John Lewis
ELLIS ENTERTAINMENT WITH SHELF
Thank you for purchasing this Ellis entertainment with shelf. Please read the instructions carefully before
use to ensure safe and satisfactory operation of this product.
Pre-assembly preparation
Please ensure instructions are read in full before attempting to assemble this product.
Necessary Tools
A cross head screwdriver only should be used to assemble this Ellis entertainment with shelf , an electric drill
may cause damage to the product and is not recommended.
Please check the pack contents before attempting to assemble this product. A full checklist of components is
given in this leaflet. If any components are missing, please contact the retailer from whom you bought this
product.
This product takes approximately 40 MINUTES to assemble with 2 PEOPLE.
All assembly should be performed on a flat, stable, clean and soft surface.
The fitting pack contains SMALL ITEMS which should be KEPT AWAY FROM YOUNG CHILDREN.
IMPORTANT: Retain these instructions for future reference.
Stock Number: 87722751
Page : 1
IW-17-4335-252-0
Advertisement
Related Manuals for John Lewis 87722751
Summary of Contents for John Lewis 87722751
- Page 1 John Lewis ELLIS ENTERTAINMENT WITH SHELF Stock Number: 87722751 Thank you for purchasing this Ellis entertainment with shelf. Please read the instructions carefully before use to ensure safe and satisfactory operation of this product. Pre-assembly preparation Please ensure instructions are read in full before attempting to assemble this product.
- Page 2 Fittings and parts checklist Table top Side left Partition Bottom Side right Back panel Removable shelf Dowel Hex key Minifix housing Ø8 x 30 Ø 1 5 x 1 2.5 Minifix bolt Conformat Ø7 x 34 hex head screw Ø7 x 50 Shelf Pin Round cross head screw Ø3.5 x 15...
- Page 3 Step By Step Assembly Instructions Step 1 : Attach minifix bolts (B) into table top ( 1 ) as shown. Step 2 : Attach minifix bolts (B) into side panels left (4) and right ( 5 ) as shown. : Attach dowels (D) into side panels: left (4) and right ( 5 ) as shown. : Attach 4 x dowels (D) into the partition (7) as shown.
- Page 4 Step 4 : Attach partition ( 7 ) to bottom panel (2) with 2 x conformat hex head screws (E) and tighten with hex key (G) as shown. Fitting E x 2 Step 5 : Attach side panel - left (4) and right (5) onto bottom panel (2). Using 4 x minifix housings (A) as shown.
- Page 5 Step 6 : Attach top panel ( 1 ) to side panels: left (4) and right ( 5 ) and partition (7). Using 6 x minifix housing (A) as shown. Fitting Step 7 : Attach back panel (3) onto back side with 1 8 x round cross head screws (F) as shown. Page : 5 IW-17-4335-252-0...
- Page 6 1 : Place 8 x shelf pin (C) into side panels left (4), right ( 5 ) and partition (7) as shown. Step 8 2: Place removable shelfs (6) onto the previously attached fitting ( C ) as shown. Fitting Page : 6 IW-17-4335-252-0...
- Page 7 Furniture can be dangerous if incorrectly installed. Assembly should be carried out by a competent person. No liability will be accepted for damage or injury caused by incorrectly installed or assembled furniture. PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE John Lewis Partnership 171 Victoria Street, London, SWIE 5NN www.johnlewis.com Page : 7...
