Sliding Attachment Kit
RT1200 Trencher
Model No. 25454—Serial No. 314000001 and Up
Model No. 25454E—Serial No. 314000001 and Up
Loose Parts
Use the chart below to verify that all parts have been shipped.
Description
Slide mount
Pivot pin
Boom cylinder pin
Threaded rod
Hex Nut
Flat Washer (5/8 inch)
Retaining ring
Screw (3/8 inch)
Washer (3/8 inch)
Nut (3/8 inch)
Slide plate
Wear strip
Upper slide plate
Idler wheel
Bearing
Chain assembly
Roller axle
Square hole washer
Washer (2 1/2 inch)
Washer (5/8 inch)
Hex bolt (5/8 x 1 3/4 inch)
Hex bolt (5/8 x 2 3/4 inch)
Hydraulic cylinder boom
No parts required
Side Shift
Bolt
Washer
Nut
Hydraulic line
Note: Additional hydraulic components are required for the
operation of this kit. Please see your Authorized Toro Dealer
for additional information.
© 2014—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
Qty.
1
1
1
2
4
10
2
1
1
1
1
2
Assemble the kit
1
2
2
2
2
12
3
4
3
1
1
–
Prepare the machine.
1
6
6
Install the mounting frame.
6
2
Register at www.Toro.com.
Form No. 3377-984 Rev A
Installation Instructions
Use
Original Instructions (EN)
All Rights Reserved *3377-984* A
Printed in the USA
Advertisement
Related Manuals for Toro 25454
Summary of Contents for Toro 25454
- Page 1 Bolt Washer Install the mounting frame. Hydraulic line Note: Additional hydraulic components are required for the operation of this kit. Please see your Authorized Toro Dealer for additional information. © 2014—The Toro® Company Register at www.Toro.com. Original Instructions (EN) All Rights Reserved *3377-984* A...
- Page 2 WARNING CALIFORNIA Proposition 65 Warning This product contains a chemical or chemicals known to the State of California to cause cancer, birth defects, or reproductive harm.
- Page 3 Assembling the Sliding Attachment Kit 1. Stack the boom idler wheel assembly (Figure 1). g025743 Figure 1 3. Bearing 1. Square-hole washer 2. Idler wheel 2. Slide the boom-idler wheel into the slid mount assembly, and insert the slide plate and wear strip (Figure 2).
- Page 4 3. Slide the-side-boom idler wheel into the mount assembly (Figure 3). g025745 Figure 3 1. Side-boom-idler wheel 4. Install the roller axle to secure the roller into place (Figure 4). Note: Slide the boom so that you can install the top bolt.
- Page 5 6. Install the chains to the frame of the attachment 8. Attach the chain assembly to the threaded rods (Figure (Figure 6). 1 2 3 g025750 Figure 8 1. Chain assembly 3. Chain retaining pin 2. Chain pin 4. Threaded rod 9.
- Page 6 10. Install the cylinder mounting fitting end of the hydraulic cylinder to the attachment frame (Figure 10). g025752 Figure 10 1. Cylinder-mounting fitting 4. Washer (3/8 inch) 2. Attachment frame 5. Boom cylinder pin 3. Nut (3/8 inch) 6. Screw (3/8 inch)
-
Page 7: Preparing The Machine
Note: Install new attachments to the front of the mounting face of the sliding attachment kit as you would to the front of the machine’s mounting face. Longer hydraulic lines will be needed. Contact your Authorized Toro Dealer for more information.
