26928
I
NTRODUCTION
40-Channel 900 MHz
CAUTION: When using telephone equipment, there are basic safety instructions that should always be
Cordless Telephone
followed. Refer to the IMPORTANT SAFETY INSTRUCTIONS provided with this product and save them
for future reference.
User's Guide
Your Cordless Telephone is designed to give you flexibility in use and high quality performance. To get the most
from your new cordless telephone, we suggest that you take a few minutes right now to read through this
instruction manual.
IMPORTANT: Because cordless phones operate on electricity, you should have at least one phone in your home that is
not cordless, in case the power in your home goes out.
B Y B
EFORE OU EGIN
P C
ARTS HECKLIST
Make sure your package includes the items shown here.
VOL
- TALK +
redial memory program
1 2 3 def
abc
ghi 4 5 jkl 6 mno
7 pqrs 8 tuv 9 wxyz
* tone 0 pause #
ringer oper
channel off on flash
Base Handset AC power supply
T J R
ELEPHONE ACK
To use this phone, you need an RJ11C type modular telephone jack, which might look like
the one pictured here, installed in your home. If you don't have a modular jack, call your
local phone company to find out how to get one installed.
D S S
IGITAL ECURITY YSTEM
Your cordless phone uses a digital security system to provide protection against false ringing, unauthorized
access, and charges to your phone line.
When you place the handset in the base, the unit verifies its security code. After a power outage or battery
replacement, you should place the handset in the base for about 20 seconds to reset the code.
THE LIGHTNING
We bring good things to life.
FLASH AND ARROW
WARNING: TO
HEAD WITHIN THE
PREVENT FIRE OR
TRIANGLE IS A
WARNING SIGN
ELECTRICAL SHOCK
ALERTING YOU OF
E A I
QUIPMENT PPROVAL NFORMATION HAZARD, DO NOT
"DANGEROUS
Your telephone equipment is approved for connection to the Public Switched Telephone Network and is in compliance with parts 15 VOLTAGE" INSIDE
EXPOSE THIS
and 68, FCC Rules and Regulations and the Technical Requirements for Telephone Terminal Equipment published by ACTA.
THE PRODUCT.
PRODUCT TO RAIN
1 Notification to the Local Telephone Company
On the bottom of this equipment is a label indicating, among other information, the US number and Ringer Equivalence Number
OR MOISTURE.
(REN) for the equipment. You must, upon request, provide this information to your telephone company.
The REN is useful in determining the number of devices you may connect to your telephone line and still have all of these I
NSTALLATION AND
devices ring when your telephone number is called. In most (but not all) areas, the sum of the RENs of all devices connected to
one line should not exceed 5. To be certain of the number of devices you may connect to your line as determined by the REN, you
should contact your local telephone company.
A plug and jack used to connect this equipment to the premises wiring and telephone network must comply with the applicable FCC
INSTALLATION NOTE: Some cordless telephones operate at frequencies that may cause interference to nearby TVs,
Part 68 rules and requirements adopted by the ACTA. A compliant telephone cord and modular plug is provided with this product. It is
designed to be connected to a compatible modular jack that is also compliant. See installation instructions for details. microwave ovens, and VCRs. To minimize or prevent such interference, the base of the cordless telephone should not be placed
Notes near or on top of a TV, microwave oven, or VCR. If interference continues, moving the cordless telephone farther away from the
• This equipment may not be used on coin service provided by the telephone company.
TV or VCR will often reduce or eliminate the interference.
• Party lines are subject to state tariffs, and therefore, you may not be able to use your own telephone equipment if you are on
a party line. Check with your local telephone company. Certain other communications devices may also use the 900 MHz frequency for communication, and, if not
• Notice must be given to the telephone company upon permanent disconnection of your telephone from your line. properly set, these devices may interfere with each other and/or your new telephone. If you are concerned with
• If your home has specially wired alarm equipment connected to the telephone line, ensure the installation of this product interference, please refer to the owner's manual for these devices on how to properly set channels to avoid
does not disable your alarm equipment. If you have questions about what will disable alarm equipment, consult your
interference. Typical devices that may use the 900 MHz frequency for communication include wireless audio/video
telephone company or a qualified installer.
senders, wireless computer networks, multi-handset cordless telephone systems, and some long-range cordless
2 Rights of the Telephone Company
Should your equipment cause trouble on your line which may harm the telephone network, the telephone company shall, where telephone systems.
practicable, notify you that temporary discontinuance of service may be required. Where prior notice is not practicable and the
circumstances warrant such action, the telephone company may temporarily discontinue service immediately. In case of such
temporary discontinuance, the telephone company must: (1) promptly notify you of such temporary discontinuance; (2) afford you the
opportunity to correct the situation; and (3) inform you of your right to bring a complaint to the Commission pursuant to procedures set I I
MPORTANT NSTALLATION
forth in Subpart E of Part 68, FCC Rules and Regulations.
