SERVICE MANUAL
This model is classified as a
This Service Manual describes replacement parts for the green product. When repairing this
green product, use the part(s) described in this manual and
For (*1) and (*2), refer to
SOLDER.
© TOSHIBA CORPORATION
file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.466\37H...
LCD Color Television
37HL86
green product
(*1), as indicated by the underlined serial number.
GREEN PRODUCT PROCUREMENT
Ver. 1.01
lead-free solder
(*2).
and
LEAD-FREE
Стр. 1 из 1
10.05.2015

Advertisement

Table of Contents
loading

Related Manuals for Toshiba 37HL86

Summary of Contents for Toshiba 37HL86

  • Page 1 This Service Manual describes replacement parts for the green product. When repairing this green product, use the part(s) described in this manual and lead-free solder (*2). For (*1) and (*2), refer to GREEN PRODUCT PROCUREMENT LEAD-FREE SOLDER. © TOSHIBA CORPORATION file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.466\37H... 10.05.2015...

  • Page 2: Green Product Procurement

    Corporation recognizes environmental protection as a key management tasks, and is doing its utmost to enhance and improve the quality and scope of its environmental activities. In line with this, Toshiba proactively promotes Green Procurement, and seeks to purchase and use products, parts and materials that have low environmental impacts.

  • Page 3: Lead-Free Solder

    Стр. 1 из 1 LEAD-FREE SOLDER This product is manufactured using lead-free solder as a part of a movement within the consumer products industry at large to be environmentally responsible. Lead-free solder must be used in the servicing and repair of this product. WARNING: This product is manufactured using lead free solder.

  • Page 4: Important Notice

    Through WEB, ver. 6.5 has been released but with it, the linking function in this manual may not work properly. If ver. 6.5 has been installed, uninstall it and reinstall ver. 6.0. To get ver. 6.0, click the icon, or contact to the nearest Toshiba Service Centre for further assistance. Freezing windows opened (Cannot close the open windows) This may happen occasionally.
  • Page 5 Стр. 2 из 2 Continue to use by operating the windows. Precaution when opening the diagrams While opening the diagrams, the menu in the left frame changes its color to GRAY. This is an indication that the viewer is processing. With this condition, the menu indication color may stick to the GRAY color or Windows may freeze if clicking other menu.
  • Page 6 Стр. 1 из 4 IMPORTANT NOTICE User Guide Autodesk® DWF™ Viewer is necessary to view drawings and to activate the functions of this system. Please download and install. When Windows XP SP2 is used, pop-up windows are limited by the enhanced security function and this sample may not work.

  • Page 7: Operating Environment

    Стр. 2 из 4 Operating Environment : Pentium III or higher recommended Monitor : 1024 x 768 or higher resolution recommended file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.117\37H... 10.05.2015...
  • Page 8 Стр. 3 из 4 Mouse : A mouse with wheel recommended : Microsoft Windows 2000/XP Browser Microsoft Internet Explorer 6.0 or later Drawing viewer : Autodesk DWF Viewer 6.0 * Use the software following respective license terms and conditions. Note: In case of using this service manual with network connection, allocate its folder to the client PCs as network drive to avoid any possible malfunction.
  • Page 9 Стр. 4 из 4 Layer Display Changing Function When any of the color buttons on the toolbar is clicked, it can be selected to display desired layer in its color or not to display each layer. This allows you to see the pattern layer only by setting other layers to "non-display".
  • Page 10 WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Toshiba shall not be liable for any damages, losses, expenses or costs, if any, incurred in connection with or as a result of use of any information or data provided herein.

  • Page 11: Service Mode

    Стр. 1 из 11 ADJUSTMENT Service Mode Entering to Service Mode 1. Press MUTE button once on remote control. ↓ ↓ ↓ ↓ 2. Press MUTE button again and keep pressing. ↓ ↓ ↓ ↓ Service Mode display 3. While pressing the MUTE button, press MENU button on TV set.
  • Page 12 Стр. 2 из 11 Displaying the Adjustment Menu Press MENU button on TV. Service Mode Press ↑ ↑ ↑ ↑ ↓ ↓ ↓ ↓ Press Adjustment Mode Key Function in the Service Mode The following key entry during display of adjustment menu provides special functions. CAUTION: Never try to perform initialization unless you have changed the memory IC.
  • Page 13 Стр. 3 из 11 Test signal selection INPUT button (on remote control) Selection of the adjustment items (on TV or remote control) Change of the data value Volume +/- (on TV or remote control) Adjustment menu mode ON/OFF MENU button (on TV) Initialization of the memory (QA02) CALL + CH button on TV ( "RCUT"...
  • Page 14 Стр. 4 из 11 ← BCUT B CUT OFF ← RDRV R DRIVE ← GDRV G DRIVE ← BDRV B DRIVE ← BRTC BRIGHTNESS CENTER FEH ← COLC COLOR CENTER ← UVTT BASE BAND TINT ← CNTX CONTRAST MAX ← VOLUX MAX VOLUME LIMITED ←...

