Shure N92E User Manual

N92E, Biradial
(elliptical)
10 x 18µ
(.0004 x .0007 in.)
{Output voltages given for stereo cut record; for MONO cut record, output voltage at both left channel and right
channel cartridge terminals will be 71% of figure above.
*Do not exceed indicated tracking force.
STYLUS REMOVAL AND REPLACEMENT
Replace the stylus as shown above. Always hold the
stylus only by the plastic grip; take care not to touch
or damage the diamond tip or shank.
1. Protect stylus with stylus guard when dusting turntable
2. Regulate tone arm set-down or changer mechanism to prevent stylus from striking edge of turntable or
record.
3. Do not handle tone arm while record is being played; handling may cause arm to sweep across record.
Use cuing device if available.
4. If manual set-down is necessary, release arm as soon as stylus engages groove
5. Do not activate arm without record on turntable.
6. Do not use damaged records.
7. Make certain cartridge is correctly mounted in tone arm; make certain stylus is properly inserted in car-
tridge.
8. Use appropriate vertical tracking force for each cartridge and stylus; forces outside recommended range
can cause stylus and record damage.
9. Follow turntable or tone arm instructions for antiskating force.
To maintain the original performance standards of your cartridge, be certain that any replacement stylus you
buy bears the following certification on the package: "This Stereo DYNETIC
tured by Shure Inc." AVOID INFERIOR IMITATIONS. THEY WILL SERIOUSLY DEGRADE THE PER-
FORMANCE OF YOUR CARTRIDGE. ALL GENUINE "DYNETIC
SHURE INC. LOOK FOR THE NAME SHURE ON THE STYLUS GRIP.
Shure Incorporated ("Shure"), 222 Hartrey Avenue, Evanston, Illinois 60202-3696, warrants to the owner
of this product that it will be free in normal use, of any defects in workmanship and materials for a period
of one year from date of purchase. You should retain proof of date of purchase. Shure is not liable for any
consequential damages. If this Shure product has any defects as described above, carefully repack the
unit, have it insured, and return it prepaid to:
If you are not in the United States, return the unit to your dealer or Authorized Service Center for repair.
The unit will be repaired or replaced and returned to you promptly, and if it cannot be repaired or replaced,
you may elect to receive a refund. This warranty does not include stylus wear.
PATENT NOTICE: Manufactured under one or more of the following U.S. Patents: 3,463,889; 4,194,744;
4,270,758; 4,275,888; D230,741; D230,995; D235,070; D235,351; D235,352; D235,658; D235,661;
D245,022; D245,433; D252,;628; D254,004; D257,676; D255,898; D258,586; D274,810; D274,811;
D274,812; D274,813; 4,441,177; 4,473,897; 4,514,836.
Copyright 2001, Shure Inc.
27A1958(AK)
SPECIFICATIONS
Red 5.0 mV 20 to
18,000
Hz
TO PRESERVE STYLUS LIFE
SPECIAL NOTE
FULL ONE-YEAR WARRANTY
Shure Incorporated
Attention: Service Department
222 Hartrey Avenue
Evanston, Illinois 60202–3696
Model N92E User Guide
Within 20 0.75
grams
2 dB dB
Minimum
at
1.5 grams
1 kHz
Maximum
STYLUS CLEANING
Use a soft brush with alcohol or an alcohol-distilled wa-
ter solution. Brush only from back to front as shown.
Commercial cleaning solutions may cause stylus dam-
age.


" STYLI ARE MANUFACTURED BY
400 Hz – 24 cm/sec
at 1.25 grams
Optimum
stylus is precision manufac-
Printed in Mexico
