- Page 1 SERVICE MANUAL PS2030 Seeder Part number 47918064 English January 2015 © 2015 CNH Industrial Italia S.p.A. All Rights Reserved.
- Page 2 SERVICE MANUAL PS2030 Standard 47918064 10/09/2015 Find manuals at https://best-manuals.com...
- Page 3 Contents INTRODUCTION Hydraulic systems............... 35 [35.744] Seeding and planting hydraulic circuits ..........35.1 Wheels ..................
- Page 4 INTRODUCTION 47918064 10/09/2015 Find manuals at https://best-manuals.com...
- Page 5 Contents INTRODUCTION Safety rules ..................3 Basic instructions .
-
Page 6: Safety Rules
INTRODUCTION Safety rules PERSONAL PROTECTIVE EQUIPMENT (PPE) RECOMMENDED 1. Ear protector. 2. Gloves. 3. Boots (with steel toe). 4. Overalls. 5. Glasses. BAIL14SE00801AA SEM19101776 SAFETY FEATURES FOUND IN THE MACHINE 1. Support stands: provide safe support of the front part of the machine when performing maintenance and ad- justments. - Page 7 INTRODUCTION 2. Safety chains: avoid lack of control over machine in case of accidental disengagement between the draw- bar of the Seeder and the drawbar of the tractor. Also, they limit the descent of the lift arms and the drawbar. BAIL14SE00801AC 3.
- Page 8 INTRODUCTION • For operations performed by default of the current regulations, the consequences must be borne by the operator. When displacement with the tractor is allowed: • Use alerting devices, such as flags, slow vehicle emblems, lights, etc., approved by the current local traffic laws. Keep these devices clean and in good condition.
- Page 9 INTRODUCTION When removing, reinstalling or moving heavy assemblies • Always use appropriate devices to attach and lift whole and/or heavy assemblies. • Never stand under suspended loads. As safe as the lifting equipment may be, it is not worth running the risk! •...
- Page 10 INTRODUCTION • With the engine running: Do not touch or enter the seed or fertilizer box and not perform any repairs or adjust- ments, and also Do not access the supply platform. • Do not wear loose clothing, blankets or loose hair (if long), jewelery such as rings, bracelets and necklaces: moving parts could wind, pull and tear such items, with a risk of serious injury!
- Page 11 INTRODUCTION • Close all safety devices before starting the machine. This will prevent other materials from getting tangled on gears, chains, shafts and other moving parts of the system. SEM19101786 • Keep away from the articulated parts of the machine, such as row markers.
- Page 12 INTRODUCTION Care taken with hydraulic systems and fluids under pressure in general • Fluids escaping under pressure can penetrate the skin, causing injury and serious poisoning; fluids injected into the skin must be surgically removed as soon as possi- ble, as they may cause gangrene. •...
- Page 13 INTRODUCTION • Before disposing of used fluids and lubricants, always remember the environment: Do not pour or spill these products on the ground or water, or place them in con- tainers that could cause leaks. • Dispose of oils, solvents, paints and other products ad- equately, as established in the existing environmental legislation.
-
Page 14: Welding Work
INTRODUCTION Welding work • Use the proper PPE for this activity: mask, gloves and a leather apron. • In case of electric welding: always seek to connect the negative electrode near the point to be welded. • Only perform welding in well ventilated areas to avoid the concentration of toxic gases and dust. -
Page 15: Basic Instructions
INTRODUCTION Basic instructions HITCH THE MACHINE ONTO THE TRACTOR CAUTION Transport hazard! Always connect a safety chain between the machine and the implement. Only use a safety chain with a strength rating equal to or greater than the gross weight of the implement. Failure to comply could result in minor or moderate injury. - Page 16 INTRODUCTION Couple the seeder's quick coupling hoses onto the hydraulic system of the tractor. NOTICE: Ensure thorough cleaning of the quick couplers of hydraulic cylinder hoses. Keep the plastic caps in place while not in use. Do not couple hydraulic systems with impurities in the circuit into the tractor: serious damage can occur to the tractor. NOTE: Do not drive the hydraulic system without removing the locks (5).
- Page 17 INTRODUCTION Basic instructions PERIODIC MAINTENANCE TABLE Item / Frequency Every 10 h or daily Every 50 h or daily After the planting season Grease all grease fittings. Calibrate the tires Re-tighten bolts and nuts in For a new machine, do the general tightening daily, throughout the first week.
- Page 18 INTRODUCTION Clearance, adjusted by sprockets or fixed pulleys (1) • The chain, in this case, works with a clearance, mea- sured by deflection "X" in the longest free length of the chain. • The "X" deflection must be 1 to 2% of the "L" distance, measured between the centers of the farthest shafts.
- Page 19 INTRODUCTION NOTE: When opening (dismantle) a chain, note the cor- rect position of the lock (6) of the pins: the side with the opening should be facing the side opposite the direction of displacement (X) of the chain. NOTE: This prevents any interference of the chain with crop residues (such as corn stalks) from causing the re- moval of the lock (6) .
- Page 20 INTRODUCTION BAIL14TR00474EA Item Description Excessive pressure Low pressure Correct pressure: 1 - 3 bar (15 - 38 psi) GENERAL TIGHTENING OF BOLTS For further information refer to Torque (). • Incorrectly tightened bolts can drop a part, which may bend or break, damaging others. •...