  • Page 15: Test Signal Selection

    Стр. 5 из 11 1. Enter the service mode, then select any register item. 2. Press and hold the CALL button on the remote control, then press the CH button on the TV. The initialization of QA02 has been completed. 3.

  • Page 16: Self-Diagnostic Function

    Стр. 6 из 11 All White Self Diagnostic Function 1. Press "9" button on remote control during display of adjustment menu in the service mode. The diagnosis will begin to check if interface among IC's is executed properly. 2. During diagnosis, the following displays are shown. (1) Firmware : Version information of microprocessor In case of file name : HL86 and Version : 0443a indicates [HL86_0443a].
  • Page 17 Стр. 7 из 11 (5) Block : TV reception mode V1 - V4 : VIDEO 1-4 input mode : PC mode HL86 Video1 ColorStreamHD1 (Composite/Component) Video2 (Composite/S-VIDEO) ColorStreamHD2 (Component) HDMI Version Check Mode 1. Press "9" button twice on remote control during display of adjustment menu in the service mode.
  • Page 18 Стр. 8 из 11 (1) MAIN MPU : Version information of microprocessor In case of file name : HL86, Version 0443a for Code Program Version and (U01) for OSD Version indicates [HL86_0443a (U01)] (2) EEPROM : Version information of EEPROM : Display 1 byte data. (3) SUB MPU : Version information of SUB MPU : Display 1 byte data.
  • Page 19 Стр. 9 из 11 Panel Vender Screen Size (Inch) Example : AUO-32 indicates that Vender is AUO and Screen Size is 32 inch. Status Check Mode 1. Press "9" button thrice on remote control during display of adjustment menu in the service mode.
  • Page 20 Стр. 10 из 11 (3) MAIN PLL : Main PLL information : Display 1 byte data at five. (4) SCREEN SIZE : Display the one of screen size as follows. Theater Wide 1 Theater Wide 2 Theater Wide 3 FULL NATURAL 4:3 HD (5) OTHER STATUS :...
  • Page 21 Стр. 11 из 11 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.213\37H... 10.05.2015...

  • Page 22: Function And Operation

    Стр. 1 из 2 FUNCTION AND OPERATION TV Front and Side Panel Control and Connection file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.268\37H... 10.05.2015...
  • Page 23 Стр. 2 из 2 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.268\37H... 10.05.2015...

  • Page 24: Learning About The Remote Control

    Стр. 1 из 3 FUNCTION AND OPERATION Learning about the Remote Control file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.433\37H... 10.05.2015...
  • Page 25 Стр. 2 из 3 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.433\37H... 10.05.2015...
  • Page 26 Стр. 3 из 3 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.433\37H... 10.05.2015...
  • Page 27 Стр. 1 из 4 FUNCTION AND OPERATION Programming Channel into the TV's Channel Memory Programming Channel Automatically file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.806\37H... 10.05.2015...
  • Page 28 Стр. 2 из 4 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.806\37H... 10.05.2015...
  • Page 29 Стр. 3 из 4 Manually Adding and Deleting Channel in the Channel Memory file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.806\37H... 10.05.2015...
  • Page 30 Стр. 4 из 4 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.806\37H... 10.05.2015...
  • Page 31 Стр. 1 из 2 FUNCTION AND OPERATION Programming Your Favorite Channel file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.046\37H... 10.05.2015...
  • Page 32 Стр. 2 из 2 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.046\37H... 10.05.2015...

  • Page 33: Labeling Channel

    Стр. 1 из 2 FUNCTION AND OPERATION Labeling Channel file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.610\37H... 10.05.2015...
  • Page 34 Стр. 2 из 2 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.610\37H... 10.05.2015...

