Backhoe Drive Release Kit
RT600 Traction Unit with Backhoe
Model No. 25433
Model No. 25433E
Loose Parts
Use the chart below to verify that all parts have been shipped.
Description
Hydraulic fitting (90 degree)
Elbow fitting (90 degree)
Flange-head bolt (1/4 x 1-3/4 inches)
Flange-head bolt (M8 x 1-1/4 inch)
Orifice (0.080 inch)
Elbow fitting (45 degree)
Cable tie
Bolt (5/16 x 1 inch)
Washer
Nut (5/16 inch)
10 Amp fuse
WARNING
CALIFORNIA
Proposition 65 Warning
This product contains a chemical or chemicals
known to the State of California to cause cancer,
birth defects, or reproductive harm.
Installing the Valve Assembly
WARNING
If the engine has been running, the hydraulic fluid
and components may be hot and could burn you.
Allow the machine to cool before performing this
procedure.
© 2014-The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
Qty.
1
2
1
1
Install the valve assembly.
2
2
2
1
2
2
Installing the hydraulic hoses.
5
1
1
2
2
Install the valve switch.
2
2
1
5
Register at www.Toro.com.
Installation Instructions
Use
1. Park the machine on a firm, level surface.
2. Lower all attachments to the ground.
3. Turn off the engine, remove the key, and allow the
machine to cool completely.
4. Remove the left-side, engine cover; refer to the RT600
Traction Unit Operator's Manual for instructions.
5. Loosen the 4 bolts securing the access panel in front of
the traction unit seat, and remove the panel (Figure 1).
Original Instructions (EN)
All Rights Reserved *3377-954* B
Printed in the USA
Form No. 3377-954 Rev B
