

  • Page 31: Multiple Tool Program

    Smart Shop "M" Maker 2 Multiple Tool Program Tool Cone Set-Up This section is a work flow, from turning the machine on, to starting your program. This walk through assumes only TOOL 1 is used. 1.Power on Machine. 2.Home Machine. 3.Verify that the machine is connected to an air supply.
  • Page 32 Smart Shop "M" Maker 2 - 3 Phase Power 1.Select a router bit and its corresponding collet. ****Note-The collets & spindle nut must be cleaned regularly. Ensure that the slots in the collets are free of debris. 2. Press the collet into the spindle nut until it snaps into place. 3.
  • Page 33 Smart Shop "M" Maker 2...

  • Page 34: Multiple Tool Program (Cont'd)

    Smart Shop "M" Maker 2 - 3 Phase Power Multiple Tool Program (Cont'd) Setup a Tool Cone (Example 1) with the Router Bit one does intend to use. a.) Use the manual tool release button located on the tool head to load the tool cone into the spindle. b.) It is pertinent that the spindle releases and engages the tool cone repeatedly.

  • Page 35: Transfer "G" Code Program

    Smart Shop "M" Maker 2 Transfer "G" Code Program Transferring onto a USB and into the Controller's Internal Memory...
  • Page 36 Smart Shop "M" Maker 2 - 3 Phase Power...

  • Page 37: Loading Program To Cut Load Program

    Smart Shop "M" Maker 2 Loading Program to Cut Load Program...

  • Page 38: Setting "Xy" Work Origin

    Smart Shop "M" Maker 2 - 3 Phase Power Setting "XY" Work Origin Verify Coordinate System (Figure #1). a.) Workpiece 1 should be selected. Setting “XY” Work Origin SECTION (Cont’d.)-Verify Coordinate System (See Photo Illustration Below) Figure #1-Control Screen after Loading Program and Setting Work Origin. b.) If not in work piece, hold Menu&...
  • Page 39 Smart Shop "M" Maker 2 1.) Press & Hold Down “MENU” Button. 2.)Press“C+/1 Button”. Verify which tool cone is currently in the spindle and compare to the “CurSpindl” parameter on the controller run screen. If Current Tool Number is Not Tool #1, then switch tools using Tool Switch Function (See Basic Button Functions-Press “Tool Change Menu Button or Tool Switch Menu Button”).
  • Page 40 Smart Shop "M" Maker 2 - 3 Phase Power **Note: Tool 1 is needed, because Tool 1 is the Master Tool Bit.** Figure #1-Control Screen after Loading Program and Setting Work Origin. Jog the spindle to the “Program’s Origin Point”. This is determined by the CNC Program that was previously created.
  • Page 41 Smart Shop "M" Maker 2 Press the up Y+, and down Y-, right X+, left X-Buttons to Scroll or Jog up/down, right/left to the to the desired selected program. **Note: One must be in Work Piece Mode. Remember Origin=Office. One starts work @ the Office & not at home.**...

  • Page 42: Setting "Z" Work Origin

    Smart Shop "M" Maker 2 - 3 Phase Power Setting "Z" Work Origin a.) Set the Jog Speed to “Low” and carefully move the spindle down until the desired Z-Zero Position is obtained. Z-Zero position is determined by the software, either top of the material or bottom of the material. Verify speed on screen.
  • Page 43 Smart Shop "M" Maker 2 i.It may be helpful to use a sheet of paper by sliding it back and forth under the bit, while jogging the z-axis down. ii.Once the paper is snagged by the bit you know one is within a paper thickness (0.1mm) of your material. iii.Must set by using Tool #1.
  • Page 44 Smart Shop "M" Maker 2 - 3 Phase Power g.) In case of an emergency or machine failure you can hit the “E-STOP Button” on the control cabinet. ***[In most cases the “Stop/Cancel Button” on the Handheld Controller (HHC) is a preferred stopping method.]*** h.) Press the “RUN/PAUSE/DELETE Button”...
  • Page 45 Smart Shop "M" Maker 2 k.) Feed rate can be adjusted by pressing the Y+ or Y-buttons. i. Y+ will increase the feed rate by 10%. ii. Y-will decrease the speed by 10% iii. The max speed is determined by the program file. l.) Program End.

