DVPDU-01 Digital Setup Display
1 WARNING
Please power down the MPU of the
PLC prior to install the DU-01, which
is connected via a high-density
connector. Also please read the
figures on the right for operation
correctly to prevent damage.
2 INTRODUCTION
DU-01 Digital Setup Display has two operation modes, TS-01 and
TC-01. The mode selection switch locates at the back of the
DU-01. Factory setting is TS-01 mode. The current operation
mode will be displayed every time when power up.
TS-01 TC-01
1. In TS-01 mode, DU-01 (specified as TS-01 hereof) has the following functions:
• Read/Write both the internal devices of PLC (e.g. perpetual calendar, bit devices (X, Y, M, S)
and word devices (T, C, D)) and the Control Register (CR) inside the extension units.
• Support the read/write 32-bit data register.
• Set Start-up display and power save mode.
• Monitor the devices.
• If connect the accessory cable to ES-series without perpetual calendar, the Time Display will
start from 00-00-00 calculated by the microprocessor of DU-01 (timing error may occur).
• Give RUN-STOP command to PLC.
2. In TC-01 mode, DU-01 (specified as TC-01 hereof) has the following functions for DVP all series:
• Read/write the program P, data register D and file register F from PLC.
• Copy program and data.
• Support the PLC password protection.
Overview of the Product - Names of Parts
1 5
2 6
3 7
4 8
9
ESC OK
DU-01
3
1. Direct mounting to the expansion slot in the MPU of
the EP/EH series
Instruction Sheet
Please power down the PLC MPU prior to install the DU-01,
which is connected via a high-density connector. Also please
refer to the figures above for proper operation.
face-up DU-01 slantly in the extension slot, then push it down
in arrow direction. DO NOT push it down vertically to prevent
damage.
4
1. Switch DU-01 to TS-01 mode. (Please see the back of the DU-01)
2. Main Process
Back of the DU-01
ESC
Device Selection
ESC
P: program area indication
1
(TC-01)
2 W: write (WR) indication (TC-01)
3 R: read (RD) indication (TC-01)
4 "In communication" indication
D: Data Register indication
5
(TC-01)
F: File Register indication
6
(TC-01)
CR: Control Register indication
7
(Extension Module)
8 ER: Error message display
3. Start-up display mode setting (press
9 Display Area
10 Enter button
indication
K (Decimal), H (Hexadecimal)
11
indication
Contacts & coils of timer /
12
counter indications
Word devices T, C, D, DD
(32-bit)
13
indication
14 Bit devices X, Y, M, S indication
15 Digit backspace / Run (TC-01)
16 Back to previous status
17 Enter number or select device
*Note: not include system operation mode setting
18 Confirm
19 Enter number or select device
4. Please see the back page for detail information about the process of each mode.
INSTALLATION & WIRING
2. Connecting to DVP
series PLC via accessory
cable
Put the
(No need to shut down the MPU)
TS-01 OPERATION
Time Mode
Press and hold for 3 sec. Press and hold for 3 sec.
ESC
Operation Mode
Auto Save
ESC
YY-MM-DD
Press and hold for 3 sec.
OK
Display
Selection
HH-MM-SS
No Save
ESC
Confirm & update time
OK OK
Device
Selection
X, Y, M, S
T, C, D
CR
DD(32-bit)
OK
Specify a number
Device
Monitor
OK
Press and hold for 3 sec.
Number Selection
Force On/Off setting
OK OK
Bit Monitor status of 8 consecutive
Device confirm
devices from the specified number
Device
ESC
ESC
to complete entering & return
Press
OK
Number Selection
OK
Press and hold for 3 sec.
OK OK
Word Specified No.
Device confirm
Device Display
ESC ESC ESC
+ buttons simultaneously)
Monitor
Press + +
Mode
Any mode*
Time & device Until
content
Sleep mode activated if no button is pressed
within 30 seconds
Sleep mode
5
1. Switch the DU-01 to TC-01
mode (please see the back of
the DU-01), and select RD (to
read P, D and F in the MPU of
PLC) or WR (to write the data
in P, D, F of DU-01 to the MPU
of PLC).
Note: P: Program, D: Data register, F: File register
2. TC-01 Password Key Setting
Password key setting of TC-01 can be set via WPLSoft. The purpose is to read/write to the key-locked
PLC as long as the password setting matches with the one in PLC. To unlock the password key
setting, please use WPLSoft as well.
a) Password Key Setting
In RD or WR mode, press ESC button and hold for 3 seconds or
more to enter password setting. See the figure on the right:
Open WPLSoft [Setting]
Select [Enter TC-01 password key], and operate as instructed.
After setting, display shows the figure on the right. (KEY SET),
then press ESC to exit.
b) TC-01 has password key setting, therefore, only if the PLC has no password protection or with the
same password with TC-01 can process the writing. It also writes the password to the PLC for
added protection.
c) Password key clear (KEY CLR): Same as the operation above. Open WPLSoft, select [TC-01
password key clear], and operate as instructed.
3. Clear P, D, F of TC-01: select the device (P, D or F) to be cleared, press
then press ESC.
4. RD mode description:
P(Program)
Reading P (Program).
You can press ESC to
pause reading.
Enter a number
Enter Set Value
Finish reading.
d1EC is the CHKSUM
of writing program
Finish reading
shows
TC-01 OPERATION
TC-01
Indication of the connected MPU model
Indication of internal data storage model
[TC-01 password key setting].
+ simultaneously,
RD read mode
+
P,D,F selection
Confirm
Device
D (Data Register) F (File Register)
Setting reading range.
Reading F (file register)
(default start & end
You can press ESC to
addresses are latched
pause reading.
area range. User can
re-set it.)
Enter start address
2746 is the CHKSUM
of writing data
Enter end address
Finish reading
Reading processing...
You can press ESC to
pause reading.
Finish reading