The telephone company may make changes in its communications facilities, equipment, operations or procedures where such action is
required in the operation of its business and not inconsistent with FCC Rules and Regulations. If these changes are expected to affect
• Never install telephone wiring during a lightning storm.
the use or performance of your telephone equipment, the telephone company must give you adequate notice, in writing, to allow you to
maintain uninterrupted service.
• Never touch uninsulated telephone wires or terminals, unless the telephone line has been disconnected at the
I I network interface.
NTERFERENCE NFORMATION
• Use caution when installing or modifying telephone lines.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful
interference; and (2) This device must accept any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are • Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.
designed to provide reasonable protection against harmful interference in a residential installation.
D I
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may ESKTOP NSTALLATION
cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna (that is, the antenna for radio or television that is "receiving" the interference).
• Reorient or relocate and increase the separation between the telecommunications equipment and receiving antenna.
• Connect the telecommunications equipment into an outlet on a circuit different from that to which the receiving antenna is connected.
If these measures do not eliminate the interference, please consult your dealer or an experienced radio/television technician for
additional suggestions. Also, the Federal Communications Commission has prepared a helpful booklet, "How To Identify and Resolve
Radio/TV Interference Problems." This booklet is available from the U.S. Government Printing Office, Washington, D.C. 20402. Please
specify stock number 004-000-00345-4 when ordering copies.
VOL
- TALK +
H A C
EARING ID OMPATIBILITY redial program
memory
1 2 abc def 3
4 ghi 5 jkl 6 mno
This telephone system meets FCC standards for Hearing Aid Compatibility.
7 pqrs 8 tuv wxyz 9
* tone 0 oper # pause
US NUMBER IS LOCATED ON THE CABINET BOTTOM ringer
channel flash
off on
REN NUMBER IS LOCATED ON THE CABINET BOTTOM
ATLINKS USA, Inc.
101 West 103rd Street 1
Model 26928M
Indianapolis, IN 46290
16167880 (Rev. 0 E/S)
© 2003 ATLINKS USA, Inc.
03-10
Trademark(s) ® Registered
Printed in China Marca(s) Registrada(s)
1. Set the ringer switch (on the handset front) to ON, and place handset in the cradle on the base.
2. Plug the power supply into the power jack on the bottom of the base and the other end into an electrical outlet.
The "in use/charge" indicator comes on verifying the battery is charging.
Allow the phone to charge for 12 hours prior to first use. If you don't properly charge the phone, battery
performance will be compromised.
3. Plug the telephone line cord into the telephone jack on the bottom of the base and into a modular wall
phone jack.
NOTE: The phone automatically defaults to touch-tone dialing. To change to pulse (rotary) dialing, see "Tone/Pulse
Dialing." If you don't know which type of service you have, check with the phone company.
CAUTION: Use only the ATLINKS USA, Inc. 5-2581 power supply that came with this unit. Using other
adapters may damage the unit.
W M I
ALL OUNT NSTALLATION
Because it is necessary to charge the handset for 12 hours prior to connecting the phone for use the first time, it
is better to leave the unit on a flat surface during initial charge before attempting to hang it on the wall.
5
VOL
- TALK +
Telephone line cord redial program
memory
Wall plate 1 2 abc 3 def
ghi 4 5 jkl mno 6
EQUIREMENTS pqrs 7 8 tuv 9 wxyz
* tone 0 oper pause #
ringer
channel flash
Telephone off on
line jack
1
3
1. Set the ringer switch (on the handset front) to ON, and place handset in the cradle on the base.
2. Plug one end of the power supply into the power jack on the back of the base and the other end into an electrical
outlet. The "in use/charge" indicator comes on, verifying the battery is charging.
Allow the phone to charge for 12 hours prior to first use. If you don't properly charge the phone, battery
performance will be compromised.
CAUTION:
RISK OF ELECTRIC SHOCK 3. Plug the telephone line cord into the telephone jack on the bottom of the base and into a modular wall
DO NOT OPEN phone jack.
CAUTION: TO REDUCE THE THE EXCLAMATION
4. Slip the mounting holes over the wall plate posts and slide the unit down firmly into place. (Wall plate not
RISK OF ELECTRIC SHOCK, DO POINT WITHIN THE
included.)
NOT REMOVE COVER (OR TRIANGLE IS A
BACK). NO USER WARNING SIGN 5. Place the handset in the cradle.
