GE JGBS04PPM Dimensions And Installation Information

JGBS04PPM
GE 30" Free-Standing Gas Range
®
Dimensions and Installation Information (in inches)
Factory set for Natural gas. A set of LP orifices is
included with each range for LP conversion.
Gas Self-Clean Range Anti-Tip Bracket
(Part No. 205C1714P001)
Electrical Rating: 120V, 60Hz, 5A
Installation Information: Before installing,
consult installation instructions packed with
product for current dimensional data.
For answers to your Monogram, GE Profile
®
GE ® appliance questions, visit our website at
ge.com or call GE Answer Center
®
800.626.2000.
46-7/8
25-5/16*
46-1/4
46-7/8
25-5/16*
46-1/4
or
™
service,
36-1/4 ± 1/4
* Dimension from wall
to front of closed
door handle is 29".
30
36-1/4 ± 1/4
* Dimension from wall
to front of closed
door handle is 29".
Recommended area for
120V outlet on rear wall
and area for thru the wall
8
connection of pipe stub
and shut-off valve
4
9
Recommended area for
120V outlet on rear wall
and area for thru the wall
connection of pipe stub
and shut-off valve
All GE ranges are equipped with
an Anti-Tip device. The installation
of this device is an important,
required step in the installation
of the range.
Specification Created 4/08
Recommended common
area for gas outlet and
electrical outlet
30
2-1/2
24
2
C L
Recommended area for
thru the floor connection
of pipe stub and shut-off valve
Recommended c
area for gas outle
electrical outlet
30
2-1/2
8
4
24
2
9 330518
C L
Recommended area for
thru the floor connection
