All manuals and user guides at all-guides.com WR 325 RSF Room Sealed Fan-Assisted Multipoint Water Heater GC NUMBER ??-???-??? USER INSTRUCTIONS & CUSTOMER CARE GUIDE...
All manuals and user guides at all-guides.com GENERAL INFORMATION GAS SAFETY (INSTALLATION AND USE) REGULATIONS 1998 IMPORTANT: NOTE: GENERAL DESCRIPTION Technical Data WR325 Appliance Type Nat. gas L.P.G. Rated Input (Qn) 24.3 kW 24.3 kW Maximum Rated Output (Pn) 21.4 kW 21.4 kW Minimum Rated Output (Pmin) 7.0 kW 7.0 kW...
Page 4
All manuals and user guides at all-guides.com Performance Temperature control turned fully anti-clockwise 12 litres/minute at 25°C temperature rise Temperature control turned fully clockwise 6 litres/minute at 55°C temperature rise Temperature limiter Fig. 1...
All manuals and user guides at all-guides.com GENERAL NOTES CLEARANCES Above the turret 30 mm In front 600 mm Below 200 mm Right-hand side 10 mm Left-hand side 10 mm...
Page 6
All manuals and user guides at all-guides.com SHOWERS, BIDETS, TAPS AND MIXING VALVES HOT AND COLD FLOW WATER MAINS FAILURE USE IN HARD WATER AREAS VENTILATION OF ROOM SEALED FANNED FLUE (RSF) APPLIANCES FROST PRECAUTIONS SERVICE...
Page 7
All manuals and user guides at all-guides.com WARNING CLEANING...
All manuals and user guides at all-guides.com OPERATION OF CONTROLS Operation Starting up Switching On/Off Switching On: I Switching Off: 0 Fig. 2 Temperature Control Fig. 3 Shut Down...
Page 9
All manuals and user guides at all-guides.com Safety Cut-Out Fig. 4 Servicing...
Page 10
All manuals and user guides at all-guides.com Fig. 6 - Controls Fig. 5...
Page 11
All manuals and user guides at all-guides.com APPLIANCE FAILS TO OPERATE CALL-OUT CHARGES NOTE:...