  • Page 35: Safety Instruction

    Handling the LCD Module Стр. 1 из 4 SAFETY INSTRUCTION Handling the LCD Module Safety Precaution In the event that the screen is damaged or the liquid crystal (fluid) leaks, do not breathe in or drink this fluid. Also, never touch this fluid. Such actions could cause toxicity or skin irritation. If this fluid should enter the mouth, rinse the mouth thoroughly with water.
  • Page 36 Handling the LCD Module Стр. 2 из 4 3. If the panel surface becomes soiled, wipe with cotton or a soft cloth. If this does not remove the soiling, breathe on the surface and then wipe again. If the panel surface is extremely solied, use a CRT cleaner as a cleaner. Wipe off the panel surface by drop the cleaner on the cloth.
  • Page 37 Handling the LCD Module Стр. 3 из 4 6. CMOS-LSI circuitry is used in the LCD module, so avoid damage due to static electricity. When handling the module, use a wrist ground or anchor ground. 7. Do not expose the LCD module to direct sunlight or strong ultraviolet rays for an extended period of time.
  • Page 38 Handling the LCD Module Стр. 4 из 4 10. When transporting the LCD module, do not use packing containing epoxy resin (amine) or silicon resin (alcohol or oxim). The gas generated by these materials can cause loss of polarity. file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.844\37H... 10.05.2015...

  • Page 39: Safety Precaution

    SAFETY INSTRUCTION [LCD] USA Стр. 1 из 3 SAFETY INSTRUCTION WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" INSTRUCTIONS BELOW. Safety Precaution WARNING: SERVICING SHOULD NOT BE ATTEMPTED BY ANYONE UNFAMILIAR WITH THE NECESSARY PRECAUTIONS ON THIS RECEIVER. THE FOLLOWING ARE THE NECESSARY PRECAUTIONS TO BE OBSERVED BEFORE SERVICING THIS CHASSIS.
  • Page 40 SAFETY INSTRUCTION [LCD] USA Стр. 2 из 3 inflammability, voltage resistance, etc. therefore, use only replacement parts that have these same characteristics. Use only the specified parts when the mark is indicated in the circuit diagram or parts list. 7. Parts mounting and routing dressing of wirings should be the same as that used originally.

  • Page 41: Product Safety Notice

    SAFETY INSTRUCTION [LCD] USA Стр. 3 из 3 limit constitutes a potential shock hazard and must be corrected immediately. Product Safety Notice Many electrical and mechanical parts in this chassis have special safety-related characteristics. These characteristics are often passed unnoticed by a visual inspection and the protection afforded by them cannot necessarily be obtained by using replacement components rated for higher voltage, wattage, etc.

  • Page 42: Specification

    Стр. 1 из 2 SPECIFICATION file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.631\37H... 10.05.2015...
  • Page 43 Стр. 2 из 2 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.631\37H... 10.05.2015...
  • Page 56 SIGNAL BOARD AV BOARD PANEL DDR RAM FLI8538 CORTEZ Plus VBI Data Processor PANEL I/F DCDi Video Input Analog MADi Decoder Terminal Front Scaling (Audio) (16port) LVDS CVBS(L/R) S-VIDEO(L/R) YCbCr(L/R) Channel Standby Process uCON Digital Input A EEPROM PC_IN(L/R) Digital Input B Micro- processor...

  • Page 57: Schematic Diagram

    Стр. 1 из 2 SCHEMATIC DIAGRAM Precaution WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION" FOR DIRECT VIEW CTV ONLY, "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" OF THIS MANUAL. CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit...
  • Page 58 Стр. 2 из 2 All capacitors are ceramic 50 V, unless otherwise noted as the following marks. = Electrolytic capacitor = Mylar capacitor 3. The parts indicated with " " have special characteristics, and should be replaced with identical parts only. 4.
  • Page 112 Accessory Стр. 1 из 1 Accessory Location Parts No. Description Y101 75002553 MANUAL ENG/FRE Y109 23945015 BAG, POLYETHYLENE COVER 250X400 Y130 75002548 REMOCON HAND UNIT HL86, CT-90262 Y170 23845800 HOLDER, WIRE, NYLON66 D6.8 file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.833\37H... 10.05.2015...
  • Page 113 Cabinet Стр. 1 из 1 Cabinet Location Parts No. Description A201 75002570 CESE/COVER/LID FRONT BEZEL ASSY A315 75002076 PIECE C COVER ASSY 37C1000 A320 75002550 PIECE FRONT AV ASSY A340 75001920 PIECE BUTTON 7 KEY A380 23717240 SCREW, BITTB3X10SZN A401 75002569 CESE/COVER/LID BACK COVER ASSY A410...
  • Page 114 Miscellaneous Стр. 1 из 1 Miscellaneous Location Parts No. Description B001 75001858 DISPLAY, G6AUO37 V2 P801 23372264 POWER CORD, U/C 125V10A HSV 5 CMC-02P 11111 PJ22B 75001874 CONNECTOR, B-B PLUG PP01 23845859 HOLDER, WIRE, PVC-C0AT, L=70MM PP05 23845856 CLAMP, WIRE, POF COAT) L=70MM PP08 23974994 BAND, KESSOKU...
  • Page 115 Packing Стр. 1 из 1 Packing Location Parts No. Description A701A 75002574 CARTON TOP CASE A701B 75002571 CARTON BOTTOM CASE A702A 75002572 PAD TOP PACKING A702B 75002573 PAD BOTTOM PACKING A703 23945216 BAG, LAMIFILM BAG A709 75002346 PAD CENTER PACKING file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.122\37H...