  • Page 46: Understanding The Work Coordinate System

    Smart Shop "M" Maker 2 - 3 Phase Power Understanding the Work Coordinate System Machine Coordinates (Workpiece 0). Coordinates are based off of the home switches, not the origin. Tool positions and TTO switch location are set relative to machine coordinates. Press “MENU + ZRN/0”...
  • Page 47 Smart Shop "M" Maker 2 Transitioning between workpieces will, in turn transition between X, Y, and Z offsets made in each Workpiece.

  • Page 48: Adding Tools And Touching Off

    Smart Shop "M" Maker 2 - 3 Phase Power Adding Tools and Touching Off Prepare the Machine: Prepare all tool cones for the job, and place into tools corresponding holders. Prepare all Tool Cones for the job, and place into Tools corresponding holders. Run procedure to calculate Tool Offsets.
  • Page 49 Smart Shop "M" Maker 2 Run procedure to calculate Tool Offsets (Cont’d.) Set XY Work Origin. Start with Tool 1, Tool 1 = Master Tool Bit. Press and hold the “MENU” button --> press “TOOLSET” button -->release both buttons. Once Tool 1 has touched off, Switch to Tool 2, using the Tool Switch button. Press and hold the “MENU”...
  • Page 50 Smart Shop "M" Maker 2 - 3 Phase Power Note: Cannot touch off plaining bits.

  • Page 51: Multiple Tool Program

    Smart Shop "M" Maker 2 Multiple Tool Program Touch Off Tool #1 and any subsequent Tools, after that, switch back to Tool #1 for manual Touch Off. Set Z work origin with Tool 1. Run Program.

  • Page 52: Setting Tool Offsets

    Smart Shop "M" Maker 2 - 3 Phase Power Setting Tool Offsets Place the designated tools into the corresponding tool holders on the machine, determined at the time of program creation. Change to workpiece 1 and tool 1(Changing Tools Section). Verify Workpiece 1.

  • Page 53: Setting The Origin/Xy Datum

    Smart Shop "M" Maker 2 Setting the Origin/XY Datum Set XY Work Origin.

  • Page 54: Set Z Work Origin

    Smart Shop "M" Maker 2 - 3 Phase Power Set Z Work Origin Set Z work origin with Tool 1.

  • Page 55: Run Program

    Smart Shop "M" Maker 2 Run Program Run Program.

  • Page 56: Understanding Work Coordinate Systems

    Smart Shop "M" Maker 2 - 3 Phase Power Understanding Work Coordinate Systems Machine Coordinates (Workpiece 0). Coordinates based off of the home switches, not the origin. Tool positions and TTO switch location are set relative to machine coordinates. Press “MENU + ZRN/0” to switch to “Workpiece 0”. Hold down the MENU + 1-9 Buttons to move between different origin points.
  • Page 57 Smart Shop "M" Maker 2...

  • Page 58: Maintenance & Trouble Shooting

    Smart Shop "M" Maker 2 - 3 Phase Power Maintenance & Trouble Shooting The Smartshop M uses Linear Guide Rails, Ball Screws, and Ball Bearings. These need to be lubricated periodically (Once a Week). Each Axis has 2 Guide Rails each. Keep machine free of the products chips & debris. **Note: Do to leave Spindle in the Tool for a prolonged period of time (Spindle could Rust into the tool over time).

