ASROCK DN2800MT Settings Manual

*15G06X648001AK*
P/ N: 15G06X648001AK V1.0b
Jumpers and headers setting guide
DN2800MT
41
The terms HDMI™ and HDMI High-Definition
Multimedia Interface, and the HDMI logo are
40
trademarks or registered trademarks of HDMI
Licensing LLC in the United States and other
countries.
39
38
37
36
35
34
33
32
31
30
29
28
1 : 2-pin ATX Power Input/Output
Connector
2 : 2-pin UPS Module Power Input
Connector
1
3 : DC_CTL1
Power Input Voltage > +12V: Short
Power Input Voltage ≤ +12V: Open
4 : SATA Power Output Connector
5 : AMP_CTL1
PIN Signal Name
1 GPIO_VOL_DW
2 GND
3 GPIO_VOL_UP
6 : BLT_PWM1 (CON_LBKLT_CTL)
1-2: +3V
2-3: +5V
7 : LVDS Panel Connector
PIN Signal Name PIN Signal Name
2 LCD_VCC 1 LCD_VCC
4 LDDC_CLK 3 +3V
6 LVDS_A_DATA0# 5 LDDC_DATA
8 GND 7 LVDS_A_DATA0
10 LVDS_A_DATA1 9 LVDS_A_DATA1#
12 LVDS_A_DATA2# 11 GND
14 GND 13 LVDS_A_DATA2
16 LVDS_A_DATA3 15 LVDS_A_DATA3#
18 LVDS_A_CLK# 17 GND
20 GND 19 LVDS_A_CLK
22 LVDS_B_DATA0 21 LVDS_B_DATA0#
24 LVDS_B_DATA1# 23 GND
26 GND 25 LVDS_B_DATA1
28 LVDS_B_DATA2 27 LVDS_B_DATA2#
30 LVDS_B_DATA3# 29 DPLVDD_EN
32 GND 31 LVDS_B_DATA3
34 LVDS_B_CLK 33 LVDS_B_CLK#
36 CON_LBKLT_EN 35 GND
38 LCD_BLT_VCC 37 CON_LBKLT_CTL
40 LCD_BLT_VCC 39 LCD_BLT_VCC
All manuals and user guides at all-guides.com
1 2 3 4
SATA_PWR1
DC_JACK1
INT_DC1
USB 2.0
UPS_IN1
T: USB0
B: USB1
1
DC_CTL1
LAN1
SATAII_1
1
BAT1
1 SATAII_2
MSATA_SEL1
BIOS
Chip
USB 2.0
T: USB2
B: USB3
CI1
1
1
CLRCMOS1
1
CI2
HDMI1
DN2800MT
Line Out
1
CHA_FAN1
Mic In
AUDIO
SPEAKER1
CODEC
HD_AUDIO1
PCIE1
SPDIF1
1
1
26
27 25
8 : BLT_CTL1
PIN Signal Name
1 CON_LBKLT_EN
2 CON_LBKLT_CTL
3 LCD_BLT_VCC
4 LCD_BLT_VCC
5 GND
6 GND
7 GPIO_BLT_UP
8 GPIO_BLT_DW
9 : PNL_PWR1
PIN Signal Name
1 +3.3V
2 NC
3 LCD_VCC
4 +12V
5 +5V
6 NC
2
1
10 : BKT_PWR1
PIN Signal Name
1 +5V
2 NC
3 LCD_BLT_VCC
40 39
4 +Vin
5 +12V
6 NC
11 : Digital Input / Output Power select
1-2: +12V
2-3: +5V
5
1
AMP_CTL1
COM1 COM2
1 1
BUZZ1
1
LPT1
PS2_KB_MS1
CS1
1
1 DMIC1
1
1
TPM1
24 23 22 21 20 19 18
1 12 : Digital Input / Output
Pin Header
PIN Signal Name PIN Signal Name
10
8 SIO_GP03
6 SIO_GP02
4 SIO_GP01
2 SIO_GP00
13 : 4-Pin CPU FAN Connector (+12V)
1
14 : ATX/AT mode Selection
1-2: AT mode
2-3: ATX mode
15 : System Panel Header
USB2.0 Headers
1
16 : USB4_5
17 : USB6_7
18 : DMIC1
PIN Signal Name
1
2 DMIC_DATA
3
4 DMIC_CLK
3 2 1
5
6
1
BLT_PWM1
1
7
1
8
1
9
10
1
11
1
12
1
JGPIO1
13
CPU_FAN1
14
1
PWR_JP1
PANEL1
15
USB6_7 USB4_5
16
1 1
17
GND 9 JGPIO_PWR1
7 SIO_GP07
5 SIO_GP06
3 SIO_GP05
1 SIO_GP04
GND
+12V
CPU_FAN_SPEED
FAN_SPEED_CONTROL
3 2 1
1
+3V
GND
NC
