- Page 1 USE AND CARE OF YOUR DELUXE Coffee Grinder CONTAINS A SECTION ON COFFEE FUNDAMENTALS Keep this booklet for future reference...
-
Page 2: Table Of Contents
Coffee Fundamentals ... 12 Coffee Storage ... 14 Specifications ... 14 Authorized Service ... 14 Available Spare Parts ... 15 Limited Warranty ... Back Cover 14002.9500B 8ø/00 © 1990 BUNN-O-MATIC CORPORATION WELCOME ® Deluxe Home Model ...finest and freshest cup of coffee possible... -
Page 4: Important Safeguards
(See Page 14). ❑ The use of attachments not recommended or sold by Bunn- O-Matic may cause fire, electric shock or injury. ❑ Do not allow the cord to... -
Page 5: Additional Precautions
ADDITIONAL PRECAUTIONS • Coffee Grinder - This unit is intended for household use only. Any required servicing other than normal cleaning and general user maintenance procedures should be performed by an authorized service facility (See Page 14). • Voltage Source - The grinder operates on 120 vac, 1.5 amp, 60Hz,... -
Page 6: Preparation For Grinding
Be sure the coffee grinder is unplugged for the following procedures: Step 1. Wipe the unit clean - Before using the BUNN Coffee Grinder for the first time, wipe any lint off all exposed surfaces of the unit. Remove the hopper lid and wipe all accessible surfaces with a damp cloth. - Page 7 WARNING DO NOT reach below the GRIND ADJUST knob while the unit is running. Step 3. Load hopper - Pour coffee beans into the hopper and fill to the desired level (See illustration below). One of two approaches may be used: (a) pre-weigh the beans for a desired amount of fresh coffee to be ground or (b) fill the hopper up to its capacity (slightly over one...
-
Page 8: Grinding Fresh Coffee
(See illustration below). Unless the coffee collector is correctly placed on the collector platform track and pushed all the way to the back, the coffee grinder will not operate. Step 3. Set OPERATING Knob - There are two basic methods for... - Page 9 turn the OPERATING Knob to OFF. The ground coffee is ready for brewing. Empty the coffee collector into the brewing filter. (Method 2) Automatic Grind - If the hopper has sufficient amount of coffee beans, the OPERATING Knob can be set to automatically grind the desired amount of coffee for brewing.
-
Page 10: Cleaning
PRECAUTIONS - Your coffee grinder should be periodically cleaned. NOTE Be sure to heed all the warnings located within the grinder. ❖ Be sure to unplug the unit before attempting any cleaning. ❖ Always empty beans from hopper before beginning any maintenance or routine cleaning procedures. - Page 11 Empty the coffee beans from the hopper. Step 4. Locate hex screw - Turn the coffee grinder upside down and locate the hex head screw in the center of the dechaffer. Be sure to read WARNING label.
-
Page 12: Coffee Fundamentals
Proper brewing techniques require precise control of the following functions; the water temperature, volume of water, and the proper brew time. All Bunn coffee makers are designed to perform these functions perfectly. Other important components to the recipe are the type of grind and amount of coffee used. - Page 13 3) Accurate Temperature - The temperature of the water is very important maintained by the Bunn Brewer for both brewing and holding coffee on the warmer. 4) Proper Grind - The correct coffee grind is one that permits the...
-
Page 14: Coffee Storage
SPECIFICATIONS Electrical - UL listed for household use only. The coffee grinder has an attached, polarized cord and requires 2-wire service with ground rated at 120 volts ac, 1 amp, single phase, 60Hz. 135 watts total. -
Page 15: Available Spare Parts
AVAILABLE SPARE PARTS Cleaning Brush - 14002.9100 Coffee Collector with Seal White - 14002.8610 Black - 14002.8611 Collector Seal - 14002.5800 Hopper Lid - 14002.5400 Cutting Burr - 14002.0400 Grind Shield - 14002.2100 Dechaffer - 14002.3000 Hex key - 14002.7700 Hex Screw (L.H. -
Page 16: Limited Warranty
LIMITED WARRANTY Bunn-O-Matic warrants the Bunn Coffee Grinder (“Grinder”), to be free from defects in material and workmanship existing at the time of manufacture and appearing within three (3) years from the date of original purchase. If such a defect appears during the warranty period, we will (at our sole option) repair or replace the defective unit with no charge for service or parts, provided that the unit is delivered at the customer’s expense to one...
