INDEX This user’s manual describes the jumper setting of B59 Main Board. For detailed technical information, please refer to CDs attached with PC system unit. Table of Contents Page Technical details 1. Jumpers location diagram for B59 main board 2. Memory configuration 3.
Memory configuration for “B59 V1.X” main board l System Memory Configuration Capacity DIMM 1 DIMM 2 16MB None 16MB 32MB 16MB 16MB 32MB 32MB None 32MB 32MB 64MB 64MB None 64MB 16MB 64MB 80MB 80MB 64MB 16MB 128MB 64MB 64MB...
Page 6
Open Open Open Close Close Close Open AMD K6-2/400MHz Close Open Close Close Close Close Open AMD K6-3/400MHz AMD K6-3/450MHz Close Close Close Close Close Close Open AMD K6 -2/450MHZ AMD K6-2/500MHZ Open Close Close Close Close Close Open AMD-K6-3/500MHZ...
Page 7
l CPU Voltage selection : Vcore 9-10 Open Open Close Open Close Open Close Close Open Close Open Open Open Close Close Open Close Open Close Close Open Open Close Close Close Open Close Close Close Close Close Open Open Open Open Open...
Page 8
l Disk On Chip address selection: JP12, JP13 Address JP12 JP13 0 C C 0 0 H – 0 C D F F H 0 D 0 0 0 H – 0 D 1 F F H 1-2 0 D 4 0 0 H – 0 D 5 F F H 3-4 0 D 8 0 0 H –...
Page 9
=Digital I/O (4 Output & 4 Input) : J5 This main board provide the basic digital I/O signal controller, user can develop the program and extra controller to open and sense of the cash drawer based on the digital I/O function on this main board. PIN ASSIGNMENT Out 1 VDC +12V...
Page 10
ν Digital output programming The output is TTL Level. The output signal must be TTL compatible. Output Address Out 0 Out 1 Out 2 Out 3 Example : ( “0” = off “1” =on ) Data 00 = Out 0 and Out 1 = “0” Data 01 = Out 0 = “1”...