SERVICEABLE PARTS INSIDE. ALERTING YOU OF
NOTE: The phone automatically defaults to touch-tone dialing. To change to pulse (rotary) dialing, see "Tone/Pulse
REFER SERVICING TO IMPORTANT
QUALIFIED SERVICE INSTRUCTIONS Dialing." If you don't know which type of service you have, check with the phone company.
PERSONNEL. ACCOMPANYING
THE PRODUCT.
CAUTION: Use only the ATLINKS USA, Inc. 5-2581 power supply that came with this unit. Using other
adapters may damage the unit.
SEE MARKING ON BOTTOM / BACK OF PRODUCT
C P B
S U ORDLESS HONE ASICS
ET P
VOLUME - button
VOLUME + button
TALK button VOL
- TALK +
program button
I
NFORMATION redial program
memory
redial button
1 2 3 def
abc
4 6
ghi 5 mno memory button
jkl
7 9
pqrs 8 wxyz
tuv
*tone button
# # pause button
* tone 0 oper pause
channel ringer flash
off on
channel button flash button
ringer switch
M C
AKING A ALL
After initial set up, put handset in cradle on the base and charge the battery for 12 hours. To make a call:
• Press the TALK button before you dial.
2
• Press TALK or place the handset in the base to hang up.
3
R C
ECEIVING A ALL
To answer a call, press the TALK button and begin speaking.
I U I L D
N SE NDICATOR IGHT
The phone is ON/in use when the TALK button on the handset and the base charge/in use indicator is lit.
1. Make sure the phone is ON by pressing the TALK button.
R
EDIAL 2. Press the memory button.
3. Press the number (0-9) for the desired memory location. The number dials automatically.
Press the TALK button, then press the redial button to redial the last number you called (up to 32 digits). If you get
a busy signal, and want to keep dialing the number, just press redial again (you don't have to turn the phone off
IMPORTANT: If you make test calls to emergency numbers stored in memory, remain on the line and briefly
and back on).
explain the reason for the call to the dispatcher. Also, it's a good idea to make these calls in off-peak hours, such as
early morning or late evening.
F
LASH
C
Use the flash button to activate custom calling services such as Call Waiting or call transfer, which are available
through your local phone company.
Make sure the telephone is OFF before you replace battery.
TIP: If you press the TALK button to activate custom calling services such as call waiting, you'll hang up the phone.
1. Remove the battery compartment door.
Press flash button instead.
2. Disconnect the cord attached to the battery pack and remove the battery pack from the
V handset.
OLUME
3. Insert the new battery pack and connect the cord into the jack inside the handset.
The VOLUME (left and right arrow) buttons control the volume of the handset's earpiece.
4. Put the battery compartment door back on.
R S
INGER WITCH
5. Place handset in the base to charge. If you don't charge the handset battery properly
(for 12 hours) when you first set up the phone and/or when you install a new battery
The handset ringer switch can be set to ON or OFF. If the switch is off, the unit will not ring.
pack, the battery's long-term performance will be compromised.
T /P D
ONE ULSE IALING
This adjustment allows you to select tone (touch-tone) or pulse (rotary) mode dialing. The phone is pre-set for
2
touch-tone use. To set to tone or pulse dialing:
B
ATTERY
1. Press and hold the program button for two seconds. You will hear a beep.
• Do not burn, disassemble, mutilate, or puncture. Like other batteries of this type, toxic
2. Press the *tone button to select Tone Dialing or press #pause to select Pulse Dialing.
materials could be released which can cause injury.
3. Press the program button again. You will hear a confirmation tone.
• To reduce the risk of fire or personal injury, use only the battery listed in the User's Guide.
4
T T
EMPORARY ONE • Keep batteries out of the reach of children.
• Remove batteries if storing over 30 days.
If you have pulse (rotary) service, and want to access customer calling services that require tone dialing (such as
telebanking and long distance services), you can use this feature to make your phone temporarily touch-tone
compatible.
1. Press the TALK button, and call the bank's information line.
page button
H
2. Press the *tone button after your call is answered.
3. Follow the voice instructions to complete your transaction.
Signal
4. Hang up when finished. The phone returns to pulse (rotary) service.
A long warbling tone
P H
AGING THE ANDSET
One short beep and one long beep
Press the page button on the base to locate a misplaced handset. When you press the page A short beep every seven seconds
button, the handset beeps and the indicator on the handset and the page/in use indicator on the
Three short beeps
base blinks. Press the TALK button when you locate the handset. The page signal is one short
beep and one long beep for two minutes. To cancel the page, press the page button again. Two long beeps
NOTE: You can still page the handset with the ringer off.