  • Page 59: Resetting Tool Location & Tto Location

    Smart Shop "M" Maker 2 Resetting Tool Location & TTO Location Resetting Tool Location: Home the machine. This will reset the controller's machine coordinates, relative to the position of the home switches and flags. Verify the controller is in machine coordinates (workpiece 0). If not, press MENU+ZRN/0 to change to machine coordinates.
  • Page 60 Smart Shop "M" Maker 2 - 3 Phase Power Scroll down to ATC setup--> REF/OK. Scroll up to ATC position --> REF/OK Select Tool# desired Press Cancel Select desired Axis Press Run/Pause/Delete Input Valves Next desired Axis until all X, Y, & Z (Z-always input a “Negative Number”) is complete.

  • Page 61: Setting "Z" Work Origin-Tools Setting "Z" Adjustment

    Smart Shop "M" Maker 2 Setting "Z" Work Origin-Tools Setting "Z" Adjustment If the “ToolSettingZ” parameter needs to be adjusted follow this path. MENU --> Menu function user interface --> machine setup -->Toolset setup --> C.A.D. position --> select with REF/OK.button.

  • Page 62: Installation Outline

    Smart Shop "M" Maker 2 - 3 Phase Power Installation Outline...

  • Page 63: Default Machine Settings Protocols

    Smart Shop "M" Maker 2 Default Machine Settings Protocols...

  • Page 64: Schematics

    Smart Shop "M" Maker 2 - 3 Phase Power Schematics...
  • Page 65 Smart Shop "M" Maker 2...

  • Page 66: Creating A "G-Code File" Using V-Carve Programming

    Smart Shop "M" Maker 2 - 3 Phase Power Creating a "G-Code File" using V-Carve Programming...
  • Page 67 Smart Shop "M" Maker 2...

  • Page 68: Appendix

    Smart Shop "M" Maker 2 - 3 Phase Power Appendix HITECO SPINDLE PNEUMATIC SPECIFICATIONS:...

  • Page 69: Exploded & Normal View

    Smart Shop "M" Maker 2 Exploded & Normal View...

  • Page 70: Dealer Warranty

    Laguna Tools Customer Support Website. The labor required to install replacement parts is the responsibility of the user. Laguna Tools is not responsible for damage or loss caused by a freight company or other circumstances not in our control. All claims for loss or damaged goods must be notified to Laguna Tools within twenty-four hours of delivery.
  • Page 71 Smart Shop "M" Maker 2...

  • Page 72: Cnc Limited Warranty

    Tools Customer Support Website. The labor required to install replacement parts is the responsibility of the user. Laguna Tools is not responsible for damage or loss caused by a freight company or other circumstances not in our control. All claims for loss or damaged goods must be notified to Laguna Toolswithin twenty-four hours of delivery.

  • Page 73: Maker Cheat Sheet

    Smart Shop "M" Maker 2 Maker Cheat Sheet Common Errors: SW limit error. This means the machine has either of three issues: 1) The machine cannot move a specified amount. Either the origin needs to be moved or it is out of place. 2) There is an operator error using the software design.

  • Page 74: Contact Information

    Smart Shop "M" Maker 2 - 3 Phase Power Contact Information Laguna Tools Contact Information Should you have any questions please feel free to call our Customer Service at 1-800-234-1976 or contact your Customer Service or Sales Representative. LAGUNA AMERICAN HEADQUARTERS: Texas: 744 Refuge Way Suite 200, Grand Prairie, Texas 75050, U.S.A.
  • Page 75 LAGUNA AMERICAN HEADQUARTERS Texas: 744 Refuge Way Suite 200, Grand Prairie, Texas 75050, U.S.A. Phone: +1-800-332-4094 Huntington Beach: 7291 Heil Ave Huntington Beach, CA 92647, U.S.A. Phone: +1-949-474-1200 South Carolina: 825 Bistline Dr. Ste 101, West Columbia, SC 29172, U.S.A. Phone: +1-800-234-1976 Minnesota: 5250 West 74th St, Edina, MN 55439, U.S.A Phone: +1-949-474-1200...
