Summary of Contents for Galaxy 2500
- Page 1 Tvisto Lite User Guide & Manual Version 1.0...
-
Page 2: Table Of Contents
Table of Contents FEATURES OF TVISTO LITE ...1 ... 1 OMPACT ESIGN ... 2 CONNECTION ... 2 CONNECTION ... 2 UDIO FEATURES ... 2 IDEO FEATURES ... 3 ULTILINGUAL ... 3 EMOTE ... 3 IRMWARE UPDATE FORMATTING THE HDD...4 PC (W 2000/XP) ... -
Page 3: Features Of Tvisto Lite
Features of Tvisto Lite Compact Design Everything you love about multimedia, movies, music, and photos is brought to you by Tvisto Lite. Tvisto Lite features a high quality aluminum case to protect your device. The dimensions of Tvisto Lite are depicted in the adjacent figures. The front panel of Tvisto Lite is transparent, allowing the user to see the infrared receiver and two indicative LEDs:... -
Page 4: Pc Connection
PC connection Tvisto Lite can be connected to any PC or Mac via USB interface supporting FAT32 / MS-DOS file formats. With up to 480 Mbps transfer rate (in USB 2.0 connections), you can quickly move large multimedia files from your computer to Tvisto Lite. Please note that you need to use an external power adaptor with your Tvisto Lite. -
Page 5: Multilingual
Multilingual Tvisto Lite supports English, Traditional Chinese, and Simplified Chinese Remote Tvisto Lite is equipped with a compact elegant infrared remote control. Also control buttons on the device. Please refer to the chapter “TV Connection” for a detailed description of the both these controls. -
Page 6: Formatting The Hdd
Formatting the HDD Formatting on a PC (Win2000/XP) Use the Disk Management Utility • Right click on “My Computer” and choose “Manage” • Select “Disk Management” • Choose the drive you want to format and right click on the Disk or drive field for further commands •... - Page 7 Creating Directories For organizing your files on the hard drive, we suggest you to create four (4) folders with the following names shown below. We suggest you to make all folders READ ONLY attribute. This should help to make sure your folders are not deleted by accident. You can however use any names you would like for the folders.
- Page 8 PC/Mac Connection Tvisto Lite automatically operates as an external USB 2.0 hard disk when connected to a PC or Macintosh. Use the included USB 2.0 cable to connect your device to the computer system. Your system will automatically recognize Tvisto Lite as an external hard disk in which you can copy any file(s) you want (music, movie, picture, and/or data).
-
Page 9: Tv Connection
How to Safely remove Tvisto Lite from the Computer In order to safely remove your Tvisto Lite from your system, please follow the same procedures as for any Plug & Play external USB device, specifically: Double click on the taskbar icon to “Unplug or Eject hardware”. -
Page 10: Remote Control Keys
Remote Control Keys Tvisto Lite’s remote control has a full set of buttons in order to provide the user with complete control of the device. 1. ZOOM to image 2. ROTATE image 3. TRANSITION/EQUALIZER 4. POWER On/Off 5. PHOTO 6. MUSIC 7. -
Page 11: Tvisto Lite Control Keys
Tvisto Lite Control Keys Tvisto Lite’s housing has a set of control keys built into the housing. These keys can be used to control your Tvisto Lite. Keys Movie MODE Main Menu SETUP Setup Menu PLAY Select / Play STOP Stop Playback Reverse Play Fast Forward... -
Page 12: Summary Of Remote Control Keys
Summary of Remote Control Keys Movie ZOOM ROTATE TRANSITION / EQ POWER POWER On/Off PHOTO Photo Library MUSIC Music Library FILE File Library SETUP Setup Menu MODE Main Menu VOL + Increase volume VOL - Decrease Volume LEFT ENTER/PLAY Select / Play RIGHT INFO Displays File Info (size, format, etc) -
Page 13: Remote Control Battery Installation
Remote Control Battery Installation Tvisto Lite’s Remote Control uses one (1) 3 Volt CR2025 type Lithium Battery. This battery may be packaged separately from the remote control. To load it into the remote, do the following: • Remove the battery compartment cover/holder. -
Page 14: Main Menu
Menu Functions Main Menu This is the menu (as shown in the adjacent figure) that appears when you turn on Tvisto Lite. You have four (4) main selections that you can access with the navigation buttons and by pressing PLAY/ENTER Please look at the following paragraphs for a more detailed description of these menus. -
Page 15: Movie
MOVIE Selecting the Movies menu will bring the adjacent image onto your TV screen. Press the INFO button on the remote control to view the size of the file you have selected. By using the navigation buttons and the PLAY/ENTER on your remote or device, you can select the movie you want to play. -
Page 16: Photo Setup
Setup Menu The Tvisto Lite Setup Menu is extremely important in order to correctly configure your device and benefit from its advanced features. In the following paragraphs, there are detailed descriptions of the various settings and parameters. Use the arrow navigation buttons to select your preference and press the PLAY/ENTER button on the remote control or fixed buttons on the Tvisto Lite case to activate it. -
Page 17: Movie Setup
Movie Setup This feature allows you to control how your movies are played back, and if they are repeated how many times. Settings: Repeat Mode – Single / One Loop / Continuous Slide Show Setup Selecting Slide Show setting lets you configure the speed and way in which your pictures are displayed on your TV screen. -
Page 18: Specifications
Specifications Supported Audio Files Formats Supported Audio Outputs Formats Supported Video Files Formats Supported Video Outputs Formats Languages Supported Supported Interfaces Output Ports Input Ports Storage Capacity File Systems Supported Power Input Power Consumption Dimensions Weight Operating Temperature/Humidity Storage Temperature/Humidity Dual Stereo analog audio MPEG-1 (AVI, MPG, DAT), MPEG-2 (AVI, VOB) MPEG-4 (AVI, DivX, XviD). -
Page 19: Package Contents
Package Contents Standard Package Check Part Description Note The Tvisto Lite portable media center. NO hard drive included! Power Adaptor with automatic voltage changeover 110V/220V. Infrared Remote Control and one 3Volt CR2025 type Lithium Battery ■... - Page 20 AV Cable (Composite RCA, S- Video mini DIN, Left Audio RCA, Right Audio RCA) USB 2.0 Cable (A to mini B). In order to have maximum transfer rate and reliability, use only the cable provided in this package CD with USB driver for Win98/SE User Guide &...
-
Page 21: Power On/Off Precautions
Safety Information Before starting your Tvisto Lite, please carefully read the following information relating to the safety issues on your device in order to extend its life. Power on/off precautions Tvisto Lite Remote Control provides the POWER ON/OFF button that controls the power status of your device. - Page 22 © Copyright 2004 by GMG, INC. All Rights Reserved The information contained in this manual is believed to be accurate and reliable. GMG INC assumes no responsibility for any errors contained in this manual. GMG INC reserves the right to make changes in the specifications and/or design of the above mentioned product without prior notice.
- Page 23 AUGUST, 2005 / E15-5742100011...
