H-6932, H-6933
ECONOMY TRAINING
TABLE
TOOLS INCLUDED
Allen Wrench
Allen Wrench
5 mm
4 mm
Tabletop x 1
Locking Swivel
Caster x 4
Figure 1
1⁄" Socket
Nut
Screw
PAGE 1 OF 6
1-800-295-5510
uline.com
Double Sided
Wrench
PARTS
Modesty Panel x 1
Nut x 2
ASSEMBLY
Nut
Tabletop
Lever
Pour le français, consulter les pages 5-6.
1⁄" Socket Screw
1⁄" Socket Screw
x 2
1.
Place tabletop frame side up on a clean
surface. Depress the lever on the tabletop
locking mechanism to release the lock. Align
holes in legs with holes in tabletop frame as
shown. Secure with a 1⁄" socket screw and
nut on each side. (Ensure the elongated part
for the legs are positioned over the tabletop
as shown.) Tighten with enclosed 5 mm Allen
wrench and double sided wrench.
(See Figure 1)
1⁄" Socket
Screw
Para Español, vea páginas 3-4.
Leg x 2
x 4
0222 IH-6932