  • Page 116: Parts List

    Стр. 1 из 2 PARTS LIST Precaution WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION" FOR DIRECT VIEW CTV ONLY, "SAFETY PRECAUTION" AND "PRODUCT SAFETY NOTICE" OF THIS MANUAL. CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which have special characteristics important for safety and should be replaced only with types identical to those in the original circuit...
  • Page 117 Стр. 2 из 2 : Electrolytic : Metal Film : Fusible Resistor All CD and PF capacitors are ±5 %, 50 V and all resistor, ±5 %, 1/6 W unless otherwise noted. file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.121\37H... 10.05.2015...
  • Page 118 U01A POWER (PE0103) Стр. 1 из 4 U01A POWER (PE0103) Location Parts No. Description U01A 75002567 PWU, POWER, B910PE0103C1 C801 76503507 PLASTIC FILM, AC275V 0.22UF K C802 76503507 PLASTIC FILM, AC275V 0.22UF K C803 76168103 PLASTIC FILM 92T 400V 220NF J C804 76214103 CERAMIC DISC, 500V B 0.01UF K...
  • Page 119 U01A POWER (PE0103) Стр. 2 из 4 CE43 76503041 PLASTIC FILM , 63V 0.1UF J CE82 76676470 ELECTROLYTIC, 100V 47UF M CE85 76073178 ELECTROLYTIC, 25V 3300UF M D801 23362200 DIODE, D5SB60, 7009F07 D801B 23717240 SCREW, BITTB3X10SZN D805 23357627 DIODE, ZENER, RD9.1ESA B1 D806 23357666 DIODE, ZENER, RD27ESA B3...
  • Page 120 U01A POWER (PE0103) Стр. 3 из 4 FE01 23144380 FUSE, RADIAL LEAD SUB-MINIATUR, 250V 3.15A FE72 23144708 FUSE, AXIAL, 125V 1A FE75 23144715 FUSE, CARTRIDGE 5.2X20, 125V 5A L801 23217834 TRANSFORMER, CHOKE, TPW2078AS L802 23217792 TRANSFORMER, CHOKE, TPW2072AS L806 23248417 COIL, CHOKE, TLN3481AH L807 23248417...
  • Page 121 U01A POWER (PE0103) Стр. 4 из 4 R815 76552100 OXIDE METAL FILM, 1/2W 10 OHM J R816 76011331 CHIP, 1/20W 330 OHM J R817 76382823 OXIDE METAL FILM, 1W 82K OHM J R821 76553680 OXIDE METAL FILM, 1W 68 OHM J R827 76383103 OXIDE METAL FILM, 2W 10K OHM J...
  • Page 122 U01B LOWB (PE0103) Стр. 1 из 3 U01B LOWB (PE0103) Location Parts No. Description U01B 75002568 PWU, LOWB, B910PE0103C2 C851 76092538 CERAMIC CHIP, 10V F 1UF Z C852 76109102 CERAMIC CHIP, 50V B 1000PF K CE40 76073183 ELECTROLYTIC, 35V 220UF M CE42 76539104 PLASTIC FILM, 50V 0.1UF J...
  • Page 123 U01B LOWB (PE0103) Стр. 2 из 3 Q856 23205327 TRANSISTOR, RN1406(F) Q860 75001881 IC, CE-1059 QE40 23085463 IC, SI-8050E QE52 23205567 TRANSISTOR, RN2403(TE85L,F) QE53 23205330 TRANSISTOR, RN1403(F) QE64 23085415 IC, BD4746G QE71 75001881 IC, CE-1059 QE74 23205330 TRANSISTOR, RN1403(F) QE82 23205446 TRANSISTOR, 2SC2412K, Q T146 QE90...
  • Page 124 U01B LOWB (PE0103) Стр. 3 из 3 RE95 76553122 OXIDE METAL FILM, 1W 1.2K OHM J RE96 76011473 CHIP, 1/20W 47K OHM J RE97 76011562 CHIP, 1/20W 5.6K OHM J RE98 76011104 CHIP, 1/20W 100K OHM J file://C:\Documents and Settings\Alexsandr\Local Settings\Temp\Rar$EXa0.318\37H... 10.05.2015...