C B T
HANNEL UTTON
ALK
If you ever experience any interference or don't have clear voice quality, press the channel button on the handset
Signal
to advance to another channel.
Lights steadily
M
EMORY
Quickly flashing
Flashes every 7 seconds (phone is off)
Store up to ten 20-digit telephone numbers in memory for quick dialing.
S N M T
TORING A UMBER IN EMORY
1. Make sure the phone is OFF, and press the memory button. In case of difficulty, please check the following Troubleshooting Guide before seeking service.
2. Press a number key (0-9) to store the phone number in that memory location.
Problem
3. Press memory button.
No dial tone
4. Use the keypad to enter the number (up to 20 digits) you want to store in that memory location.
5. Press the memory button again to confirm.
C S N
HANGING A TORED UMBER
Follow the procedure in STORING A NUMBER IN MEMORY, except replace the old phone number with a new
phone number.
S P M
TORING A AUSE IN EMORY
Use the #pause button to insert a pause when a delay is needed in the dialing sequence (for example, when you
must dial a 9 to get an outside line or when you must enter codes to access your bank's information line). Each
pause counts toward the 20-digit limit.
If you need to dial 9 to get an outside line and want to store a number in memory without having to dial 9 each
time, you would:
1. Make sure the phone is OFF, and press the memory button.
3. Press a number (0-9) to store the phone number in that memory location.
Dial tone is OK, but
4. Press memory again.
can't dial out
5. Enter the number 9 (or any other appropriate number) to access an outside line.
Handset does not ring
6. Press # pause button.
7. Enter the phone number you want to store in memory.
8. Press the memory button again to confirm.
Cannot hear phone
TIP: If you need a longer pause, press the #pause button twice. conversation
You experience static, • Change channels.
S N
IALING A TORED UMBER
noise, or fading in • Is handset out of range? Move closer to the base.
and out • Does the base need to be relocated?
• Charge handset battery.
• Make sure base is not plugged into an outlet with another
household appliance.
Range is shorter • Press the channel button during the conversation to
than normal select a new channel.
Phone dials in pulse • Make sure the phone is set to tone dialing.
B
with tone service
HANGING THE ATTERY
Phone won't dial out • Make sure the phone is set to pulse dialing.
with pulse service
Battery will not hold a • Be sure you are charging the battery for 12 hours; you
charge can expect approximately seven hours of talk time.
• Check to be sure battery contacts on both the handset and
the base are making contact and are clean; free of dirt or lint.
• When the handset is placed in the base, check that the base
in use/charge light is on.
Memory Dialing • Did you program the memory location keys correctly?
doesn't work • Did you follow proper dialing sequence?
• Make sure the tone/pulse setting is programmed correctly.
CAUTION: To reduce the risk of fire or personal injury, use only the battery listed in
the instruction book. Unit locks up and • If the phone still does not work, disconnect the power cord
no communication and remove the battery pack. Then reconnect the power
S P
AFETY RECAUTIONS between the base cord and reinstall the battery pack. Place handset in the base
and the handset for 10 seconds to allow it to reinitialize.
• If a power outage occurs while the handset is away from the
base, the handset must be returned to the base when the
power returns.
S
ERVICE
NOTE: The RBRC seal on the battery used in your ATLINKS USA product indicates that we are
participating in a program to collect and recycle Nickel Cadmium batteries throughout the United States. If trouble is experienced with this equipment, for repair or warranty information, please contact customer service
Please call 1-800-8-BATTERY for information or contact your local recycling center.
at 1-800-448-0329. If the equipment is causing harm to the telephone network, the telephone company may
request that you disconnect the equipment until the problem is resolved.
S S
ANDSET OUND IGNALS
This product may be serviced only by the manufacturer or its authorized service agents. Changes or modifications
Meaning
not expressly approved by ATLINKS USA, Inc. could void the user's authority to operate this product. For
instructions on how to obtain service, refer to the warranty included in this guide or call customer service at 1-
You have an incoming call (with ringer ON)
800-448-0329.
The handset is being paged
Or refer inquiries to:
Low battery warning
ATLINKS USA, Inc.
Manager, Consumer Relations
Error tone
P O Box 1976
Confirmation tone
Indianapolis, IN 46206
Attach your sales receipt to the booklet for future reference or jot down the date this product was purchased or
received as a gift. This information will be valuable if service should be required during the warranty period.
B I L
UTTON NDICATOR IGHT
Purchase date _______________________________________________________________________________
Meaning
Phone is in use
Name of store _______________________________________________________________________________
You have an incoming call or page
L W
Low battery warning
IMITED ARRANTY
G
ROUBLESHOOTING UIDE
What your warranty covers:
• Defects in materials or workmanship.
