- Page 1 Lexicon LE45 mobile computer Q i k St t G id Quick Start Guide www.lexicontech.com...
- Page 2 Features front and side views Power Button LCD display Right Scan Trigger Button Left Scan Trigger Button USB-C connector Keypad Keypad Battery Notification LEDs www.lexicontech.com...
- Page 3 Features rear, top and bottom views Data Capture Window Bottom Pogo Pin Speaker Handstrap clip Battery pack Handstrap Bar Handstrap Bar www.lexicontech.com...
- Page 4 Getting started cradling and charging Charging the device by power adapter Charging the device by power adapter Insert the small end of power adapter into the USB-C jack Plug the large end of power adapter into a power outlet Charging status LED on device •...
-
Page 5: Charging The Device
Getting started cradling and charging Cradling the device Sliding the device into the device with slight Sliding the device into the device with slight angle Slightly push the device back The device is sitting on the cradle in a secure manner Charging the device Connect the power supply to the cradle, make... -
Page 6: Installing Handstrap
Getting started Installing handstrap Remove screws from handstrap holder. Remove screws from handstrap holder. Separate the velcro of the handstrap. Feed the loose end of the extended handstrap through the handstrap clip Wrap the handstrap around the clip and fasten together to close the strap Wrap the handstrap around the clip and fasten together to close the strap Install the screws back to handstrap holder. -
Page 7: Disabling Wifi
Getting started Enabling & disabling WiFi Enabling WiFi Tap Apps icon then select Settings Tap Apps icon, then select Settings Go to Network connections, turn on WiFi Tap the WiFi text on the setting screen A list of WiFi networks appears pick the desired AP and setup as the wireless AP A list of WiFi networks appears, pick the desired AP and setup as the wireless AP properties as usual Disabling WiFi... - Page 8 Getting started Enabling & disabling BT Enabling Bluetooth Tap Apps icon then select Settings Tap Apps icon, then select Settings Go to Network connections, turn on Bluetooth Tap the Blyetooth text on the setting screen A list of bluetooth devices appears pick the desired device to pair up A list of bluetooth devices appears, pick the desired device to pair up Disabling Bluetooth Tap Apps icon, then select Settings...
- Page 9 Getting started reboot and factory data reset Performing reboot Long press power button Long press power button A menu appears , keep to hold the power key until the device reboot Performing factory data reset Tap Apps icon, then select Settings In Personal section select Back up and reset In Personal section, select Back up and reset Select Factory data reset, click Reset phone...
- Page 10 Getting started Refreshing ROM Refreshing RT55 ROM Copy RT55 ROM zip file to the root directory of the Copy RT55 ROM zip file to the root directory of the microSD card Open the battery cover, remove the battery Insert the microSD card Install the battery to the battery compartment Press and hold the power button and the F2 button for few seconds...
- Page 11 Getting started Refreshing ROM Select Yes – delete all us, press enter Finally select “reboot system now” to reboot the device ww.lexicontech.com...
- Page 12 Getting started Enabling scanner Enabling scanner Remove the scanner film on the scanner window Tap Apps icon, then select ScanDemo Press the scanner button on the device to b tt th d scan the barcode Barcode data will be shown on the screen Scan button ww.lexicontech.com...
-
Page 13: Battery Safety Guidelines
Getting started Battery warning Battery safety guidelines Use manufacturer's original battery and charger only. Any incompatible battery or charger may result in a fire, explosion, or other hazard. Do not disassemble or open, crush, bend or deform, puncture, or shred the battery. Do not short-circuit a battery by allowing conductive materials to contact the battery terminals. -
Page 14: Fcc And Canadian Compliance
FCC and Canadian Compliance Tested to Comply with FCC Standards. LE45 mobile computers meet or exceed all applicable standards and have been manufactured to the highest level of quality. Waste Electrical and Electronic Equipment (WEEE) Information This product has required the extraction and use of natural resources for its production It may contain hazardous substances that This product has required the extraction and use of natural resources for its production. - Page 15 FCC RF Exposure Information and Statement the SAR limit of USA (FCC) is HEAD AND TRUNK LIMIT FOR 1-g(1.6 W/kg) AND EXTREMITY FOR 10-g(4.0 W/kg) averaged over one gram of this Device LE45 (FCC ID: 2AWU8-LE45) has been tested against this SAR limit. SAR information on this can be viewed on-line at http://www.fcc.gov/oet/ea/fccid/.