  • Page 125 U02A AV TERM (PE0102) Стр. 1 из 6 Loading ... Location Parts No. Description U02A 75002543 PWU, AV TERM, B910PE0102A1 C102 76073019 ELECTROLYTIC, 10V 470UF M C103 76109102 CERAMIC CHIP, 50V B 1000PF K C104 76766479 ELECTROLYTIC, 50V 4.7UF M C105 76073019 ELECTROLYTIC, 10V 470UF M...
  • Page 126 U02A AV TERM (PE0102) Стр. 2 из 6 C630 76092730 CERAMIC CHIP, 16V B 0.1UF K C635 76666221 ELECTROLYTIC, 16V 220UF M C636 76666221 ELECTROLYTIC, 16V 220UF M C640 76092738 CERAMIC CHIP, 25V B 0.47UF K C641 76092738 CERAMIC CHIP, 25V B 0.47UF K C642 76285104 CERAMIC CHIP, 50V B 0.1UF K...
  • Page 127 U02A AV TERM (PE0102) Стр. 3 из 6 CG13 76669100 ELECTROLYTIC, 50V 10UF M CG14 76669100 ELECTROLYTIC, 50V 10UF M CG15 76105101 CERAMIC CHIP, 50V CH 100PF J CG16 76105101 CERAMIC CHIP, 50V CH 100PF J CG17 76669470 ELECTROLYTIC, 50V 47UF M CG20 76669100 ELECTROLYTIC, 50V 10UF M...
  • Page 128 U02A AV TERM (PE0102) Стр. 4 из 6 CV212 76793471 ELECTROLYTIC, 10V 470UF M CV213 76100104 CERAMIC CHIP, 25V F 0.1UF Z D401 23357703 DIODE, 1SS355 D621 23362140 DIODE, KDS160-RTK D622 23362214 DIODE, SCHOTTKY, RSX301L-30 TE25 D623 23362214 DIODE, SCHOTTKY, RSX301L-30 TE25 D624 23362140 DIODE, KDS160-RTK...
  • Page 129 U02A AV TERM (PE0102) Стр. 5 из 6 L103 23103233 INDUCTOR, BEAD, TEM2137AD L104 23103233 INDUCTOR, BEAD, TEM2137AD L190 23103233 INDUCTOR, BEAD, TEM2137AD L414 23289985 COIL, PEAKING, TRF4100AF L620 23246406 COIL, CHOKE, TLN3528AF L621 23246406 COIL, CHOKE, TLN3528AF L622 23246406 COIL, CHOKE, TLN3528AF L623 23246406...
  • Page 130 U02A AV TERM (PE0102) Стр. 6 из 6 Q681 23205506 TRANSISTOR, 2SC4081 Q Q4100 23085635 TRANSISTOR, 2SC3437-Y(TE85L,F) Q4101 23085635 TRANSISTOR, 2SC3437-Y(TE85L,F) Q4102 23085635 TRANSISTOR, 2SC3437-Y(TE85L,F) Q4103 23085635 TRANSISTOR, 2SC3437-Y(TE85L,F) QA01 75001884 IC, T5CB5-6G52(F,JZ) QA03 75001878 IC, TC7SH126FU(TE85L,F) QA70 23205506 TRANSISTOR, 2SC4081 Q QA71 23205506 TRANSISTOR, 2SC4081 Q...
  • Page 131 U02B FRONT AV-1 (PE0102) Стр. 1 из 1 U02B FRONT AV-1 (PE0102) Location Parts No. Description U02B 75002544 PWU, FRONT AV-1, B910PE0102A2 CC11 76109102 CERAMIC CHIP, 50V B 1000PF K CC12 76109102 CERAMIC CHIP, 50V B 1000PF K CV12 76109103 CERAMIC CHIP, 50V B 0.01UF K CV13 76105101...
  • Page 132 U02C LED (PE0102) Стр. 1 из 1 U02C LED (PE0102) Location Parts No. Description U02C 75002545 PWU, LED, B910PE0102A3 CB02 76202221 ELECTROLYTIC, 10V 220UF M CB03 76100104 CERAMIC CHIP, 25V F 0.1UF Z CB04 76100104 CERAMIC CHIP, 25V F 0.1UF Z CB05 76202221 ELECTROLYTIC, 10V 220UF M...