For how long after your purchase:
Solution
• One year, from date of purchase.
• Check installation:
(The warranty period for rental units begins with the first rental or 45 days from date of
Is the base power cord connected to a working outlet?
shipment to the rental firm, whichever comes first.)
Are the in use lamps on the handset and base lit?
What we will do:
Is the handset in use/charge light on?
• Provide you with a new or, at our option, a refurbished unit. The exchange unit is under
Is the telephone line cord connected to the base unit and the
warranty for the remainder of the original product's warranty period.
wall jack?
• Disconnect the base from the wall jack and connect another How you get service:
phone to the same jack. If there is no dial tone in the second
• Properly pack your unit. Include any cables, etc., which were originally provided with the
phone, the problem might be your wiring or local service. product. We recommend using the original carton and packing materials.
• Is the handset out of the base unit's range? Move closer to
• "Proof of purchase in the form of a bill of sale or receipted invoice which is evidence that the
the base unit. product is within the warranty period, must be presented to obtain warranty service. " For
• Make sure the battery is properly charged (12 hours).
rental firms, proof of first rental is also required. Also print your name and address and a
• Is the battery pack installed correctly? description of the defect. Send via standard UPS or its equivalent to:
• If the phone still does not work, disconnect the power cord ATLINKS USA, Inc.
and remove the battery pack. Then reconnect the power cord c/o Thomson
and reinstall the battery pack. Place handset in the base for 11721 B Alameda Ave.
10 seconds to allow it to reinitialize. Socorro, Texas 79927
• Make sure the tone/pulse setting is • Pay any charges billed to you by the Exchange Center for service not covered by the warranty.
programmed correctly. • Insure your shipment for loss or damage. ATLINKS accepts no liability in case of damage or loss.
• Make sure the ringer switch on the handset is turned to ON. • A new or refurbished unit will be shipped to you freight prepaid.
• You may have too many extension phones on your line. Try What your warranty does not cover:
unplugging some phones.
• Customer instruction. (Your Owner's Manual provides information regarding operating
• See solutions for "No dial tone. "
instructions and user controls. Any additional information, should be obtained from your dealer.)
• Press the VOLUME (left and right arrow) buttons to adjust • Installation and setup service adjustments.
the volume to the desired listening level.
• Batteries.
• Damage from misuse or neglect.
• Products which have been modified or incorporated into other products.
• Products purchased or serviced outside the USA.
• Acts of nature, such as but not limited to lightning damage.
Product Registration:
• Please complete and mail the Product Registration Card packed with your unit. It will make it
easier to contact you should it ever be necessary. The return of the card is not required for
warranty coverage.
Limitation of Warranty:
• THE WARRANTY STATED ABOVE IS THE ONLY WARRANTY APPLICABLE TO THIS PRODUCT. ALL
OTHER WARRANTIES, EXPRESS OR IMPLIED (INCLUDING ALL IMPLIED WARRANTIES OF
MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE) ARE HEREBY DISCLAIMED. NO
VERBAL OR WRITTEN INFORMATION GIVEN BY ATLINKS USA, INC., ITS AGENTS, OR EMPLOYEES
SHALL CREATE A GUARANTY OR IN ANY WAY INCREASE THE SCOPE OF THIS WARRANTY.
• REPAIR OR REPLACEMENT AS PROVIDED UNDER THIS WARRANTY IS THE EXCLUSIVE
REMEDY OF THE CONSUMER. ATLINKS USA, INC. SHALL NOT BE LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT OR ARISING
OUT OF ANY BREACH OF ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT. THIS
DISCLAIMER OF WARRANTIES AND LIMITED WARRANTY ARE GOVERNED BY THE LAWS OF
THE STATE OF INDIANA. EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE LAW, ANY
IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON
THIS PRODUCT IS LIMITED TO THE APPLICABLE WARRANTY PERIOD SET FORTH ABOVE.
How state law relates to this warranty:
• Some states do not allow the exclusion nor limitation of incidental or consequential
damages, or limitations on how long an implied warranty lasts so the above limitations or
exclusions may not apply to you.
• This warranty gives you specific legal rights, and you also may have other rights that vary
from state to state.
If you purchased your product outside the USA:
• This warranty does not apply. Contact your dealer for warranty information.
DESCRIPTION MODEL NO. PRICE* QUANTITY TOTAL
silver blue red
AC power supply 5-2581 5-2581 5-2581 $19.95
Replacement battery 5-2574 5-2574 5-2574 $9.95
To order, call 1-800-338-0376 (for accessories only) or complete this order form.
