ge.com
Owner's Manual &
Connect Electricity . . . . . . . . . . . . . . . .3
Installation Instructions
Extension Cords . . . . . . . . . . . . . . . . . .2
Models 22, 25
Proper Disposal . . . . . . . . . . . . . . . . . .2
Safety Precautions . . . . . . . . . . . . . . . .2
Operating Instructions
Additional Features . . . . . . . . . . . . . . .9
Automatic Icemaker . . . . . . . . . . . . . .10
Controls . . . . . . . . . . . . . . . . . . . . . .4, 5
Crispers and Pans . . . . . . . . . . . . . .9, 10
Shelves and Bins . . . . . . . . . . . . . . . .7, 8
Water Dispenser . . . . . . . . . . . . . . . .11
Water Filter . . . . . . . . . . . . . . . . . . . . .6
Care and Cleaning . . . . . . . . . . . . . . .11
Replacing the Light Bulbs . . . . . . . . .12
Preparing to Install
the Refrigerator . . . . . . . . . . . . . . . . .13
Reversing the Door Swing . . . . . .18-22
Water Line Installation . . . . . . . .14-18
. . . . . . . . .24-26
Normal Operating Sounds . . . . . . . .23
Consumer Support
Consumer Support . . . . . . .Back Cover
Performance Data Sheet . . . . . . . . . .27
Device Certificate . . . . . . . . . . . . . . . .28
Warranty for Canadian Customers . .29
Warranty for U.S. Customers . . . . . . .30
Write the model and serial numbers here:
Model #__________________________
Serial # __________________________
Find these numbers on the gray label
on the left side, near the top of the
refrigerator compartment.
200D8114P001
49-60444 11-05 JR
Advertisement
Table of Contents
Related Manuals for GE GTL22JBPBS
Summary of Contents for GE GTL22JBPBS
-
Page 1: Table Of Contents
Installation Instructions Preparing to Install the Refrigerator ....13 Reversing the Door Swing ..18–22 Water Line Installation ..14–18 Troubleshooting Tips . -
Page 2: Extension Cords
Installation Instructions before it is used. Do not allow children to climb, stand or hang on the shelves in the refrigerator. They could damage the refrigerator and seriously injure themselves. Do not touch the cold surfaces in the freezer compartment when hands are damp or wet. -
Page 3: Safety Instructions Connect Electricity
This provides the best performance and also prevents overloading house wiring circuits which could cause a fire hazard from overheated wires. Never unplug your refrigerator by pulling on the power cord. Always grip plug firmly and pull straight out from the outlet. -
Page 4: Controls
3 SECS IS COLDEST IS COLDEST Initially, set the refrigerator control at 5 and the freezer control at 5 and allow 12–24 hours for the temperature to stabilize. Several adjustments may be required. Adjust the controls one increment at a time, and allow 12 hours after each adjustment for the refrigerator to reach the temperature you have set. - Page 5 24 hours for the temperature to stabilize to the preset recommended settings. The temperature controls can display both the SET temperature as well as the actual temperature in the refrigerator and freezer. The actual temperature may vary slightly from the SET temperature based on usage and operating environment.
-
Page 6: Water Filter
Replacement Filters To order additional filter cartridges in the United States, visit our Website, ge.com, or call GE Parts and Accessories, 800.626.2002. Filter Model GSWF Suggested Retail Price $34.95 USD... -
Page 7: Shelves And Bins
About the shelves and bins. Not all features are on all models. Rearranging the Shelves Shelves in the refrigerator and freezer compartments are adjustable. Refrigerator Compartment To remove: Tilt the shelf up at the front. Lift the shelf up at the back and bring the shelf out. - Page 8 Adjustable Bins on the Door Finger hold Snugger Adjustable bins can easily be carried from refrigerator to work area. To remove: Lift the bin straight up, then pull out. To replace or relocate: Engage the bin in the molded supports of the door, and push in.
-
Page 9: Additional Features
(on some models) The settings can be adjusted anywhere between cold When set at cold, the pan will stay at the normal refrigerator temperature. The coldest setting provides the coldest storage area. ge.com and coldest... -
Page 10: Automatic Icemaker
To Remove: These drawers can be removed easily by lifting up slightly while pulling the drawer past the stop location. About the automatic icemaker. A newly-installed refrigerator may take 12–24 hours to begin making ice. Automatic Icemaker Power Switch Icemaker The icemaker will produce seven or eight cubes (depending on model) per cycle—... -
Page 11: Water Dispenser
Do not wipe the refrigerator with a soiled dish cloth or wet towel. These may leave a residue that can erode the paint. Do not use scouring pads, powdered cleaners, bleach or cleaners containing bleach because these products can scratch and weaken the paint finish. -
Page 12: Replacing The Light Bulbs
To remove the light shield, grasp the shield as shown. Squeeze the shield and rotate the shield toward the back of the refrigerator. The light shield will pop out. Freezer Compartment Light CAUTION: Unplug the refrigerator. -
Page 13: Installation Instructions
(ON SOME MODELS) If the refrigerator has an icemaker, it will have to be connected to a cold water line. A GE water supply kit (containing tubing, shutoff valve, fittings and instructions) is available at extra cost from your dealer, by visiting our Website at ge.com (in Canada at... -
Page 14: Water Line Installation
WX08X10025). When connecting your refrigerator to a GE Reverse Osmosis Water System, the only approved installation is with a GE RVKit. For other reverse osmosis water systems, follow the manufacturer’s recommendations. This water line installation is not warranted by the refrigerator or icemaker manufacturer. - Page 15 Installation Instructions WHAT YOU WILL NEED • A GE water supply kit (containing tubing, shutoff valve and fittings listed below) is available at extra cost from your dealer or from Parts and Accessories, 800.626.2002. • A cold water supply. The water pressure must be between 20 and 120 p.s.i.