  • Page 133 U02D KEY (PE0102) Стр. 1 из 1 U02D KEY (PE0102) Location Parts No. Description U02D 75002546 PWU, KEY, B910PE0102A4 DA01 23362042 DIODE, ZENER, UDZS6.8B DA06 23362042 DIODE, ZENER, UDZS6.8B DA07 23362042 DIODE, ZENER, UDZS6.8B PJ42A 23713948 CONNECTOR, S6B-PH-K-S(LF) RA71 76011683 CHIP, 1/20W 68K OHM J RA72 76011223...
  • Page 134 U03 SIGNAL (PE0081) Стр. 1 из 6 Loading ... Location Parts No. Description 75004717 PWB, SIGNAL C301 V01GD0000896 CHIP RESISTOR (1608) C302 V01GD0000896 CHIP RESISTOR (1608) C303 V01GD0000896 CHIP RESISTOR (1608) C304 V01GD0000896 CHIP RESISTOR (1608) C305 V01GD0000896 CHIP RESISTOR (1608) C306 V01GD0000896 CHIP RESISTOR (1608) C307...
  • Page 135 U03 SIGNAL (PE0081) Стр. 2 из 6 C375 V03GD0000578 CHIP CERAMIC CAPACITOR (1608) C376 V03GD0000541 CHIP CERAMIC CAPACITOR (1608) C377 V03GD0000541 CHIP CERAMIC CAPACITOR (1608) C378 V03GD0000741 CHIP CERAMIC CAPACITOR (3216) C379 V03GD0000741 CHIP CERAMIC CAPACITOR (3216) C380 V03GD0001318 CHIP CERAMIC CAPACITOR (2012) C381 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C401...
  • Page 136 U03 SIGNAL (PE0081) Стр. 3 из 6 C491 V03A000003Q0 CAPACITOR C492 V03A000003Q0 CAPACITOR C493 V03A000003Q0 CAPACITOR C494 V03A000004Q0 CAPACITOR CHIP CERA 25V 104S 3 C495 V03GD0000585 CHIP CERAMIC CAPACITOR (1608) C496 V03GD0000585 CHIP CERAMIC CAPACITOR (1608) C773 V03GD0001131 CHIP CERAMIC CAPACITOR (2012) C774 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C775...
  • Page 137 U03 SIGNAL (PE0081) Стр. 4 из 6 C947 V03A000003Q0 CAPACITOR C948 V03A000003Q0 CAPACITOR C949 V03A000003Q0 CAPACITOR C950 V03A000003Q0 CAPACITOR C951 V03GD0001192 CHIP CERAMIC CAPACITOR (1005) C953 V03GD0001126 CHIP CERAMIC CAPACITOR (1608) C2000 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C2001 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C2002 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C2003...
  • Page 138 U03 SIGNAL (PE0081) Стр. 5 из 6 C3414 V03GD0000538 CHIP CERAMIC CAPACITOR (1608) C3415 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C3416 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C3417 V03GD0000589 CHIP CERAMIC CAPACITOR (1608) C3418 V03GD0000589 CHIP CERAMIC CAPACITOR (1608) C3419 V03GD0000538 CHIP CERAMIC CAPACITOR (1608) C3420 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C3421...
  • Page 139 U03 SIGNAL (PE0081) Стр. 6 из 6 C7909 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7910 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7911 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7912 V03GD0000572 CHIP CERAMIC CAPACITOR (1608) C7913 V03GD0001131 CHIP CERAMIC CAPACITOR (2012) C7914 V03GD0001131 CHIP CERAMIC CAPACITOR (2012) C7915 V03GD0001131 CHIP CERAMIC CAPACITOR (2012) C7916...
