- Page 1 All manuals and user guides at all-guides.com OMEGA Owner’s Manual Part #9301297-001 ®...
-
Page 2: Table Of Contents
All manuals and user guides at all-guides.com ABLE OF ONTENTS Introduction..........................3 About This Product......................3 Unpacking ..........................3 Associated Components......................4 Installation of Spikes.........................4 Connections Using a Stereo Amplifier...................5–6 Connection for Bi-Amp Operation....................7 Bi-Wiring ..........................8 Positioning Your Speaker ....................9–11 Room Acoustics, Speaker Positioning and Tonal Balance ..........12–13 Adjusting Your EMIT™... -
Page 3: Introduction
RODUCT You have invested in one of the finest audio/video speakers available. Your Infinity Omega speaker employs new technology in driver, crossover and cabinet construction, which places it at the forefront of current speaker design. As with any high-quality product, special care must be taken to install and operate your new speaker. -
Page 4: Associated Components
If you are replacing existing speakers with an Infinity Omega System, there should be an audible improvement in sonic quality, assuming your other components are at least on a par with the Omega speaker in terms of low dis- tortion, phase linearity, frequency response and so on. -
Page 5: Connections Using A Stereo Amplifier
Infinity Omega. If inferior wire is used, sonic quality will suffer and the degra- dation of sound will be readily audible. For best results, do not use wire that is thinner than 16 gauge. - Page 6 LEFT channel output terminals in a similar manner. (See fig- ure 2.) OMEGA Figure 2. – Speaker connection. EMIT flat LEFT SPEAKER flat EMIM AMPLIFIER – L.F. LEFT RIGHT – – NORTHRIDGE, CALIFORNIA, USA 6 Omega – Owner’ s Manual...
-
Page 7: Connection For Bi-Amp Operation
All manuals and user guides at all-guides.com ONNECTION FOR PERATION Your Infinity Omega speakers permit you to employ two power amplifiers in a bi-amp configuration. One amplifier feeds the woofer (the signal passes through the speaker’ s crossover network to feed the woofer) and the other amplifier drives the remainder of the speaker system. -
Page 8: Bi-Wiring
Many audiophiles recommend using two connecting wires instead of one because two wires share current through a greater conducting area. If you wish to bi-wire your Omega speaker with a single power amplifier, remove the two shorting straps on the rear of the speaker that separate the woofer and midrange/tweeter sections of the crossover network. -
Page 9: Positioning Your Speaker
OSITIONING PEAKERS OSITION ITHIN Locating your Omega speakers in the proper position within your listening room is of primary importance if you wish to obtain the best possible perfor- TRONGLY NFLUENCE mance from your audio system. Depending on room size and acoustics, mov- ERFORMANCE ing the speakers as little as an inch (2.5cm) forward, rearward or sideways can... - Page 10 Sound is more direct when midrange FRONT OF SPEAKERS ON SAME PLANE AND and tweeter reach AT SAME ANGLE the listener at ear level. Tilt speaker forward to direct sound at ear level. LISTENER’S POSITION 10 Omega – Owner’ s Manual...
- Page 11 Use various types of program material when determining sonic balance. Additional advice on room acoustics and placement is contained on the next page under the heading “Room Acoustics, Speaker Positioning and Tonal Balance.” Omega – Owner’ s Manual 11...
-
Page 12: Room Acoustics, Speaker Positioning And Tonal Balance
(on both speakers) so that positive becomes negative and negative becomes positive. (See figure 8.) 12 Omega – Owner’ s Manual... - Page 13 NORTHRIDGE, CALIFORNIA, USA If you are using two separate amplifiers in a bi-amp mode (that are inverting types) to drive your Omega system, the aforementioned modification must be made to the wires connecting both amplifiers to the speakers. If the only inverting component in your system is the preamplifier or CD play- er, all of the speaker leads (when using a single amplifier or two separate ones) must be reversed at either the amplifier output or speaker inputs.
-
Page 14: Adjusting Your Emit™ Level
DJUSTING EVEL Your Omega loudspeaker allows the EMIT tweeter to be adjusted to one of three settings (boost, flat, cut). Start with the flat setting and compare to the boost or cut setting. Trust your ears and select the setting that is most pleasur- able for your listening room. -
Page 15: Acoustic Feedback
In turn, this vibration is fed back to the electronics and speakers. Since Omega speakers extend to very low frequencies, isolating the turntable from vibrations becomes an important procedure. The turntable should be placed on a heavy, solid support located as far from the speaker as possible. -
Page 16: Specifications
Infinity constantly strives to update and improve existing products, as well as create new ones. EN 50081-1:1991 Therefore, the specifications and construction details in this and related Infinity publications are EN 50082-1:1992 subject to change without notice.