-
Page 16: Installing The Water Line
Make sure the tubing is fully inserted into the valve. Tighten the compression nut securely. For plastic tubing from a GE SmartConnect Refrigerator Tubing kit, insert the molded end Vertical Cold of the tubing into the shutoff valve and tighten... - Page 17 Remove the access cover. Remove the plastic flexible cap from the water valve (refrigerator connection). Place the compression nut and ferrule (sleeve) onto the end of the tubing as shown. On GE SmartConnect ™ Refrigerator Tubing kit, the nuts are already assembled to the tubing.
-
Page 18: Reversing The Door Swing
INSTALLING THE WATER LINE PLUG IN THE REFRIGERATOR Arrange the coil of tubing so that it does not vibrate against the back of the refrigerator or against the wall. Push the refrigerator back to the wall. START THE ICEMAKER Power switch models – Set the icemaker power switch to the I (on) position. -
Page 19: Remove The Freezer Door
Remove the tape and tilt the door away from the cabinet. Lift it off the center hinge pin. Set the door on a non-scratching surface with the inside up. REMOVE THE REFRIGERATOR DOOR Tape the door shut with masking tape. Remove the center hinge pin with a 3/4″ socket. - Page 20 REVERSING THE DOOR SWING TRANSFER BOTTOM HINGE BRACKET TO THE LEFT Remove the base grille by pulling it straight out. Using a socket driver, move the bottom hinge bracket from the right side to the left side. NOTE: If the washer is not on the hinge bracket, check to see if it is stuck to the bottom of the door.
- Page 21 Installation Instructions TRANSFER REFRIGERATOR DOOR HANDLE TO THE RIGHT To remove the handle: Remove the plug button by carefully prying under the edge with a putty knife. Remove the exposed screw holding the handle. Handle Plug Remove the two screws holding the handle to the top of the door.
-
Page 22: Rehang The Refrigerator Door
Installation Instructions (CONT.) REHANG THE REFRIGERATOR DOOR Lower the refrigerator door onto the bottom hinge pin. Straighten the door and line it up with the center hinge bracket. Reinstall the center hinge pin with a 3/4″ socket. -
Page 23: Normal Operating Sounds
This happens when the refrigerator is first plugged in, when the doors are opened frequently or when a large amount of food is added to the refrigerator or freezer compartments. If either door is open for over 3 minutes, you may hear the fans come on in order to cool the light bulbs. -
Page 24: Troubleshooting Tips
What To Do • Wait about 40 minutes for defrost cycle to end. • Move the refrigerator and freezer control to a temperature setting. • Push the plug completely into the outlet. •Replace fuse or reset the breaker. - Page 25 •See About the controls. • Call a plumber. • Foods with strong odors should be tightly wrapped. • Keep an open box of baking soda in the refrigerator; replace every three months. • See Care and cleaning. • Replace fuse or reset the breaker.
- Page 26 Unit just plugged in. equal to Set temperature Door open for too long. (on some models) Warm food added to refrigerator. • Allow 24 hours for system to stabilize. Defrost cycle is in process. What To Do •See Installing the water line.
-
Page 27: Performance Data Sheet
This system has been tested according to NSF/ANSI 42/53 for reduction of the substances listed below. The concentration of the indicated substances in water entering the system was reduced to a concentration less than or equal to the permissible limit for water leaving the system, as specified in NSF/ANSI 42/53.* (100% safety factors built in for unmetered usage) Parameter USEPA... -
Page 28: State Of California Water Device Certificate
Trademark/Model Designation GE GSWF Manufacturer: General Electric Consumer Products The water treatment device(s) listed on this certificate have met the testing requirements pursuant to Section 116830 of the Health and Safety Code for the following health related contaminants: Microbiological Contaminants and Turbidity... -
Page 29: Terms And Conditions
CUSTOMER WARRANTY Your refrigerator is warranted to be free of defects in material and workmanship. What is covered How Long Warranted (From Date of Sale) Compressor GE Profile: Ten (10) Years Brands: One (1) Year Sealed System (including GE Profile: Five (5) Years... -
Page 30: Warranty For U.s. Customers
This warranty is extended to the original purchaser and any succeeding owner for products purchased for home use within the USA. If the product is located in an area where service by a GE Authorized Servicer is not available, you may be responsible for a trip charge or you may be required to bring the product to an Authorized GE Service location for service. - Page 31 Notes. ge.com...
- Page 32 Customers in Canada should consult the yellow pages for the nearest Camco service center, or call 1.888.261.3055. Contact Us If you are not satisfied with the service you receive from GE, contact us on our Website with all the details including your phone number, or write to: General Manager, Customer Relations In Canada: www.geappliances.ca, or write to: Director, Consumer Relations, Camco, Inc.
